Specifications And Features - Lectrosonics M187 Operating Instructions And Troubleshooting Manual

Operating frequencies:
RF Power output:
Deviation:
Spurious radiation:
Equivalent input noise:
Input level:
Input impedance:
Input compressor:
Gain control range:
Modulation indicators:
Controls:
Audio Input Jack:
Antenna:
Battery:
Weight:
Dimensions:
Emission Designator:
12

SPECIFICATIONS AND FEATURES

Specifications subject to change without notice.
150 to 216 MHz
50 mW
±15kHz (max)
55 dB below carrier
-126 dBV
Nominal 2 mV to 300 mV (before compression)
30 Volt max. input level (including limiter)
Selectable for 500, 1K, 10K Ohm
Soft compressor, 35dB range
43 dB; semi-log rotary control
Dual LEDs indicate modulation level and onset of limiting
3 position "OFF-MUTE-ON" for noiseless operation
Front panel knob adjusts audio gain
Switchcraft 5 pin locking (TA5F)
Dipole radiator formed by mic cord shield and
transmitter housing
Precision compartment auto-adjusts to accept any known
alkaline 9 Volt battery (We've tried 107 of them!)
5.3 ozs. including battery
3.1 x 2.4 x .75 inches
54KOF3E
