15. INCLUTED RACK ADAPTERS
S1
STEP 1
STEP 2
STEP 3
SINGLE RACK
DOUBLE RACK
spacers
S2
S1
S2
16
Fix by the supplied screws the two
rack adapters as shown in the
drawing.
Unscrew the 4 anchor points of the
front panels and remove it.
Remove the smaller steel spacer (S2)
from DEVICE A and traslate S1 on
DEVICE B like in the draw beside.
Then refit the front panels fixing all the
4 screws on DEVICE B and just the
two ones through S1 on the DEVICE A
Plug the two devices together
by the last two screws and fix
the rack adapters.
