12) AUDIO (SLOW + ZOOM)
Press "SLOW" + "ZOOM" simultaneously to select the audio channel you want for listening to the live audio (in the
live mode) or playback audio (in the playback mode).
Live audio of the 1st audio channel
Live audio of the 2nd audio channel
Live audio of the 3rd audio channel
Live audio of the 4th audio channel
The audio channel is not selected.
13) P.T.Z. ( + SEQ)
Press + SEQ at the same time to enter / exit the PTZ control mode.
For PTZ camera operation, please refer t its user manual.
14) LIST (Event List Search)
Press "LIST" to quickly search the recorded files by four event lists: RECORD LIST / MOTION LIST / ALARM LIST
/ SYSTEM or TIMER LIST, or select FULL LIST to show all the event logs.
To quickly search the time you want, select "QUICK SEARCH". Select the log you want, and press "ENTER" to
play the selected file.
16CH / 8CH Model
LIST
RECORD LIST
MOTION LIST
ALARM LIST
SYSTEM LIST
FULL LIST
QUICK SEARCH
15) SNAP
Press "SNAP" to take a snapshot.
Note: Before taking a snapshot, insert a compatible USB flash drive into the DVR USB port for snapshot
saving. For the compatible USB flash drive list, please refer to "APPENDIX 2 COMPATIBLE USB
FLASH DRIVE BRAND" at page 55.
16) EJECT
(Selected Models Only)
Press "EJECT" to open / close the DVD Writer.
17) USB
Supports firmware / OSD upgrade and file backup.
Playback audio of the 1st audio channel
Playback audio of the 2nd audio channel
Playback audio of the 3rd audio channel
Playback audio of the 4th audio channel
4CH Model
LIST
RECORD LIST
MOTION LIST
ALARM LIST
TIMER LIST
FULL LIST
QUICK SEARCH
5
FRONT AND REAR PANELS
