Quiko
è un marchio Borinato F.lli Snc
E-mail: info@quiko.biz Web: www.quiko.biz
Sede legale e stabilimento 1: Via Chiesa, 59 - 36040 San Germano D.B. (VI) - Italia
Tel: +39 0444 868126 Fax: +39 0444 868126
Stabilimento 2: Via Seccalegno, 19 - 36040 Sossano (VI) - Italia
Tel: +39 0444 785513 Fax: +39 0444 782371
TITANO
230/400V SLIDING GATE OPENER
USE AND MAINTENANCE MANUAL
E
N
G
L
I
S
H
Advertisement
Table of Contents
Related Manuals for quiko Titano QK-T4000
Summary of Contents for quiko Titano QK-T4000
- Page 1 ® Quiko è un marchio Borinato F.lli Snc E-mail: info@quiko.biz Web: www.quiko.biz Sede legale e stabilimento 1: Via Chiesa, 59 - 36040 San Germano D.B. (VI) - Italia Tel: +39 0444 868126 Fax: +39 0444 868126 Stabilimento 2: Via Seccalegno, 19 - 36040 Sossano (VI) - Italia...
-
Page 2: Technical Features
TECHNICAL FEATURES QK-T4000 QK-T6000 230/400 Three -phase VOLTAGE SUPPLY (VAC) 1500 1100 POWER ABSORBED 6/3,5 4,5/2,6 CURRENT ABSORBED -30/+70 OPERATING TEMPERATURE C° GATE SPEED m/min PROTECTION LEVEL WORKING CYCLE GEARMOTOR WEIGHT 1400 SPEED 1/30 REDUCTION RATIO 6000 4000 MAX. GATE WEIGHT PRE-INSTALLATION CONTROL Before installing the automation, you must check that: The wheels of the gate are attached to make the gate stable and must be in good condition;... -
Page 3: Materials For Installation
MATERIALS FOR INSTALLATION Fig. 1 1. Gear-motor 2. Counterplate 3. M6 iron rack 30x30mm 4. Limit switch cammes POSITIONING OF THE COUNTERPLATE Fig. 2... -
Page 4: Installation Of The Gearmotor
INSTALLATION OF THE GEARMOTOR Fig. 3 Open the removable cover of the gearmotor. Loosen the four screws and remove the case. Remove the nuts used to fasten the anchoring brackets. Position the gearmotor onto the counterplate. The gearmotor has to be adjusted: - Horizontally: along the gearmotor base slot (approx. - Page 5 Fig. 5 POSITIONING THE LIMIT SWITCH CAMMES Fig. 6 Open the gate manually and fasten the limit switch cammes (2) (3) onto the rack.
-
Page 6: Adjusting The Clutch
USE OF MANUAL UNLOCKING Fig.7 RELEASE INSTRUCTIONS In case of fault or power failure, open the removable door and unlock the pinion gear by turning the pinion gear pin counter clockwise by means of the provided tool. This allows moving the gate manually. Attention: perform locking and lock release operations with motor cut off. -
Page 7: Typical Installation
TYPICAL INSTALLATION Fig. 9 MAIN COMPONENTS 1 - GEAR MOTOR 2 - CLOSING LIMIT SWITCH CAMME 3 - OPENING LIMIT SWITCH CAMME 4 - PHOTOCELL 5 - KEY SELECTOR 6 - PHOTOCELL ON POSTS 7 - PHOTOCELL POST 8 - FLASHING LAMP 9 - AERIAL For all electrical connections see the Control Board INSTALLATION MANUAL... -
Page 8: Declaration Of Compliance
DECLARATION OF COMPLIANCE (in accordance with the European Regulation UE89/392 Appendix IIA) Manufacturer: Borinato F.lli Snc Sede legale e stabilimento 1 Stabilimento 2 Via Chiesa, 59 Via Seccalegno, 19 36040 San Germano Dei Berici (VI) 36040 Sossano (VI) Italia Italia hereby declares, under his liability, that the products: QK-T4000 and QK-T6000 gearmotors are in compliance with the essential safety requirements of the regulations:... - Page 9 ® Quiko è un marchio Borinato F.lli Snc E-mail: info@quiko.biz Web: www.quiko.biz Sede legale e stabilimento 1 Via Chiesa, 59 - 36040 San Germano D.B. (VI) - Italia Tel: +39 0444 868126 Fax: +39 0444 868126 Stabilimento 2 Via Seccalegno, 19 - 36040 Sossano (VI) - Italia...
