Fitting The Seat Upholstery - Handicare Simplicity+ Installation Manual

Fitting the seat upholstery

Items required:
• Seat upholstery
1 Clip in the seat back, starting with the top
two clips (Figure 52) and then screw in the
seat belt cover mouldings (Figure 53).
2 Fit the main seat cushion.
3 Fit the seat flap cushion.
4 Fit the arm upholstery. Starting at the front,
press the upholstery into the arm recess.
(Figure 54).
Figure 52
tools required:
• Screw driver
Fitting the seat upholstery
Figure 53
Figure 54
MINIVATOR SIMPLICITY + INSTALLATION MANUAL 19
