1. OVERVIEW

1.1 Features

Easy & Complete CCTV Solution
‧ Controls your speed dome cameras and auto zoom cameras by DVR with a video cable connected only
DCC (DVR Camera Communication) Technology
‧ Allows easy installation without having to connect the RS-485 cable and to change the current decoration.
‧ Supports excellent functions of adjusting for zoom-in and zoom-out via DVR directly.
H.264 Video Compression Technology
‧ At the local site, the file size is minimized and the record time is lengthened
‧ At the remote site, with the features of small file size and low bit rate, it will be more adaptive to different kinds of
network environment compared with conventional codec designs
Graphical & Multi-language OSD
Remote Independent Operation
‧ Allows single-channel viewing of live displays without changing display settings on the licensed software AP
provided
Free Upgrade to Advanced Functions
‧ Allows you to upgrade DVR functions without any charges
Multiplex Operation
‧ Allows live display, record, playback, backup, and network operations at the same time
Excellent Image Quality and Performance
‧ The CIF image quality is excellent for clear and detailed image
Intelligent Motion Trigger Recording
‧ Activates event recording automatically when alarm is triggered, and sends alerts with images to the designated
e-mails / FTP address
‧ Customizable security settings are achieved with the advanced motion detection, the scheduled motion detection
recording (with 4 individually adjustable parameters), and the quick search function
‧ Supports pre-alarm recording (8MB)
Backup Devices
‧ Supports USB 2.0 flash drive, DVD writer (optional), and network
Remote Surveillance
‧ Supports remote surveillance up to 20 users simultaneously with the licensed software "Video Viewer", Internet
Explorer / Mozilla Firefox web browser, and QuickTime player.
Covert Recording
‧ Blank screen replaces live displays to achieve covert recording
A/V Support
‧ For 16CH & 8CH: Supports 4 audio-in, 2 audio-out to record sounds
For 4CH: Supports 4 audio-in, 1 audio-out to record sounds
‧ Supports VGA output to monitor (VGA interface built-in / output resolution up to 1600 x 1200)
General
‧ Supports SATA HDDs
‧ Supports IR remote controller and keyboard controller
‧ System auto recovery after power failure
‧ Supports PTZ camera operations through RS-485, and PTZ Hot Point function
‧ Supports daylight saving function
‧ Supports manual / timer / motion / alarm / network recording
‧ Supports TCP/IP, PPPoE, DHCP and DDNS network connection.
1
OVERVIEW
