Summary of Contents for Ganz ZN-PTZ12VP-XT
-
Page 2: Information To User
INFORMATION TO USER CAUTION RISK OF ELECTRIC SHOCK, DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SEERIVCE PERSONEL. This symbol is intended to alert the user to the presence of un-insulated “dangerous voltage”... -
Page 3: Table Of Contents
NVC/IPE Series Installation Guide IPE5510 Installation Guide Table of Contents 1. FEATURES ......................... 4 2. PACKAGE CONTENTS ....................5 3. PART NAMES ......................6 4. INSTALLATION ......................8 4.1. Installation Template ...................... 9 4.2.Setting the Image Attribute ................... 10 4.3.Operating the OSD Menu ....................10 5. -
Page 4: Features
NVC/IPE Series Installation Guide IPE5510 Installation Guide 1. FEATURES Camera Indoor/Outdoor Mini PTZ Dome IP Camera (Vandal Proof) Sony 1/4” Super HAD CCD, 410K Pixel x12 Optical Zoom, x16 Digital Zoom (Max x192) True Day & Night (IR Cut Filter, DSS) ... -
Page 5: Package Contents
NVC/IPE Series Installation Guide IPE5510 Installation Guide 2. PACKAGE CONTENTS Unpack carefully and handle the equipment with care. The packaging contains: Camera DC power adaptor Terminal block Installation Template Power adaptor jack Screws and Anchor blocks Video BNC cable Hex wrench driver Quick Installation Guide The above contents are subject to change without prior notice. -
Page 6: Part Names
NVC/IPE Series Installation Guide IPE5510 Installation Guide 3. PART NAMES AUDIO RS-485 Vout ⑤ ① ② AUDIO RS-485 Vout ③ ④ * Models herein and their appearance are subject to change without any prior notice. 01A.02... - Page 7 NVC/IPE Series Installation Guide IPE5510 Installation Guide ① Micro SD Card Socket It is a memory card slot for external storage. ② LAN Connector (Ethernet) This is a RJ45 LAN connector for 10/100 Base-T Ethernet. LED1 LED2 This LED lights up as orange and turns green when the encoder is powered on. LED operation setting: For the factory default setting, LED 2 blinks for the heartbeat and LED 1 turns on for video signal.
-
Page 8: Installation
NVC/IPE Series Installation Guide IPE5510 Installation Guide 4. INSTALLATION Connect the LAN cable, power supply cable, and the video loop out cable with the camera. Place the installation template on the ceiling. Drill four holes on the template and insert anchor blocks into the holes. -
Page 9: Installation Template
NVC/IPE Series Installation Guide IPE5510 Installation Guide The camera may fall off the ceiling even after the proper installation and mounting. To prevent any accident, make sure the ceiling is firm and stable Caution enough to support the camera. If any reinforcement is needed, consult with your safety personnel and proceed with the installation. -
Page 10: Setting The Image Attribute
NVC/IPE Series Installation Guide IPE5510 Installation Guide 4.2.Setting the Image Attribute You can set the image attribute of camera through the webpage. The menu of image attribute can be seen under Setup > Video & Audio > Video-in > Attribute Setting. -
Page 11: Connections
NVC/IPE Series Installation Guide IPE5510 Installation Guide 5. CONNECTIONS 5.1.Connectors ④ ① ② ③ ⑤ ⑥ AUDIO RS-485 Vout AUDIO RS-485 Vout ① Audio Input/Output Connection Connect to the audio input device such as a mike and the audio output device such as the amplifier speaker. - Page 12 NVC/IPE Series Installation Guide IPE5510 Installation Guide Do not connect the speaker without amplifier. Caution ② Sensor (DI) connection The camera provides 1 channel D/I. It can be connected to either a voltage type sensor or a relay type sensor as the following figures. It can be selected by software. Input voltage range: 0VDC minimum to 5VDC maximum, Max 50mA Input voltage threshold: 4.5V Do not exceed the maximum input voltage or relay rate.
- Page 13 NVC/IPE Series Installation Guide IPE5510 Installation Guide Internal Device Relay Type ④ Analog video out Connect with BNC coaxial cable. ⑤ RS-485 Communication For PTZ control, connect this line to keyboard. ⑥ Power Connection Please, check the voltage and current capacity of rated power carefully. Rated Power Input Voltage Range Current Consumption...
-
Page 14: Configuration
NVC/IPE Series Installation Guide IPE5510 Installation Guide 6. CONFIGURATION 6.1.Set up network environment The default IP address of your IP device is 192.168.XXX.XXX. You can find the available IP address from the MAC address of your device. Please make sure the device and your PC are on the same network segment before running the installation. - Page 15 NVC/IPE Series Installation Guide IPE5510 Installation Guide To use the IPAdminTool and view the live video on a web page: 1. Start IPAdminTool. Names and info of currently activated devices appear as a list. 2. Right-click on the desired device and select Web view. 3.
-
Page 16: View Video Using Ip Address
NVC/IPE Series Installation Guide IPE5510 Installation Guide 6.2.2. View video using IP address View the live video on a web page using your IP device and its IP address. To have the correct IP address ready and use it on a web page: 1. -
Page 17: Appendix (A): Specifications
NVC/IPE Series Installation Guide IPE5510 Installation Guide APPENDIX (A): SPECIFICATIONS Summary Camera Module Image Sensor Sony 1/4” Super HAD CCD Effective Pixels 811 x 508 (NTSC) / 795 x 596 (PAL) TV System NTSC / PAL Horizontal Resolution 580 TVL (Color), 680 TVL (B/W) Zoom X12 Optical Zoom, x16 Digital Zoom Focal length... -
Page 18: Electrical Characteristics
NVC/IPE Series Installation Guide IPE5510 Installation Guide Input / Output 1 / 1 Ch Compression PCM, G.711 Function Network 10/100 Base-T DI / DO 1 / 1 Ch RS-485 Support TCP/IP, UDP/IP, HTTP, RTSP, RTCP, RTP/UDP, RTP/TCP, Protocol SNTP, mDNS, UPnP, SMTP, SOCK, IGMP, DHCP, FTP, DDNS, SSL v2/v3, IEEE 802.1X, SSH, SNMP v2/v3 Micro SD card slot SD memory... -
Page 19: Appendix (B): Dimensions
NVC/IPE Series Installation Guide IPE5510 Installation Guide APPENDIX (B): DIMENSIONS (Unit: mm) 01A.02... -
Page 20: Appendix (C): Hexadecimal-Decimal Conversion Table
NVC/IPE Series Installation Guide IPE5510 Installation Guide APPENDIX (C): HEXADECIMAL-DECIMAL CONVERSION TABLE Refer to the following table when you convert the MAC address of your device to IP address. Hex Dec Hex Dec Hex Dec Hex Dec Hex Dec Hex Dec Hex Dec 94 148 25 37... -
Page 21: Revision History
NVC/IPE Series Installation Guide IPE5510 Installation Guide REVISION HISTORY MAN# DATE(M/D/Y) Comments 01A.01 12/219/2011 Created 01A.02 01/03/2012 Modified operating temperature 01A.02...
