V1700N Series
IP Dome Operation Manual
This manual mainly addresses the operation and programming of Infinova V1700N series IP domes. Based
on network technology, V1700N series IP domes could easily realize network digital video transmission and
network control function, and provide professional remote video services. They provide high-reliable,
cost-effective solutions to various applications.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V1700N series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Infinova V1700N series

Summary of Contents for Infinova V1700N series

  • Page 1 V1700N Series IP Dome Operation Manual This manual mainly addresses the operation and programming of Infinova V1700N series IP domes. Based on network technology, V1700N series IP domes could easily realize network digital video transmission and network control function, and provide professional remote video services. They provide high-reliable,...

  • Page 3: Copyright Statement

    This device must accept any interference received, including interference that may cause undesired operations. The V1700N series IP Domes have been tested and found to comply with the limits for a Class A digital device, pursuant to the FCC rules.
  • Page 4 Read this manual carefully before installation. This manual should be saved for future use. Important Safety Instructions and Warnings: Electronic devices must be kept away from water, fire or high magnetic radiation. Clean with a dry cloth. Provide adequate ventilation. Unplug the power supply when the device is not to be used for an extended period of time.

  • Page 5: Table Of Contents

    Table of Contents 4.3 Alarm Settings ................. 8 Chapter I System Introduction............1 4.4 Snapshot................... 9 1.1 Product Description ..............1 4.5 Time Setting................9 1.2 Product Features ..............1 4.6 OSD Settings ................9 1.3 Product Model................1 4.7 I/P Rate ..................9 1.4 Product Specifications .............

  • Page 7: Chapter I System Introduction

    Flexible Color Saturation Adjustment of Infinova V1700N IP domes. With multiple flexible function The color saturation of Infinova V1700N IP series Dome falls into 7 settings such as COM ports/controller setting/operation, Infinova degrades, by which customer can make change more easily for the V1700N IP domes are high-tech network products, which integrate sake of meeting different visual effect requirements.

  • Page 8: Notice

    3. Left-click the image to make it adapt to the size of the displaying First, user has to log in with the Infinova super ID and password box when viewing the images. (For more information, please refer to Chapter 3.1 Login). After 4.

  • Page 9: Set Ie Browser

    If the installation above fails, move forward according to the following steps to continue: Install DirectX End-User Runtime (Directx 9.0c) version 9.0c or above, which can be downloaded at http://www.microsoft.com/downloads/details.aspx?FamilyId=0A9B 6820-BFBB-4799-9908-D418CDEAC197&displaylang=en Install Microsoft NET Framework Version 1.1 Redistributable Package, which can be downloaded at http://www.microsoft.com/downloads/details.aspx?FamilyID=262d 25e3-f589-4842-8157-034d1e7cf3a3&displaylang=en Both of the 2 softwares above are in English and free of charge.

  • Page 10: Chapter Iii Basic Function Operation

    There are two default IDs for selection:(1)INFINOVA (password: INFINOVA); (2) Administrator (password: Infinova). Click ‘Login’ button to log on. If the username or password is not correct, the system will return to the above dialog box.

  • Page 11: System Information

    Note: The following descriptions are used for the super user. 3.2 System Information Figure 3-9 The initial interface of System Settings displays related system information. You can get to know all system information from this Click “OK” button, the image will be back to Figure 3-7. interface such as: basic information of system, network configure, If the 9 user is to be added, the following box will pop up:...

  • Page 12: Ptz Settings

    Camera Address: set the distributed address of V1700N IP dome. This address should be in line with that of S1 in DIP switch. The Free software update is provided for V1700N series IP domes, and number of camera address is determined by different control this update service can reduce system maintenance budget.

  • Page 13: Factory Settings

    4. If the type of updating file is wrong, the following information 3.9 Online Reboot will come out: Click button on the navigation bar to enter Reboot interface. Figure 3-20 Figure 3-24 At this time, re-check the updating file and camera system, or otherwise choose other program to update.

  • Page 14: Chapter Iv Video And Alarm Settings

    Chapter IV Video and Alarm Settings Sensitivity: set the sensitivity Recommended setting: 15 When logging in successfully, the interface will be “Live Page”(see The values (Area 1-Area 4) in Motion Detection box is configured figure 3-2 or 3-3), and then a serial buttons on the left helps you to by digital video monitor management software.

  • Page 15: Snapshot

    Local Contact: unable to send alarm through net, only local alarm Option On: display system’s time information output. Default: Local Contact. Off: do not display system’s time information Net Contact: send alarm via net. Synchronize with PC: used to check whether the time of system is the same as that of local PC.

  • Page 16: Frame Rate

    Recommended setting: 15. 4.10 QP Settings The adjustable bit rates include: 0, 2, 4, 8, 15, 20, 25 and 30. Click【QP Rate】 button in the navigation bar to display the QP parameters setting interface: 4.8 Frame Rate Click the 【Frame Rate】button in the navigation bar to display the Frame Rate interface: Figure 4-10 QP Ratio shows the cpmpressed space details.

  • Page 17: Chapter V Menu Settings

    There are 4 network Qos modes to be selected: Chapter V Menu Settings 1. Normal Service Note: The common users have no such settings. 2. Max Reliability 3. Max Throughput Click the 【Enter menu】 button on the bottom of Figure 4-1 to enter 4.

  • Page 18: Chapter Vi Camera Control

    Chapter VI Camera Control 6.2 Lens Function Setting The camera control keyboard is illustrated as below: When the mouse moves on , the button will turn light Lens when clicking it with the mouse, it returns to former status, which Direction Keys means it works.

  • Page 19: Speed Adjustment

    6.3.1 Speed Adjustment 6.3.4 Setting Autopan and Calling up Autopan Pan Speed: Adjust pan speed of dome. 8 grades are available: the Setting Autopan greater the number is, the faster the speed is. (1) Click in the “Autopan area” to start setting a autopan; (2) Use the joystick to perform automatically move back and forth Tilt speed: Adjust tilt speed of dome.

  • Page 20: Appendix Questions & Solutions

    Appendix Questions & Solutions The following table describes the symptoms causes, and solutions for the problems. Symptoms Possible Causes Solutions Wrong power connection Reconnect power cable The IP dome does not perform initiation sequence after Power supply failure Repair or replace power supply powering on Power PCB fuse damage Replace the fuse...
  • Page 22 Infinova 51 Stouts Lane, Monmouth Junction, NJ 08852, U.S.A. Tel: 1-888-685-2002 (USA only) 1-732-355-9100 Fax: 1-732-355-9101 sales@infinova.com V3.3 0903...
