3 Pull the anti-tamper seal tight and trim off any
excess to leave the lever hanging securely.
Note: The user must be informed that the
lever is for emergency use only.
To use, the lever should be twisted to break the
anti-tamper seal. The lever can then be inserted
into the swivel lever socket. It must be held in
place to operate the swivel mechanism.
Figure 45
Figure 46
Figure 47
Figure 48
Figure 49
MINIVATOR SIMPLICITY + INSTALLATION MANUAL 17
Fitting the seat back
