17/ 19/ 20.1/ 24" Military
Rack Mount Panel PC
User Manual
Version 1.1
Document Part No. 9152111I102D
Please read this instructions before operating the device and retain them for future reference.
Intel® Celeron N2930, 2.16 GHz
Model No.: R17IB3S-RKA1ML
R19IB3S-RKA3ML
R20IB3S-RKA2ML
W24IB3S-RKS1ML

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R17IB3S-RKA1ML and is the answer not in the manual?

Questions and answers

Related Manuals for Winmate R17IB3S-RKA1ML

Summary of Contents for Winmate R17IB3S-RKA1ML

  • Page 1 17/ 19/ 20.1/ 24” Military Rack Mount Panel PC Intel® Celeron N2930, 2.16 GHz Model No.: R17IB3S-RKA1ML R19IB3S-RKA3ML R20IB3S-RKA2ML W24IB3S-RKS1ML User Manual Version 1.1 Document Part No. 9152111I102D Please read this instructions before operating the device and retain them for future reference.

  • Page 2: Table Of Contents

    Military Rack Mount Panel PC User Manual Contents Preface ..........................4 About This User Manual ..................... 6 Chapter 1: Introduction ...................... 7 1.1 Introduction ......................8 1.2 Product Features ....................8 1.3 Package Contents ....................9 1.4 Appearance ......................9 1.5 Physical Buttons ....................
  • Page 3 Preface 3.2.5 Boot Configuration ..................50 3.2.6 Save& Exit ....................52 3.3 Using Recovery Wizard to Restore Computer ............ 54 Chapter 4: Driver Installation ................... 55 4.1 Installing Chipset Driver ..................56 4.2 Installing Graphics Driver ................... 58 4.3 Installing Intel Sideband Fabric Device (Intel MBI)Driver ........59 4.4 Installing Intel Trusted Engine Interface (Intel TXE) Driver .........

  • Page 4: Preface

    Military Rack Mount Panel PC User Manual Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.
  • Page 5 Preface Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. Note: A note is used to emphasize helpful information Important:...

  • Page 6: About This User Manual

    About This User Manual This User Manual provides information about using the Winmate® Military Grade Panel PC. The documentation set for the Military Grade Panel PC provides information for specific user needs, and includes: ...

  • Page 7: Chapter 1: Introduction

    Chapter 1: Introduction Chapter 1: Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the display device in the packing list. Mechanical dimensions and drawings included in this chapter.

  • Page 8: Introduction

    Military Rack Mount Panel PC User Manual 1.1 Introduction Thank you for choosing Winmate® Military Grade Panel PC. This series feature low power high performance CPU with fanless design. Anti-corrosive coating with aluminum alloy housing withstands the harshest military environments. Armored connectors MIL-DTL-38999 (type I and III) initially developed for aerospace industry perfectly fit in our Military grade product line.

  • Page 9: Package Contents

    Chapter 1: Introduction 1.3 Package Contents Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: ...

  • Page 10: Physical Buttons

    Military Rack Mount Panel PC User Manual 1.5 Physical Buttons On-Screen Display (OSD) is a user-friendly interface to remote the display function and to adjust the display’s image properties. It also supports special Hot Keys for easy control, such as auto- adjustment and brightness control for backlight.

  • Page 11: Dimensions

    Chapter 1: Introduction 1.7 Dimensions This section includes mechanical drawing and dimensions of Panel PCs. Dimensions 17” Unit: mm...
  • Page 12 Military Rack Mount Panel PC User Manual Dimensions 19” Unit: mm...
  • Page 13 Chapter 1: Introduction Dimensions 20” Unit: mm...
  • Page 14 Military Rack Mount Panel PC User Manual Dimensions 24” Unit: mm...

  • Page 15: Chapter 2: Installation

    Chapter 2: Installation Chapter 2: Installation This chapter provides hardware installation instructions and mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages...

  • Page 16: Cable Mounting Considerations

    Military Rack Mount Panel PC User Manual 2.1 Cable Mounting Considerations For a nice look and safe installation, make sure cables are neatly hidden behind the device. Caution/ Attention Observe all local installation requirements for connection cable type and protection level. Suivre tous les règlements locaux d’installations, de câblage et niveaux de protection.

  • Page 17: Console / Rack Mount

    Chapter 2: Installation 2.3.1 Console / Rack Mount The main mounting approach is rack mount - very user-friendly in terms of installation. Mounting Steps: 1. Prepare a fixture for the specific dimensions of the device. 2. Cut a hole on a sub frame or panel according to the cutout dimensions. 3.

  • Page 18: Vesa Mount

    Military Rack Mount Panel PC User Manual 2.3.2 VESA Mount Military Rack Mount Panel PC supports VESA Mount installation. Notice that VESA Plate is not included in Winmate’s standard accessories package. Mounting Steps: 1. Screw VESA Bracket to the fixture (ex. wall).

  • Page 19: Powering On

    Chapter 2: Installation 2.4 Powering On 2.4.1 Connecting to AC Input Power Source (Default) To connect a Panel PC to AC power source: 1. Connect one end of the Military Grade power connector MIL-DTL-38999/1 to the Panel PC. 2. Plug the other end of the power connector in to a working AC outlet. AC Power Requirements: AC Input 115~230V AC 50-60Hz...

  • Page 20: Connecting To Dc Input Power Source (Optional)

    Military Rack Mount Panel PC User Manual 2.4.2 Connecting to DC Input Power Source (Optional) To connect a Panel PC to DC power source: 1. Insert the exposed wires of the DC Power Cable to the appropriate connectors on the terminal block plug.

  • Page 21: Connecting Other Devices

    Chapter 2: Installation 2.5 Connecting Other Devices Note that all the connectors are military grade and comply with military standard. The pin assignment of the cables are as follows. Warning!/ Avertissement! Make sure the power is off when connecting and disconnecting the connectors. Assurez-vous que l'alimentation est coupée lors de la connexion et la déconnexion des connecteurs.

  • Page 22: Vga Connector

    Military Rack Mount Panel PC User Manual 2.5.2 VGA Connector Plug one end of the 15-pin D-Sub signal cable. Pin № Pin № Signal Name Name GREEN BLUE ID2/RES RED_RTN GREEN_RTN BLUE_RTN KEY/PWR ID0/RES ID1/SDA HSync VSync ID3/SCL 2.5.3 RS232/422/485 Connector Serial Port is a D-Sub 9 connector that can be configured to RS-232/422/485 by jumper Connect one side of the serial port cable to the RS-232 connector on the Panel PC and the other side to Serial COM interface.

  • Page 23: Lan Connector

    Chapter 2: Installation 2.5.5 LAN Connector Connect Ethernet connector to Ethernet interface. Pin № Pin № Signal Name Signal Name 2.5.6 HDMI Connector Pin № Signal Name Signal Name № TMDS_DATA2+ TMDS_DATA2- TMDS_DATA1+ TMDS_DATA1- TMDS_DATA0+ TMDS_DATA0- TMDS_CLOCK+ TMDS_CLOCK- DDC_CLOCK DDC_DATA Hot Plug Detect 2.5.7 RS-232 Connector (Optional) Pin №...

  • Page 24: Configuring Serial Port Settings

    Military Rack Mount Panel PC User Manual 2.6 Configuring Serial Port Settings Jumpers are located on the motherboard. It is required to open the unit to access the jumpers. Follow instructions in this section to configure serial port settings. Note: A pair of needle nose pliers may be helpful when working with jumpers.

  • Page 25: Turning On And Off

    Chapter 2: Installation 2.7 Turning On and Off To Turn ON the Panel PC: 1. Tap the power button to turn the Panel PC on. 2. Press “DEL” to enter the CMOS setting and check the BIOS setup. The Power Switch is located on the front side OSD panel. You can Turn OFF the device with the Windows power settings.

  • Page 26: Chapter 3: Bios Setup

    Military Rack Mount Panel PC User Manual Chapter 3: BIOS Setup BIOS Setup Utility is a program for configuration basic Input / Output system settings of the Panel PC for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu.

  • Page 27: When And How To Use Bios Setup

    Chapter 3: BIOS Setup 3.1 When and How to Use BIOS Setup To enter the BIOS setup, you need to connect an external USB keyboard, press <Del> key when the prompt appears on the screen during start up. The prompt screen shows only few seconds, you need to press <Del>...

  • Page 28: Main Menu

    Military Rack Mount Panel PC User Manual 3.2.1 Main Menu When you enter BIOS setup, the first menu that appears on the screen is the main menu.It contains the system information including BIOS version, processor RC version, system language, time, and date. Immediately after the [DEL] key is pressed during startup, the main BIOS setup menu appears: BIOS Setting Description...

  • Page 29: Advanced Menu

    Chapter 3: BIOS Setup 3.2.2 Advanced Menu The advanced menu also uses to set configuration of the CPU and other system devices. There are sub menus on the left frame of the screen. Important: Handle advanced BIOS settings page with caution. Any changes can affect the operation of your computer.
  • Page 30 Military Rack Mount Panel PC User Manual BIOS Setting Description Setting Option Effect ACPI Settings Configures ACPI Enter Opens submenu settings F81866 Super IO Configures IO Enter Opens submenu Configuration settings Hardware Configures Enter Opens submenu Monitor Hardware Monitor settings S5 RTC Wake Configures RTC Enter...
  • Page 31 Chapter 3: BIOS Setup 3.2.2.1 ACPI Settings Advanced Configuration and Power Interface (ACPI) settings allow to control how the power switch operates. The power supply can be adjusted for power requirements. You can use the screen to select options of ACPI configuration. A description of the selected items will appear on the right side of the screen.
  • Page 32 Military Rack Mount Panel PC User Manual 3.2.2.2 F81866 Super IO Configuration You can use the screen to select options for Super IO Configuration, and change the value of the option selected. A description of the selected item appears on the right side of the screen. For items marked with ►, please press <Enter>...
  • Page 33 Chapter 3: BIOS Setup Watch Dog Time Select You can either disable Watch Dog Timer or set up the time.Use <Arrow> keys to navigate and please press <Enter>to select the item. GPI0 Port Configuration You can use the screen to change GPI0 Port setting. Use these items to set parameters related to PIN3-PIN14 Control.
  • Page 34 Military Rack Mount Panel PC User Manual 3.2.2.3 Hardware Monitor You can check PC Health Status parameters such as system temperature, fan speed etc. 3.2.2.4 S5 RTC Wake Settings Wake system from S5 enables or disables system wake on alarm event. It allows you to wake up the system in a certain time.
  • Page 35 Chapter 3: BIOS Setup Wake System from S5 with fixed time setting Select Fixed Time to set the system to wake on the specified time. Use Navigation Keys to switch among the items: Day, Hour, Minute and Second. Type the desired value in the selected item. or example: If you want the system to start up automatically at 15:30:30, the 10th day of each month, then you should enter 10, 15, 30, and 30 from top to bottom.
  • Page 36 Military Rack Mount Panel PC User Manual 3.2.2.5 CPU Configuration BIOS Setting Description Setting Option Effect Socket CPU This item contains Enter Open sub-menu Information socket specific CPU information. CPU Thermal Thermal control Enter Open sub-menu Configuration Limit CPUID Limits CPIID Disabled/Enabled Enable/Disable Maximum...
  • Page 37 Chapter 3: BIOS Setup 3.2.2.6 PPM Configuration BIOS Setting Description Setting Option Effect CPU C State Shows CPU C Enabled/ Enable or Disable Report State Report Disabled CPU C state report to OS Max CPU C- Allows to enter C1E, C3, C6, C7, Enable or Disable State power-saving...
  • Page 38 Military Rack Mount Panel PC User Manual 3.2.2.7 Thermal Configuration This menu allows controlling thermal settings of the computer. Refer to the descriptions on the top right side of the screen for detailed information about each setting. BIOS Setting Description Setting Option Effect Critical Trip Point...
  • Page 39 Chapter 3: BIOS Setup 3.2.2.8 IDE Configuration...
  • Page 40 Military Rack Mount Panel PC User Manual BIOS Setting Description Setting Effect Option Serial- ATA Responsible for supporting Enabled/ Enable or disable (SATA) chipset drives with SATA Disabled this function interface. SATA Speed Allows forcing the speed limit Gen1 The maximum Support SATA II ports standard IDE / speed will be...
  • Page 41 Chapter 3: BIOS Setup 3.2.2.9 Miscellaneous Configuration OS Selection This item allows users to select the proper Operating System. BIOS Setting Description Setting Option Effect Windows 8.X Allows user to Enter Use Windows 8.X choose the proper Windows 7 Allows user to Enter Use Windows 7 choose the proper...
  • Page 42 Military Rack Mount Panel PC User Manual 3.2.2.10 CSM Configuration...
  • Page 43 Chapter 3: BIOS Setup BIOS Setting Description Setting Option Effect CSM Support The Compatibility Enabled/ Enable or Support Module Disabled disable the (CSM) is a Compatibility component of the Support Module UEFI firmware that provides legacy BIOS compatibility by emulating a BIOS environment, allowing legacy operating systems...
  • Page 44 Military Rack Mount Panel PC User Manual 3.2.2.11 USB Configuration...
  • Page 45 Chapter 3: BIOS Setup BIOS Setting Description Setting Option Effect Legacy USB User can enable Disable Will keep USB Support or disable USB devices port. available only for EFI applications. Enable Enable all the USB devices USB 3.0 Support User can enable Enable Enable USB 3.0 or disable USB...
  • Page 46 Military Rack Mount Panel PC User Manual 3.2.2.12 Platform Trust Technology BIOS Setting Description Setting Option Effect fTPM Trusted Platform Enabled/Disabled Enables or Module disables this parameters function...
  • Page 47 Chapter 3: BIOS Setup 3.2.2.13 Security Configuration BIOS Setting Description Setting Option Effect Trusted Execution Enabled/Disabled Enables or Technology disables this parameters function TXE HMRFPO TXE HMRFPO Enabled/Disabled Enables or parameters disables this function TXE Firmware TXE Firmware Enabled/Disabled Enables or Update Update disables this...

  • Page 48: Chipset Menu

    Military Rack Mount Panel PC User Manual 3.2.3 Chipset Menu For items marked with ►, please press <Enter> for more options. BIOS Description Setting Effect Setting Option High Allow to set up High Precious Enabled/ Enables/Disab Precious Timer settings Disabled les this Timer function...

  • Page 49: Security Menu

    Chapter 3: BIOS Setup 3.2.4 Security Menu In the Security menu, users can set administrator password, user password, and HDD security configuration. BIOS Setting Description Setting Effect Option Administrator Displays whether or not an Enter Enter Password administrator password has password been set.

  • Page 50: Boot Configuration

    Military Rack Mount Panel PC User Manual 3.2.5 Boot Configuration The Boot menu sets the sequence of the devices to be searched for the operating system.The bootable devices will be automatically detected during POST and shown here,allowing you to set the sequence that the BIOS uses to look for a boot device from which to load the operating system.
  • Page 51 Chapter 3: BIOS Setup BIOS Setting Description Setting Option Effect Setup Prompt Allows user to Enter Set the prompt Timeout configure the timeout number of seconds to stay in BIOS setup prompt screen. Boot NumLock Enables or Remains On State disables NumLock feature on the Remains OFF...

  • Page 52: Save& Exit

    Military Rack Mount Panel PC User Manual 3.2.6 Save& Exit The Exit menu displays a way how to exit BIOS Setup utility. After finishing your settings, you must save and exit for changes to be applied.
  • Page 53 Chapter 3: BIOS Setup BIOS Setting Description Setting Option Effect Save Changes This saves the Enter <YES> Save changes and Exit changes to the CMOS and exits the BIOS Setup program. Discard Changes This exits the Enter <YES> Saves the and Exit BIOS Setup changes...

  • Page 54: Using Recovery Wizard To Restore Computer

    Military Rack Mount Panel PC User Manual 3.3 Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. To enable quick one-key recovery procedure: ...

  • Page 55: Chapter 4: Driver Installation

    Chapter 4: Driver Installation Chapter 4: Driver Installation This chapter provides guideline to driver installation.

  • Page 56: Installing Chipset Driver

    Military Rack Mount Panel PC User Manual 4.1 Installing Chipset Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Chipset Driver” and click “infinst_auto.exe” to install driver. Step 2 Click Next to continue.
  • Page 57 Chapter 4: Driver Installation Step 3 Click Yes to agree the license terms. Step 4 Click Next to install the driver. Step 5 Software setup progress window will appear, click Next to continue. Step 6 Click “Yes, I want to restart this computer now” to finish the installation.

  • Page 58: Installing Graphics Driver

    Military Rack Mount Panel PC User Manual 4.2 Installing Graphics Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Graphics Driver” and click Setup to execute the setup. Step 2 Setup Welcome Window will appear, click Next to continue the process. Step 3 Carefully read the license terms and click Yes to agree.

  • Page 59: Installing Intel Sideband Fabric Device (Intel Mbi)Driver

    Chapter 4: Driver Installation 4.3 Installing Intel Sideband Fabric Device (Intel MBI)Driver Only required for Windows 8 operating system. Step 1 Insert the CD that comes with the motherboard. Open the file document “MBI” and click “Setup.exe” to install the driver. Step 2 Welcome to the setup program window will appear, click Next to start the installation.

  • Page 60: Installing Intel Trusted Engine Interface (Intel Txe) Driver

    Military Rack Mount Panel PC User Manual 4.4 Installing Intel Trusted Engine Interface (Intel TXE) Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “TXE” and click “Setup TXE.exe” to install the driver. Step 2 Welcome to the setup program window will appear, click Next to start the installation. Step 3 Carefully read the license terms and click Yes to agree.

  • Page 61: Installing Intel Network Connections

    Chapter 4: Driver Installation 4.5 Installing Intel Network Connections User must confirm the type of operating system is being used before installing Intel Network Connections. Follow the steps below to complete the installation. Step 1 Click “PROWin64.exe” Step 2 Click Yes to start the installation. Step 3 Welcome window will appear, click Next to install the driver.

  • Page 62: Installing Audio Driver

    Military Rack Mount Panel PC User Manual 4.6 Installing Audio Driver The ALC886 series are high-performance 7.1+2 channel high definition audio codecs that provide ten DAC channels for simultaneous support of 7.1 sound playback, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs. The series integrates two stereo ADCs that can support a stereo microphone, and feature Acoustic Echo Cancellation (AEC), Beam Forming (BF), and Noise Suppression (NS) technology.

  • Page 63: Installing Usb 3.0 Driver (Windows 7)

    Chapter 4: Driver Installation 4.7 Installing USB 3.0 Driver (Windows 7) Note: If your operation system is Windows Embedded 8.1 Industry or Windows Embedded 8 Standard, you should skip the USB 3.0 driver installation. This HMI features Intel Celeron Trail-M N2930CPU with the Intel® USB 3.0 extensible Host Controller.

  • Page 64: Chapter 5: Technical Support

    Military Rack Mount Panel PC User Manual Chapter 5: Technical Support This chapter includes the directory for technical support. Free technical support is available from our engineers every business day. We are always ready to give advice on application requirements or specific information on the installation and operation of any of our products. If any problem occurs fill in problem report form enclosed and immediately contact us.

  • Page 65: Introduction

    Chapter 5: Technical Support 5.1 Introduction Winmate provide the following Drivers for Military Grade Rack Mount Panel PC with Intel® Celeron N2930 2.16GHz processor. Item Driver Description Windows 10 1_Chipset 2_Graphics 3_Audio 4_DPTF 5_TXE 6_Virtual Buttons 7_Touch Driver 8_Serial IO...

  • Page 66: Problem Report Form

    Military Rack Mount Panel PC User Manual 5.2 Problem Report Form Military Grade Rack Mount Panel PC Customer name: Company: Tel.: Fax: E-mail: Date: Product Serial Number: ___________________ Problem Description: Please describe the problem as clearly as possible. Detailed description of the occurred problem will allow us to find the best solution to solve the problem as soon as possible.

  • Page 67: Appendix

    Appendix Appendix This chapter contains additional product information, including military standard compliance description and product maintenance recommendations.

  • Page 68: Appendix A: Hardware Specifications

    Military Rack Mount Panel PC User Manual Appendix A: Hardware Specifications Model Name R17IB3S- R19IB3S- R20IB3S- W24IB3S- RKA1ML RKA3ML RKA2ML RKS1ML Display: 20.1” 24” Size 17” 19” Resolution 1280 x 1024 1280 x 1024 1600 x 1200 1920 x 1200 Brightness 350 cd/ (typ.)

  • Page 69: Appendix B: Mil-Std-810F/G Compliance

    Appendix B: MIL-STD-810F/G Compliance This section includes information on testing methods and procedures in compliance with military standard MIL-STD-810 F/G. MIL-STD-810F/G Compliance Test Reference Condition * Humidity Method 507.5 30 to 60℃ ± 2℃, 95% RH ± 3% Method 514.6, 5 ~ 500 Hz, 1.48/1.90/2.24 Grms, * Vibration Procedure I...

  • Page 70: Appendix C: Mil-Std-461E/F Compliance

    Military Rack Mount Panel PC User Manual Appendix C: MIL-STD-461E/F Compliance This section includes information on testing methods and procedures in compliance with military standard MIL-STD-461 E/F. MIL-STD-461E/F Compliance Test Description Type Frequency Range CE101 Power Leads Conducted Emission 30 Hz ~ 10 kHz *CE102 Power Leads Conducted Emission...

  • Page 71: Appendix D: Maintenance

    Appendix Appendix D: Maintenance D-1 Cleaning the Display Screen  Wipe the screen with a clean, soft, lint-free cloth. This removes dust and other particles. Do not use acetone, ethyl alcohol, toluene, ethyl acid or methyl chloride to clear the panel. It may permanently damage the display screen.
  • Page 72 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
