GLOBAL CONFIG

CV MODE: 6 CONTROLS AND CLOCKS

In "6 controls" mode, all of the output pairs are used to output either a CV voltage
controlled by the control knobs or various clock divisions for synchronizing other devices.
The first seven CV outputs will generate a voltage that corresponds to the controller knob
locations and the TEMPO knob location.
The eighth CV output generates a 5V pulse that is compatible with Volca sync signals.
CV OUTPUT 1
CV OUTPUT 2
CV OUTPUT 3
CV OUTPUT 4
CV OUTPUT 5
CV OUTPUT 6
CV OUTPUT 7
CV OUTPUT 8
The eight GATE outputs generate the following clock signals:
GATE OUTPUT 1
GATE OUTPUT 2
GATE OUTPUT 3
GATE OUTPUT 4
GATE OUTPUT 5
GATE OUTPUT 6
GATE OUTPUT 7
GATE OUTPUT 8
Control voltage corresponding to control knob 1
Control voltage corresponding to control knob 2
Control voltage corresponding to control knob 3
Control voltage corresponding to control knob 4
Control voltage corresponding to control knob 5
Control voltage corresponding to control knob 6
Control voltage corresponding to tempo knob
Clock signal pulse compatible with Volca sync
24 PPQN Twenty-four pulses per quarter note.
12 PPQN Twelve per quarter note.
8 PPQN Eight pulses per quarter note.
6 PPQN Six pulses per quarter note.
4 PPQN Four pulses per quarter note.
2 PPQN Two pulses per quarter note.
1 PPQN One pulse per quarter note
RUN/STOP High while sequencer is running, low when sequencer is
stopped
132 USER GUIDE
