Model Shipways ARMED VIRGINIA SLOOP 1768 2160 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

INSTRUCTION MANUAL
M
T
M
T
ODELING
HE
ODELING
HE
A
V
S
A
V
S
RMED
IRGINIA
LOOP
RMED
IRGINIA
LOOP
1768
1768
!
!
!
!
PREPARED BY BEN LANKFORD
Technical Characteristics
SCALE: 1/4" = 1' 0" (1:48)
OVERALL LENGTH: 31" (787 mm)
OVERALL HEIGHT FROM KEEL: 22" (559 mm)
OVERALL WIDTH ACROSS
LOWER YARD: 8-1/4" (210 mm)
Manufactured by Model Shipways
A Division of Model Expo, Inc., Hollywood, FL
http://www.modelexpo-online.com
Model Shipways Kit No. 2160
