Feet positioning

Figure 15
Figure 16
8 MINIVATOR SIMPLICITY + INSTALLATION MANUAL
Feet positioning
Items required:
• None
1 Slide the track to the side of the stairs that
it will be finally located to position the feet.
The feet should be positioned so that they
are touching the stringer (Figure 15).
Note: If the stringer does not extend to the
tread, i.e. it overhangs the staircase, use a
plumb line to mark a position on the stairs.
The feet should all be positioned in this way.
Second foot
Figure 17
tools required:
• 13mm Spanner
• 13mm Socket
Third/
last foot
Splice
