Smart Seat

pre-installation check list

1 Check that all of the required components
are available. You should have 7 boxes.
These are colour coded so that identification
of any handed components is simple. The
table below shows the colour of the boxes
that you require.
cOmpONENt
Smart Seat base
Smart Seat back
power pack
Fitting kit
Smart Seat Upholstery
Bottom track Section
top track Section
e.g. a left hand lift comprises 1 purple and
6 black boxes; a right hand lift comprises
1 green and 6 black boxes.

2 Installation tools required

• Loading toggle
• Shorting links
• 10mm spanner
• 10mm socket
• Narrow nosed pliers
• 13mm socket
• 17mm socket
• Side cutters
• 8mm spanner
• 13mm spanner
• 17mm spanner
• No. 2 Pozi-drive
Note: The installation engineer must check
with Minivator for the latest installation manual
issue number.
Issue No of this manual is 2011-1
ORIGINAl lANGUAGE ENGlISH
left hand Right hand
pURplE GREEN
BlAcK
• 2.5mm Allen key
• 3mm Allen key
• 4mm Allen key
• 5mm Allen key
• 6mm Allen key
(ball ended)
• 8mm Allen key
• Spirit level
• Handlamp
• Hacksaw
• Tin snips
