- Page 1 W22IB3S-PCA3 PPC Quick Start Guide Version 1.0 January 2015 Please read these instructions carefully before using this product, and save this manual for future use.
- Page 2 Introduction Winmate’s W22IB3S-PCA3 is 21.5” flat Panel PC with Capacitive Touch Key for quick access to hardware and display OSD control. The PPC features P-Cap multi-touch screen that supports simultaneous 10-points Multi-touch for a better user experience. Features ‧21.5” 1920 x 1080 Resolution with P-Cap Multi-touch Screen ®...
- Page 3 Appearance Front View Side View W22IB3S Quick Start Guide...
- Page 4 Rear View Bottom View Top View Description Description USB 2.0 x 2 (Optional) HDMI x 1 RS232 x 1 (Optional) RJ-45 GbE LAN x 2 12V DC IN, 3-Pin Terminal Block x 1 4-Channel Isolated DIDO x 1 (Optional) RS232/422/485 x 1 Audio Jack x 1 (Optional) USB 3.0 x 1, USB 2.0 x 1 2W Speaker x 2...
-
Page 5: Getting Started
Getting Started Capacitor Touch Keys Introduction The W22IB3S-PCA3 comes with five capacitive touch keys on the front panel for quick access to hardware and display OSD control. Touch Keys Function Description Power Power on/off control To increase brightness of panel Brightness/Volume /To increase Volume (by HotTab Setting) - Page 6 Turning On / Off Turning On Press and hold the capacitive power key for 4 seconds until the blue LED backlight lid up. Turning Off Perform the following procedure to shutdown the Panel PC (for Windows 8): 1. Make sure you have closed any programs that are open on the Desktop. Start Screen apps don’t need to be closed.
-
Page 7: Using The Panel Pc
Using the Panel PC HotTab Introduction The HotTab mapping menu option allows user to change the function of the five physical touch keys (brightness/volume keys, menu key, and function key). Note: For the Panel PC to work with the capacitive touch keys, the HotTab Utility has to be installed and running the background. - Page 8 Setting the +/- Key (HotTab) This HotTab +/- Key option allows users set the (+) and (-) touch keys’ functions. The +/- keys can be set to control volume, brightness of the screen, and adjustment scale. Volume Mode Under this mode, the +/- Key controls Volume. (+) touch key is mapped to raise volume and (-) touch key is mapped to lower volume.
- Page 9 3. Tap Brightness option. Adjustment Scale Mode Under this mode, the +/- Keys switches between user’s preset Brightness level. (+) touch key sets the screen brightness to user’s preset maximum level and (-) touch key sets the screen brightness to user’s preset minimum level. In other words, user can switch between two different brightness levels quickly.
- Page 10 Setting the Function Key (HotTab) This HotTab Function Key option allows users set the function touch key’s function. To configure function key mapping, perform the following: 1. Open the HotTab utility by double clicking on the HotTab Utility icon in Windows System Tray.
- Page 11 To map the function key to another application: 1. Tap on the icon to remove connection to the original application, and pick again tapping on icon. Setting the Menu Key (HotTab) This HotTab Menu Key option allows users set the touch key’s function.
- Page 12 Metro Mode (for Windows 8) 1. When the Menu Key is set to the Metro Mode, the Menu Key icon will have the following icon: 2. When the user taps the capacitive key while running an application, the display screen will show the Metro UI as shown: W22IB3S Quick Start Guide...
- Page 13 Setting the Touchscreen Lock (HotTab) This HotTab Touch Lock option allows users to set the touchscreen lock function. To lock the touchscreen, perform the following: 1. Open the HotTab utility by double clicking on the HotTab Utility icon in Windows System Tray.
- Page 14 Setting the Key Lock / UnLock (HotTab) This HotTab Key Lock / UnLock option allows users to set the physical touch keys lock function. Icon Status Description Icon Icon Description Icon shown in white means the physical touch keys are currently unlocked. The text below the icon shows the current status (Unlocked in this case).
- Page 15 To unlock the physical touch keys, perform the following: 1. Open the HotTab utility by double clicking on the HotTab Utility icon in Windows System Tray. 2. Tap on the Key Lock option then the physical keys will be unlocked, and the icon will turn white to show that lock is no longer activated: W22IB3S Quick Start Guide...
- Page 16 W22IB3S Quick Start Guide...
