Outline and features
Extensive User-Friendly
• Quick Focus
Quick Focus automatically opens the iris then
sets the video level with the electric shutter.
With the resulting shallow depth of focus, the
exact focus point can be set easily.
• User-Programmable Switches (CS-1, CS-2, CS-3)
The user can assign VF-DTL, FOCUS IND,
QUICK FOCUS, ZEBRA CH1, ZEBRA CH2,
ZEBRA CH1+2 or Digital Extender to either of
the programmable switches for ease of
operation.
• Scene Files
Gain, detail, masking, gamma and other settings
can be stored in eight scene file memories.
• Audio test tone (1kHz) is output when color bars
are selected.
• Microphone
input
supply.
Viewfinder displays
• Two mode zebra
Menu selection of over-level or between range
zebra is provided.
• Safety zone and center mark display
• Focus assist indicator is displayed on view
finder to help adjust focus position.
• Auto focus lens area marker can be displayed.
accepts
phantom
power
Studio system configurations
SK-HD2200 camera system can be composed in
combination with the CU-HD1200 fiber base
station, RU-1500 camera control panel,
SU-1000 setup control unit, VF-L90HD 9-inch
viewfinder for studio system.
* When using with the SK-HD2200, the following
equipment must have software versions listed
below.
CU-HD1200
RU-1500JY-R1
SU-1000
Remote control filter wheel
A convenient remote controller can be used to
select optical filters.
2
: ver1.14 or later
: ver1.40 or later
: ver1.40 or later
