Service information

MIC 1,MIC 2 (3 pin XLR female：HR16PRQ-3SE(71))
PUSH
2
3
RET CONT(6 pin female：HR10A-7R-6SB(74))
Mating connector：HR10A-7P-6P
6
1
5
2
4
3
AC230 V OUT (5 pin female：RM12BRB-5S)
Mating connector：RM12BPE-5PH
5
4
3
Pin
Signal
1
MIC GND
2
MIC(H)
1
3
MIC(C)
Pin
Signal
1
INCOM 1 TALK ON/OFF
2
INCOM 2 TALK ON/OFF
3
GND
4
NC
5
RET CH1 CTL
6
RET CH2 CTL
1
Pin
Signal
1
AC 230V
2
AC 0V
2
3
GND
4
TALLY CTL(*)
5
AC CTL
(*)
open collector
INTERCOM (5 pin XLR female：HA16PRH-5S)
PUSH
5
4
3
SCRIPT (5 Pin female：HR10A-7R-5SB(73))
Mating connector：HR10A-7P-5P
1
5
4
3
CAUTION:
!
Do not connect the FS-F5 cable while the
Camera system is power on.
・ ・ ・ ・ AC230V & Tally CTL output connector .
・ ・ ・ ・ FS-F5 or other option is connected.
・ ・ ・ ・ Between AC CTL of 5PIN and GND of
3PIN is connected for safety when
AC230V output is used.
58
Pin
Signal
1
MIC IN(C)
1
2
MIC IN(H)
3
RECEIVE(C)
2
4
RECIEVE1(H)
5
RECIEVE2(H)
Pin
Signal
1
SCRIPT +12V
2
GND
2
3
NC
4
NC
5
NC
AC230V output connector
