7. INCLUDED ACCESSORIES

- 2 Rack adapters
- 2 xlr Neutrik cable mt. 0,5
- 1 Lan cable, 8 poles cat5
- 1 adjustment pen screwdriver
- 1 software and utilities CD
- 1 User's manual

9. REQUIRED VOLTAGE

KA 10 operates safely and without audio discontinuity if the AC voltage stays within either of two operating
windows: 95-125 (voltage selector on 115 V) or 195-250 V (voltage selector on 230 V), at 50 or 60 Hz.
The device is default set to be connected to 230 V AC Power. To use the device on a 115 V AC Power you
need, before connecting it, to move
the correct use voltage by the red switch. Be sure that both voltage set on the selector and AC Power have the
same value . Always close the voltage selector's cover before connecting the device to AC Power. Change
the label that points out the correct voltage in use.
CAUTION
!
Connecting a 115V system on a 230V AC Power causes heavy
damages to the device and serious risk for users .

8. WIRING

CH1 OUT
CH2 - 2-
CH1 in
CH1
hot
2
3
CH1
cold
the voltage selector's cover
8
Speakon connector
CH2 OUT
CH2 +
2+
1- CH1 - 2-
1+
CH1 +
XLR connector
CH1 out CH2 in
CH1 CH1 CH1 CH2 CH2
hot hot
grd grd grd
1 1 2 2 1
3 3
CH1 CH2
cold cold
115-230
, just loosening the two screws, and to choose
Speakon connector
2+
1- CH2 -
1+
CH2 +
XLR connector
CH2 out
CH2 CH2
hot
grd
1 2
3
CH2
cold
!
