Hitachi SK-HD1000 R2 Operating Instructions Manual

Hd color camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HD COLOR CAMERA
SK-HD1000
R2
OPERATING INSTRUCTIONS
Please read these operating instructions carefully for proper operation
and keep them for future reference.

Advertisement

Table of Contents
loading

Related Manuals for Hitachi SK-HD1000 R2

Summary of Contents for Hitachi SK-HD1000 R2

  • Page 1 HD COLOR CAMERA SK-HD1000 OPERATING INSTRUCTIONS Please read these operating instructions carefully for proper operation and keep them for future reference.
  • Page 2 Note: The model and serial numbers of your product are important for you to keep for your convenience and protection. These numbers appear on the nameplate located on bottom of the product. Please record these numbers in the spaces provided below, and retain this manual for future reference.
  • Page 3 SAFETY INSTRUCTIONS Carefully read all safety messages in this manual and safety Instructions on your equipment. Follow recommended precautions and safe operating practices. SAFETY ALERT SYMBOL This is the “Safety Alert Symbol.” This symbol is used to call your attention to items or operations that could be dangerous to you or other persons using this equipment.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS 1. Read Instructions All the safety and operating instructions should be read before the product is operated. 2. Retain Instructions The safety and operating instructions should be retained for future reference. 3. Heed Warnings All warnings on the product and the operating instructions should be adhered to. 4.
  • Page 5 14. Lightning For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet. This will prevent damage to the product due to lightning and power-line surges. 15.
  • Page 6 WICHTIGE SICHERHEITSANWEISUNGEN 1. Alle Anweisungen lesen. Vor Betrieb des Erzeugnisses sollten alle Sicherheits-und Bedienungsanleitungen gelesen werden. 2. Die Anweisungen aufbewahren. Die Sicherheits-und Bedienungsanleitungen sollten fünftigen Bezug aufbewahrt werden. 3. Warnungen beachten. Die Warnungen auf dem Erzeugnis und in den Bedienungsanleitungen solten beachtet werden. 4.
  • Page 7 Blitzschlag Für zusätzlichen Schutz des Erzeugnisses während eines Gewitters oder bei Nichtverwendung für lange Zeit den Stecker aus der Steckdose ziehen. Dies verhütet Beschädigung durch Blitzschlag und Netzspannungsstöße. 15. Überlastung Wandsteckdosen, Verlängerungskabel und eingebaute Bequemlickkeitssteckdosen nicht überlasten, da dies Feuer oder elektrischen Schlag verursachen kann. 16.
  • Page 8 MISES EN GARDE IMPORTANTES 1. Lire les instructions Lire toutes les instructions de sécurité et de fonctionnement avant de faire fonctionner l’appareil. 2. Conserver ces instructions Conserver les instructions de sécurité et de fonctionnement á des fins de référence ultérieure. 3.
  • Page 9 14. Foudre Pour renforcer la protection de l’appareil pendant un orage, ou si l’on s’en éloigne ou qu’on reste longtemps sans l’utiliser, le débrancher de la source d’alimentation. Ceci permettra d’éviter tout dommage de l’appareil dú á la foudre et aux surtensions de ligne. 15.
  • Page 10 (4) Compensation for loss of business, loss or damage to software, database and other contingent losses are beyond the scope of this Warranty. (5) Hitachi Kokusai Electric Inc. is not liable for the losses caused when the equipment is used in a system, use for business trades, production process, medical fields, crime prevention applications, etc.

  • Page 11: Table Of Contents

    Contents Outline and features ............................1 Warnings and cautions when using ........................3 Facility names and functions ..........................5 Lens installation ..............................12 Lens flange back adjustment ..........................13 White shading adjustment ..........................14 Tripod mounting ..............................17 5-inch viewfinder attachment ..........................18 Viewfinder adjustment ............................

  • Page 13: Outline And Features

    Outline and features The SK-HD1000 is a high-performance portable Setup card HDTV Studio and EFP camera. A small plug-in setup card (SD card) stores the With its new 2.3 million pixels native 1080i 3-CCD, user setup and Scene File information. the SK-HD1000 provides outstanding performance.
  • Page 14 Outline and features Automatic White Shading Studio system configurations The SK-HD1000 can be constructed a fiber cable Automatic shading corrects white vertical system and triax cable system. shading at the push of a button.  CU-HD500/CU-HD1000, CA-HF1000 This function provides separate memory of For optical fiber system.

  • Page 15: Warnings And Cautions When Using

    In event of difficulty Extremely hot or cold locations (exceeding -10 Disconnect from power and contact the nearest to 45°C), such as in enclosed vehicles. Hitachi Kokusai Electric service agency. Subject to strong vibration. Humid or dusty locations. Salt spray or corrosive gases.
  • Page 16 Warnings and cautions when using Optical Fiber Camera Cable & Connector Handling This camera is using the optical fiber cable & connector which is required special technique for handling. 1. Cable Connector & Receptacle (1) FCF (Fiber Cable Female) (2) FCM (Fiber Cable Male) (3) FCFR (Female Receptacle) (4)FCMR (Male Receptacle) 2.

  • Page 17: Facility Names And Functions

    Facility names and functions A Accessory shoe Viewfinder attachment A small spotlight can be attached without the light striking lens, viewfinder Shoulder belt hook microphone. Attachment for separately sold shoulder belt. Viewfinder front to rear lock screw CALL button Secures the front to rear position adjustment Press to call the CCU.
  • Page 18 Facility names and functions B Shoulder belt hook CCU connector Attachment for separately sold shoulder belt. Connector for fiber optic cable. Viewfinder connector AC230V OUT connector Connector for viewfinder cable. AC230V can be supplied to external unit. For detail, Refer to page 75. MON/RET output connector (BNC) HD-SDI signal output for monitor (75).
  • Page 19 Facility names and functions C MIC connector (XLR, 3pin) INCOM MIC on/off button Connector for microphone. Intercom microphone can be used while phantom power (DC+48V) pressing this button when switch E8 on camera supplied to front microphone from camera adaptor shown page 10 is set to “FRONT”. menu.
  • Page 20 Facility names and functions D POWER LED WHITE BAL switch Off: Camera power is off. PRE: The white balance is set to the memory On(Green): Camera power is on. value for 3200K. A or B: When the AUTO W/B BAL switch C4 is set to AWB, the white balance is adjusted FILTER button automatically.
  • Page 21 Facility names and functions E CS switch RET1/2 transmission signal switch CS switch can be assigned as a shortcut by This switch is used to select a return video CUSTOM SW menu. signal among four external video sources input to CCU. These four signals can be assigned by CCU menu.
  • Page 22 Facility names and functions E INCOM PGM 1/2 level INCOM 1/2 PD/ENG select switch Controls the receiving sound volume of the This switch is used to select the PD or ENG program. input of the external intercom system to be connected to the CCU rear side.
  • Page 23 Facility names and functions F DC IN connector (XLR 4 pin) MIC LINE/OFF/+48V switch This connector should be used when the LINE: For a line level signal source. camera is used in self-control mode. OFF: Not to supply a power. +48V: To supply a power of +48VDC MIC SEL switch HD-SDI 1 output connector (BNC)

  • Page 24: Lens Installation

    Lens installation Lens installation Install according to the following procedure. 1. Raise the lens lever and remove the mount 3. Lower the lens lever to secure the lens. cap. 2. Align the lens center mark with the indent at 4. Engage the cable with the cable clamp and the upper part of the lens mount and install connect it to the lens connector.

  • Page 25: Lens Flange Back Adjustment

    Lens flange back adjustment Lens flange back adjustment When operating a zoom lens, if the focus is not precisely aligned at both the telephoto and wide angle extremes of the lens, the flange back (distance from the lens mounting plane to the focal plane) is adjusted.

  • Page 26: White Shading Adjustment

    White shading adjustment White shading adjustment White shading adjustment is recommended after replacing the lens. The adjustment relates to the camera vertical coloration. If the lens includes an extender, the shading can be optimized for both extender on and off modes. (Vertical coloration refers to an effect whereby the image of an overall white sheet of paper tends toward green at the top and magenta at the bottom, or vice versa.) Adjustment...
  • Page 27 White shading adjustment 5. Open the WHITE SHADING sub menu from MAINTENANCE menu. 6. Shift cursor to WHT SHADING : PUSH > 1 SEC. 7. Press the knob direction button for about 1 second to adjust white shading. The viewfinder top and bottom cursors flash to indicate automatic white shading adjustment in progress.
  • Page 28 Camera adapter installation Camera adapter installation Install the camera adapter (option). Installation 1. Align the adapter guide pin with the camera guide shoe. Press to insert the adapter. 2. Tighten screws 1, 2 and 3 to secure the camera adapter. CAUTION Tighten screws fully to prevent wobble between adapter and camera.

  • Page 29: Tripod Mounting

    Tripod mounting Tripod mounting Use the accessory TA-Z3 tripod adapter to mount the camera on a tripod. 1. Securely attach the tripod adapter to the tripod. Shift the adapter screw position to obtain the best balance. The adapter can accept two types of screws. Use the screw hole that matches the tripod.

  • Page 30: 5-Inch Viewfinder Attachment

    5-inch viewfinder attachment 5-inch viewfinder attachment Use the separately sold AT-500 viewfinder adapter when installing the VF-HD500 5-inch viewfinder. Installation 1. Raise the lock lever of the AT-500 horizontally and remove the viewfinder mounting screw from the AT-500. Insert this screw in the bottom of the viewfinder. Insert the screw together with the viewfinder into the AT-500 and set the lock lever forward, then turn the lever clockwise to secure it.

  • Page 31: Viewfinder Adjustment

    Viewfinder adjustment Viewfinder installation 1. Turn the lock lever as indicated by the arrow to secure the viewfinder guide. 2. Turn the viewfinder lock lever fully counter-clockwise. 3. Align the 2 viewfinder guide pins with the camera guide holes and insert the viewfinder. 4.
  • Page 32 Viewfinder adjustment Visibility adjustment Screen adjustments The focus can be fine adjusted to individual Adjust the viewfinder screen with following controls. preference. Brightness: BRIGHT control 1. Adjust the camera focus. Contrast: CONTR control 2. Turn the visibility ring to adjust the focus Peaking: PEAKING control of the viewfinder image.

  • Page 33: Viewfinder Indications

    Viewfinder indications LED display in the View Finder (2 inch) R TALLY: Lights on during Red tally is on. G TALLY: Lights on during Green tally is on. G Tally R Tally EXT: Lights on during lens extender is used. MODE: Lights on during Gain is set to M or H, or shutter is on.

  • Page 34: Filter Selection

    Filter selection Filter setting In order to obtaining correct white balance, the sufficient optical filter selection is required accordance with the scene lighting source. The correct optical filter according to the scene light source needs to be selected in order to obtain correct white balance. Operation method Filter Mode...

  • Page 35: White And Black Balance Adjustment

    White and black balance adjustment White balance adjustment White balance will be adjusted to the best effort in the sequence of AWB (auto white balance), ABB (auto black balance), and again AWB. Readjustment is normally not required even at power off/on. Be sure to adjust the white balance after changes in the lighting conditions.
  • Page 36 White and black balance adjustment Auto white balance error messages When auto white balance adjustment fails, the following error messages will be displayed on the viewfinder screen for about 6 seconds. Message Cause Correction The OUTPUT/AUTO Set the OUTPUT/AUTO KNEE switch to AUTO WHITE:NG KNEE switch is set to CAM.
  • Page 37 White and black balance adjustment Black balance adjustment Black balance requires adjustment in the following situations. Equipment being used for the first time Equipment idle for an extended period Large change of ambient temperature Gamma setting changed 1. Set the AUTO W/B BAL switch to ABB for automatic black balance adjustment. AUTO W / B BAL switch 2.
  • Page 38 White and black balance adjustment Auto black balance error messages When auto black balance adjustment fails, the following error messages appear on the viewfinder screen for about 6 seconds. Message Cause Correction The OUTPUT/AUTO KNEE switch Set the OUTPUT/AUTO KNEE switch to AUTO BLACK:NG is set to BAR.
  • Page 39 White and black balance adjustment Gray scale auto set up BLAK, GAIN, FLARE and GAMMA parameter can be adjusted automatically using with the gray scale chart.(Refer to function menu 4. MAINTENANCE) Gray scale chart with gate marker in the View Finder. Gate marker Gray scale auto set up can be accessed from Function menu or the Remote control unit and following message is displayed in the view finder during auto set up working...

  • Page 40: Electronic Shutter Setting

    Electronic shutter setting Shutter modes The selectable electronic shutter modes and speeds are as follows. Mode Shutter speeds Applications PRESET 1/100(59.94i), 1/60(50i), Set to make fast-moving objects clear. 1/250, 1/500,1/1000,1/2000 second LOCK SCAN 1/59.94 to 1/1983 second (59.94i) Set to reduce horizontal scroll bars of an 1/50.00 to 1/2008 second (50i) image when shooting a computer screen.
  • Page 41 Electronic shutter setting LOCK SCAN mode The lock scan mode avoids flicker in scenes showing a computer monitor screen. 1. Set the Shutter switch to SEL to produce the lock scan mode. 2. Push MENU BUTTON, top menu screen is displayed. The cursor can be changed by rotating MENU SEL KNOB.

  • Page 42: Setup Card

    Setup card Setup card A separately sold an SD memory card can be used for storing the setting menu data. The data can then be used to quickly set the proper setup. Handling The SD memory card can be inserted and removed regardless of power on or off. However, avoid removing while loading, saving or formatting is in progress, since operating error or SD memory card breakage can occur.
  • Page 43 Setup card Setup card operation The SD memory card setting data is loaded and saved, and the setup card is formatted according to the SETUP CARD menu. If the insertion of the setup card is followed by indication of SETUP CARD menu, the setup card is checked.
  • Page 44 Setup card If the setting data for this camera exists in the setup card, the date and time when the setting data was saved appear in the DATE and TIME fields. "－" appears where no corresponding file exists. If the checking revealed an error, the indication below appears, inhibiting all operations other than formatting.
  • Page 45 Setup card Data load, save or clear 1. After Display the SETUP CARD menu, select a file to load, save or clear. Viewfinder displays in control head mode. 　ＳＥＴＵＰ　ＣＡＲＤ　ＭＥＮＵ ■ＳＥＬＥＣＴ　ＦＩＬＥ：＜ 　 　 　ＦＩＬＥ　　　　ＤＡＴＥ　　　　　ＴＩＭＥ 　ＦＩＬＥ　ＮＡＭＥ: ■［ＶＦ］１　　　－－／－－／－－　－－：－－ 　［ＶＦ］１　　　－－／－－／－－　－－：－－ 　［ＶＦ］２　　　－－／－－／－－　－－：－－ 　［ＶＦ］３　　　－－／－－／－－　－－：－－ 　［ＶＦ］４　　　－－／－－／－－　－－：－－ 　［ＶＦ］５　　　－－／－－／－－　－－：－－ 　ＬＯＡＤ　　ＦＩＬＥ：ＰＵＳＨ　＞　１ＳＥＣ...
  • Page 46 Setup card 2. Press > button 1 SEC and load, save or clear data from selected file. 　ＳＥＬＥＣＴ　ＦＩＬＥ：＜ 　ＳＥＬＥＣＴ　ＦＩＬＥ：＜ 　 　 　ＦＩＬＥ　ＮＡＭＥ: 　ＦＩＬＥ　ＮＡＭＥ: 　［ＶＦ］１　　　＊＊／＊＊／＊＊　＊＊：＊＊ 　［ＶＦ］１　　　＊＊／＊＊／＊＊　＊＊：＊＊ 　ＬＯＡＤＩＮＧ．．． ■ＬＯＡＤ　　ＦＩＬＥ：ＰＵＳＨ　＞　１ＳＥＣ 　ＳＡＶＥ　　ＦＩＬＥ：ＰＵＳＨ　＞　１ＳＥＣ ■ＬＯＡＤ　　ＦＩＬＥ：ＰＵＳＨ　＞　１ＳＥＣ 　ＣＬＥＡＲ　ＦＩＬＥ：ＰＵＳＨ　＞　１ＳＥＣ 　ＳＡＶＥ　　ＦＩＬＥ：ＰＵＳＨ　＞　１ＳＥＣ 　ＣＬＥＡＲ　ＦＩＬＥ：ＰＵＳＨ　＞　１ＳＥＣ 　ＳＥＬＥＣＴ　ＦＩＬＥ：＜ 　ＳＥＬＥＣＴ　ＦＩＬＥ：＜ 　 　 　ＦＩＬＥ　ＮＡＭＥ: 　ＦＩＬＥ　ＮＡＭＥ: 　［ＶＦ］１　　　－－／－－／－－　－－：－－ 　［ＶＦ］１　　　－－／－－／－－　－－：－－ 　ＳＡＶＩＮＧ．．．...
  • Page 47 Setup card Status pass & display for each camera operation 1. Camera system menu operation (display in the viewfinder) ■ＳＥＴＵＰ　ＣＡＲＤ　ＭＥＮＵ 　 　　　　　 ＮＯＴ　ＦＯＲＭＡＴＴＥＤ No format ＦＯＲＭＡＴ：ＰＵＳＨ　＞　１ＳＥＣ Format OK ■ＳＥＴＵＰ　ＣＡＲＤ　ＭＥＮＵ ■ＳＥＬＥＣＴ　ＦＩＬＥ：＜ 　 　 　 　ＦＩＬＥ　　　　ＤＡＴＥ　　　　　ＴＩＭＥ 　ＦＩＬＥ　ＮＡＭＥ: 　［ＶＦ］１　　　－－／－－／－－　－－：－－ 　［ＶＦ］１　　　－－／－－／－－　－－：－－ CARD OK ＆ 　［ＶＦ］２　　　－－／－－／－－　－－：－－...
  • Page 48 Remove card 　　　　　　　ＮＯ　ＣＡＲＤ In event of error If setting data save or load, or setup card format results are erroneous, the setup card may be faulty. Change the setup card. If the error recurs, consult a Hitachi technical service representative.

  • Page 49: Function Menu

    Function menu There are three function menu setting methods in the camera system chain which are, 1) Set Up Control Unit SU- 1000 MENU button on LCD. 2) Remote Control Unit RU-1500, and RU-1000 function switches 3) The CAMERA HEAD switches. In this section, only describe for the camera head switches function menu.
  • Page 50 Function menu Main Menu:（Typical main menu） There are two kind cursor ■ＶＦ　ＭＥＮＵ The cursor is moved up & down by the rotate knob and ＶＦ　ＯＵＴ　ＳＥＬ　：ＣＯＬＯＲ 　ＶＦ　ＤＥＴＡＩＬ　　：＞ the cursor is changed parameter by the MENU SEL knob. 　ＶＦ　ＭＡＲＫＥＲ　　：＞ 　ＳＩＤＥ　ＰＡＮＥＬ　：＞ The marker indicate sub menu hidden in behind.
  • Page 51 Function menu The camera head is connected with a CCU and an RU as an operational camera system, the camera head View finder display TOP MENU as follows. This is mainly used for camera man’s operation. VF MENU 　ＴＯＰ　ＭＥＮＵ 　 Open this menu by pushing the MENU SW in side of the ■ＶＦ　　　　　　　　　：＞...
  • Page 52 Function menu CAM MODE (Camera man can operate this function at camera head.) 1. VF menu structure which are displayed in the viewfinder.) MAIN MENU SUB MENU ■ＶＦ　ＭＥＮＵ ■ＶＦ　ＤＥＴＡＩＬ　　：＜ ■ＭＡＲＫＥＲ１　ＳＥＬ：＜ＵＳＥＲ　１ 　 　 ＶＦ　ＯＵＴ　ＳＥＬ　：ＣＯＬＯＲ 　ＶＦ　ＤＥＴＡＩＬ　　：ＯＮ 　ＣＥＮＴＥＲ　ＭＡＲＫ：ＯＮ 　ＶＦ　ＤＥＴＡＩＬ　　：＞ 　ＤＴＬ　ＬＥＶＥＬ　　： 　０ 　ＳＡＦＥＴＹ　ＭＡＲＫ：ＯＮ 　ＶＦ　ＭＡＲＫＥＲ　　：＞ 　ＣＲＩＳＰ　　　　　　：　　　０...
  • Page 53 Function menu 2. COLOR menu structure which are displayed in the Pix monitor or are displayed in the viewfinder with at control head mode. MAIN MENU SUB MENU ■ＣＯＬＯＲ　ＭＥＮＵ　　　　　　ＳＣＥＮＥ　０ ■ＧＡＩＮ　　　　　　　：＜　　　ＳＣＥＮＥ　０ 　 　 　ＧＡＩＮ　　　　　　　：＞ 　Ｒ　ＧＡＩＮ　　　　　：　　　０ 　ＢＬＡＣＫ／ＦＬＡＲＥ：＞ 　Ｇ　ＧＡＩＮ　　　　　：　　　０ 　ＧＡＭＭＡ　　　　　　：＞＞ 　Ｂ　ＧＡＩＮ　　　　　：　　　０ 　ＫＮＥＥ／ＣＬＩＰ　　：＞＞ 　ＭＡＳＫＩＮＧ　　　　：＞＞＞ 　...
  • Page 54 Function menu 3. DETAIL menu structure which are displayed in the Pix monitor or are displayed in the viewfinder with at control head mode. MAIN MENU SUB MENU ■ＤＥＴＡＩＬ　ＭＥＮＵ　　　　　ＳＣＥＮＥ　０ ■ＤＥＴＡＩＬ　　　　１：＞　　　ＳＣＥＮＥ　０ ■ＤＥＴＡＩＬ　　　　２：＜　　　ＳＣＥＮＥ　０ 　 　 　 　 　ＬＥＶＥＬ　　　　　　：　　　０ 　Ｄ．ＫＮＥＥ　ＷＨＴ　：　１１７ 　ＤＥＴＡＩＬ　　　　　：＞＞ 　Ｈ　ＧＡＩＮ　　　　　：　－６０ 　Ｄ．ＫＮＥＥ　ＢＬＫ　：　１２０ 　ＳＫＩＮ　ＤＴＬ　　　：＞＞...
  • Page 55 Function menu 4. MAINTENANCE menu structure which are displayed in the Pix monitor or are displayed in the viewfinder with at control head mode. MAIN MENU SUB MENU ■ＲＬＡＣ　　　　　　　：＜ ■ＭＡＩＮＴＥＮＡＮＣＥ　ＭＥＮＵ ■ＡＵＴＯ　ＳＥＴＵＰ　：＜ 　 　 　 　ＡＵＴＯ　ＳＥＴＵＰ　：＞ 　ＣＨ１．Ａ．ＰＨＡＳＥ：ＰＵＳＨ　＞　１ＳＥＣ 　ＲＬＡＣ　　　　　　　：ＯＦＦ 　ＳＴＡＴＵＳ　　　　　：ＥＮＡＢＬＥ 　ＷＨＴ　ＳＨＡＤＩＮＧ：＞ 　ＣＨ２．Ａ．ＰＨＡＳＥ：ＰＵＳＨ　＞　１ＳＥＣ 　ＡＵＴＯ　ＩＲＩＳ　　：＞...
  • Page 56 Function menu 5. FILE menu is displayed in the Pix monitor or are displayed in the viewfinder with at control head mode. MAIN MENU SUB MENU ■ＦＩＬＥ　ＭＥＮＵ ■ＳＣＥＮＥ　ＦＩＬＥ　ＭＥＮＵ 　 　 　ＳＣＥＮＥ　ＦＩＬＥ　：＞ 　ＳＣＥＮＥ　ＦＩＬＥ　：ＳＣＥＮＥ　０ 　ＬＥＮＳ　　ＦＩＬＥ　：＞ 　ＳＴＯＲＥ　ＦＩＬＥ　：ＳＣＥＮＥ　０ 　ＳＴＯＲＥ 　ＡＬＬ　ＩＮＩＴＩＡＬＩＺＥ　： ■ＬＥＮＳ　ＦＩＬＥ　ＭＥＮＵ　 ■ＡＵＴＯ　ＩＲＩＳ　　　：＜ 　ＬＥＮＳ　ＦＩＬＥ　　：ＬＥＮＳ　１ 　ＬＥＮＳ　ＦＩＬＥ　　：ＬＥＮＳ　１ 　ＡＵＴＯ　ＩＲＩＳ　　：＞...
  • Page 57 Function menu 7. EACH MENU ITEM & DESCRIPTION 7. 1 VF MENU (MAIN menu) which are displayed in the viewfinder & description. Item Setting Initial Description ■ＶＦ　ＭＥＮＵ setting ＶＦ　ＯＵＴ　ＳＥＬ　：ＣＯＬＯＲ VF OUT SEL COLOR COLOR 　ＶＦ　ＤＥＴＡＩＬ　　：＞ Y,R,G,B 　ＶＦ　ＭＡＲＫＥＲ　　：＞ VF DETAIL Change screen to VF DETAIL menu. 　ＳＩＤＥ　ＰＡＮＥＬ　：＞...
  • Page 58 Function menu 7.1.2.1 MARKER1 SEL/ MARKER2 SEL menu (VF SUB-MENU) & description. Item Setting Initial Description ■ＭＡＲＫＥＲ１　ＳＥＬ：＜ＵＳＥＲ　１ 　 setting 　ＣＥＮＴＥＲ　ＭＡＲＫ：ＯＮ CENTER MARK ON,OFF Center marker ON and OFF. 　ＳＡＦＥＴＹ　ＭＡＲＫ：ＯＮ SAFETY MARK ON,OFF Safety Maker ON and OFF. 　ＳＩＤＥ　　　４：３　：ＯＦＦ 　　　　　　　１３：９　：ＯＦＦ SIDE ON,OFF Side 4:3 marker ON and OFF 　　　　　　　１４：９　：ＯＦＦ...
  • Page 59 Function menu 7.1.2.4 OTHER SET menu (VF SUB-MENU) & description. Item Setting Initial Description ■ＯＴＨＥＲ　ＳＥＴ　　：＜ＵＳＥＲ　１ 　 setting 　ＣＥＮＴＥＲ　ＭＡＲＫ：ＴＹＰＥ１ CENTER MARK TYPE1/2/3/4 TYPE1 Type setting of center marker. 　ＳＡＦＥＴＹ　ＭＡＲＫ：ＴＹＰＥ１ 　ＳＡＦＥＴＹ　ＡＲＥＡ：９０．０％ SAFTY MARK TYPE1/2/3 TYPE1 Type setting of safety marker. 　ＭＡＲＫＥＲ　ＬＥＶ　：１００ 　 SAFTY AREA 80.0%, 90.0%, 90.0%...
  • Page 60 Function menu 7.1.3 SIDE PANEL menu (VF SUB- MENU) & description. Item Setting Initial Description ■ＳＩＤＥ　ＰＡＮＥＬ　：＜ 　 setting 　ＳＩＤＥ　ＰＡＮＥＬ　：ＯＦＦ SIDE PANEL OFF, 4:3, 13:9, Only when DISP SIZE is 16:9, it 　ＣＯＮＴＲＡＳＴ　　　：１ 14:9, 15:9 is effective. 　ＢＲＩＧＨＴ　　　　　：１ 　 CONTRAST 1 to 5 Set side panel contrast 　...
  • Page 61 Function menu 7.1.6 FOCUS IND menu (VF SUB-MENU) & description. Item Setting Initial Description ■ＦＯＣＵＳ　ＩＮＤ　　：＜ 　 setting 　ＩＮＤＩＣＡＴＯＲ　　：ＯＦＦ INDICATOR ON,OFF Display the focus assist indicator in VF, 　ＭＡＲＫＥＲ　　　　　：ＯＦＦ ON and OFF 　ＰＥＡＫ　ＨＯＬＤ　　：ＯＦＦ MARKER ON,OFF Display the detect area marker for the focus assist in VF, ON and OFF PEAK HOLD ON,OFF...
  • Page 62 Function menu 7.2 COLOR MENU (COLOR MAIN- MENU) which are displayed in the Pix monitor or are displayed in the viewfinder with at control head mode. Item Description ■ＣＯＬＯＲ　ＭＥＮＵ　　　　　　ＳＣＥＮＥ　０ 　 GAIN Change screen to GAIN menu. 　ＧＡＩＮ　　　　　　　：＞ BLACK/FLARE Change screen to BLACK/FLARE menu. 　ＢＬＡＣＫ／ＦＬＡＲＥ：＞...
  • Page 63 Function menu 7.2.3 GAMMA1 (COLOR SUB-MENU) & description. Item Setting Initial Description ■ＧＡＭＭＡ　　　　　１：＞　　　ＳＣＥＮＥ　０ 　 setting 　Ｒ　ＧＡＭＭＡ　　　　：　　　０ R GAMMA -128 to 127 Adjust Red Gamma 　Ｇ　ＧＡＭＭＡ　　　　：　　　０ G GAMMA -128 to 127 Adjust Green Gamma 　Ｂ　ＧＡＭＭＡ　　　　：　　　０ 　ＴＯＴＡＬ　ＧＡＭＭＡ：　　　０ B GAMMA -128 to 127 Adjust Blue Gamma TOTAL GAMMA -128 to 127...
  • Page 64 Function menu 7.2.6 KNEE/CLIP 2 menu (COLOR SUB-MENU) & description. Item Setting Initial Description ■ＫＮＥＥ／ＣＬＩＰ　２：＜　　　ＳＣＥＮＥ　０ setting 　ＫＮＥＥ　ＳＡＴ　　　：　　２４ KNEE SAT -128 to 127 Adjust Knee Saturation. (*) 　ＫＮＥＥ　ＳＡＴ　　　：ＯＦＦ KNEE SAT Knee Saturation function ON And ON,OFF 　ＷＨＩＴＥ　ＣＬＩＰ　：　－１６ 　ＷＨＩＴＥ　ＣＬＩＰ　：ＯＮ WHITE CLIP -128 to 127 Adjust White Clip level WHITE CLIP ON,OFF...
  • Page 65 Function menu 7.2.8 MASKING 2 menu (COLOR SUB-MENU) & description. Item Setting Initial Description ■ＭＡＳＫＩＮＧ　　　２：＜　　　ＳＣＥＮＥ　０ setting 　－ＬＩＮＥＡＲ－ LINEAR R-G -64 to +63 Adjust liner matrix R-G 　Ｒ－Ｇ：　　０　Ｇ－Ｒ：　　０　Ｂ－Ｒ：　　０ parameter offset 　Ｒ－Ｂ：　　０　Ｇ－Ｂ：　　０　Ｂ－Ｇ：　　０ LINEAR R-B -64 to +63 Adjust liner matrix R-B 　ＰＲＥＳＥＴ　ＴＹＰＥ：ＳＴＡＮＤＡＲＤ 　...
  • Page 66 Function menu 7.3 DETAIL MENU (MAIN-MENU) which are displayed in the Pix monitor or are displayed in the viewfinder with at control head mode. Item Description ■ＤＥＴＡＩＬ　ＭＥＮＵ　　　　　ＳＣＥＮＥ　０ 　 DETAIL Change screen to DETAIL menu. 　ＤＥＴＡＩＬ　　　　　：＞＞ SKIN DTL Change screen to SKIN DTL menu. 　ＳＫＩＮ　ＤＴＬ　　　：＞＞...
  • Page 67 Function menu 7.3.3 SKIN DTL 1 menu (DETAIL SUB-MENU) & description. Item Setting Initial Description ■ＳＫＩＮ　ＤＴＬ　　１：＞　　　ＳＣＥＮＥ　０ 　 setting 　ＣＨ　ＳＥＬＥＣＴ　　：１ｃｈ CH SELECT 1ch,2ch CH selection for skin tone detail 　ＣＨ１．Ａ．ＰＨＡＳＥ：ＰＵＳＨ　＞　１ＳＥＣ CH1 A.PHASE Set CH1 skin tone detail phase *1 　Ｓ．ＤＴＬ　ＬＥＶＥＬ：　－９６ 　　　　　　　ＰＨＡＳＥ：　　９７　　Ｙｅ－Ｒ S.DTL LEVEL -128 to +127 Adjust CH1 skin tone detail level...
  • Page 68 Function menu 7.3.5 HIGH CHROMA menu (DETAIL SUB-MENU) & description. Item Setting Initial Description ■ＨＩＧＨ　ＣＨＲＯＭＡ：＜　　　ＳＣＥＮＥ　０ 　 setting 　Ｒ　　　　　　　　　　：　　　０ Adjust detail level in high 　Ｇ　　　　　　　　　　：　　　０ -128 to +127 chrominance Red portion in 　Ｂ　　　　　　　　　　：　　　０ the scene. 　ＨＩＧＨ　ＣＨＲＯＭＡ：ＯＦＦ Adjust detail level in high -128 to +127 chrominance Green portion in the scene.
  • Page 69 Function menu 7.4 MAINTENANCE menu (MAIN MENU) which are displayed in the Pix monitor or are displayed in the viewfinder with at control head mode. Item Description ■ＭＡＩＮＴＥＮＡＮＣＥ　ＭＥＮＵ 　 AUTO SETUP Change screen to AUTO SETUP menu. 　ＡＵＴＯ　ＳＥＴＵＰ　：＞ WHT SHADING Change screen to WHT SHADING menu.
  • Page 70 Function menu 7.4.3 AUTO IRIS menu (MAINTENANCE SUB-MENU) & description. Item Setting Initial Description ■ＡＵＴＯ　ＩＲＩＳ　　：＜ 　 setting 　ＡＵＴＯ　ＩＲＩＳ　　：ＡＵＴＯ AUTO IRIS REMOTE, AUTO Setting of Iris control mode. *1 　ＩＲＩＳ　ＴＲＩＭ　　：　　　０ AUTO 　ＰＥＡＫ／ＡＶＥ　　　：０／１０ IRIS TRIM -128 to +127 Adjust Auto iris output level 　ＩＲＩＳ　ＧＡＴＥ　　：　　　１...
  • Page 71 Function menu 7.4.5 M.GAIN SET menu(MAINTENANCE SUB-MENU) & description. Item Setting Initial Description ■Ｍ．ＧＡＩＮ　ＳＥＴ　：＜ 　 setting 　Ｍ．ＧＡＩＮ　ＬＯＷ　：　　０　ｄＢ M.GAIN LOW -3, 0 dB Low gain setting of M.Gain 　Ｍ．ＧＡＩＮ　ＭＩＤ　：　　６　ｄＢ M.GAIN MID 0, 3, 6, 9, 12, MID gain setting of M.Gain 　Ｍ．ＧＡＩＮ　ＨＩＧＨ：　１２　ｄＢ...
  • Page 72 Function menu 7.4.9 CHECK1 menu (MAINTENANCE SUB MENU) & description. Item Setting Initial Description ■ＣＨＥＣＫ　　　　　１：＞ 　 setting 　ＴＥＳＴ　　　　　　　：ＯＦＦ TEST OFF,ON TEST signal ON and OFF 　ＧＡＭＭＡ　　　　　　：ＯＮ GAMMA OFF,ON GAMMA function ON and OFF 　ＤＥＴＡＩＬ　　　　　：ＯＮ 　ＭＡＳＫＩＮＧ　　　　：ＯＮ DETAIL OFF,ON DETAIL function ON and OFF 　ＫＮＥＥ　　　　　　　：ＯＮ...
  • Page 73 Function menu 7.5 FILE menu (FILE MENU) which are displayed in the Pix monitor or are displayed in the viewfinder with at control head mode. Item Setting Initial Description ■ＦＩＬＥ　ＭＥＮＵ 　 setting 　ＳＣＥＮＥ　ＦＩＬＥ　：＞ SCENE FILE Change screen to SCENE FILE menu. －...
  • Page 74 Function menu File structure There are ADJUST, COMMON, SCENE and LENS four major data files in the camera head memory. ADJUST Factory setting data file FILE Menu setting data file COMMON (VF, CUSTOM SW, MAINTENANCE, expect the shutter function) FILE SCENE SCENE SCENE...
  • Page 75 Function menu 7.6 CUSTOM SW MENU (MAIN menu) which are displayed in the viewfinder & description. Item Setting Initial Description ■ＣＵＳＴＯＭ　ＳＷ　ＭＥＮＵ 　 setting 　ＣＳ－１　ＳＷ　　　　：ＺＥＢＲＡ CS-1 SW ZEBRA, ZEBRA Set CS-1 switch 　ＣＡ－ＣＳ　ＳＷ　　　：－－－－－－－ MARKER, 　ＬＥＮＳ　ＶＴＲ　ＳＷ：ＴＡＬＫ VF-DTL, 　ＩＮＣＯＭ　ＳＷ　　　：ＩＮＣＯＭ１ QUICK FOCUS(*), CA-CS SW ------, ------ Set CS switch in the...
  • Page 76 Function menu Type of Auto setup & control items Following Auto setup functions are available at camera head and also remotely controlled from the RU-1000, or RU-1500. Type of GRAY WHITE SKIN TONE Auto Setup AUTO AUTO SCALE SHADING DTL PHASE BLACK WHITE AUTO...
  • Page 77 Function menu Versatility and creativity function for HDTV picture quality Camera Alignment Goal should be: - Accurate reproduction of scene - Matching a previous set up - Developing your own unique “look” or a number of different look, depending on the situation May be required a different look to a newscast or dram series.

  • Page 78: Specifications

    Specifications Camera Head SK-HD1000 / SK-HD1000E 2/3-inch, IT-CCD Total pixels 2,010 (H) × 1,120(V) 2.3 million pixels Effective pixels 1,920 (H) × 1,080 (V) 1080/59.94i (SK-HD1000/CA-HF1000) Native Scan 1080/50i (SK-HD1000E/CA-HF1000E) Prism F1.4 1X motorized filter wheel w/ 4 filter positions Optical Filter (Clear, Cross, 1/16 ND, 1/64 ND) ECC Filter...
  • Page 79 Specifications Fiber Adapter CA-HF1000 1X HFOC femail connector (LEMO/Tajimi Type) CCU connector SMPTE304M-type Fiber adapter I-O 2X BNC HD-SDI OUT 1X BNC PROMPT switch-able GENLOCK (analog Tri-level in or SD VBS OUT) 5-pin Script +12VDC OUT(1.0A max) 29-pin D-SUB for studio-adaptor 5-pin AC230V for Prompter Power / Tally out 2X XLR INCOM (2-Chnl + PGM Mix) 1X XLR DC IN...
  • Page 80 Specifications 2-inchviewfinder Model name VF-402 2-inch BW 16:9 Resolution 650 TV lines Functions BRIGHT, CONTRAST, PEAKING knob VR (front facing) Internal tally Red/Green Tally switch Tally switch OFF, NORMAL, HIGH 5-inch viewfinder Model name VF-HD500 5-inch BW 4:3 CRT Resolution 750 TV lines Function s BRIGHT, CONTRAST, PEAKING knob VR...
  • Page 81 Specifications Dimensions ･SK-HD1000 / CA-HF1000 / CX-HD1000 348( CA-HF1000 ) / 360( CX-HF1000 ) ･VF- 402...
  • Page 82 Specifications ･VF-L90HD ･VF-HD500...
  • Page 83 Specifications...

  • Page 84: Studio System Operation

    Studio system operation Connection with system The SK-HD1000 can be constructed a fiber cable system and triax cable system. The CU-HD1000 and the CA-HF1000 are for fiber system. The TU-HD1000 and the CX-HD1000 are for triax system. Both of system can be used with remote control unit RU-1500JY and RU-1000VR. Setup control unit SU-1000 can control up to 12 camera systems.

  • Page 85: Service Information

    Service information Connector pin diagrams LENS connector REMOTE connector 12pin 4pin Signal +12V output SD input SD output SD GND Signal AUX SW DC IN connector CALL TRG ENF AUTO IRIS CONTROL +12V IRIS POSITION IRIS A/R Signal EXETEND ZOOM POS F POS / L TX L RX +12V IN...
  • Page 86 Service information INTERCOM1/2 connector RET CONT 5 pin XLR female:HA16PRH-5S 6 pin female:HR10A-7R-6SB(74) Mating connector:HR10A-7P-6P PUSH Signal Signal INCOM 1 TALK ON/OFF MIC IN (C) INCOM 2 TALK ON/OFF MIC IN (H) RECEIVE(C) RECEIVE(H) RET 1 CTL RECEIVE(H) RET 2 CTL SCRIPT AC230 V OUT 5 pin female:HR10A-7R-5SB(73)

  • Page 87: Application Note: Connecting Prompter Power

    The prompter power connector is located behind the fiber connector on the Camera Adaptor CA-HF1000. This is a 5 pin socket with Power interlock. How to connect: Parts: 5 pin plug RM12BPE-5PH Hitachi code JMR0222 Refer to Page 73 of the Operation manual for pin out details. Connect as follows: Pin 1...

This manual is also suitable for:

Sk-hd1000Sk-hd1000e

Table of Contents
