Specifications - Midas M32C Quick Start Manual

18 M32C DIGITAL RACK MIXER
Specifi cations
Processing
32 input channels, 8 aux channels, 8 FX return channels, 16 aux buses,
Number of processing channels
6 matrices, main LRC
Internal eff ects engines, true stereo / mono 8 / 16
Internal total recall scenes (incl. preamp and fader) 100
Signal processing 40-bit fl oating point
Network I/O latency (stagebox in > console
1.1 ms
processing* > stagebox out)
Connectors
Talkback mic input, TRS 1 external (no phantom power)
Monitoring outputs ¼ " TRS balanced 2
AES50 ports, SuperMAC 2
Expansion card slot 32 channel audio input/output, various standards
P-16 connector, ULTRANET (no power supplied) 1
MIDI inputs / outputs 1/1
Ethernet, RJ45, rear panel, for remote control 1
USB Type A, front panel, for audio and data
1
export/import
Talkback Input
Maximum gain +50 dB
Maximum input level at unity gain +8 dBu
Input impedance 2 kΩ
Monitor Outputs
Maximum output level +21 dBu
Output impedance 50 Ω
Frequency response, +0 to -1 dB 20 Hz - 20 kHz
Output noise, 22 Hz - 22 kHz -83 dBu, unweighted
Distortion, 0 dBu output level, 1 kHz 0.02%
Indicators
LCD screen 128 x 64, LCD with RGB color backlight
Status LEDs AES50 port A/B status, power LED, Mute All button
Power
Switch-mode power supply Autorange 100-240 V (50/60 Hz)
Power consumption 40 W
Physical
Standard operating temperature range 5°C – 40°C (41°F – 104°F)
Dimensions 483 x 300 x 50 mm (19 x 11.8 x 2")
Weight 3.5 kg (7.7 lbs)
*including all channel and bus processing, excluding insert effects and line delays
Quick Start Guide 19
