M32 DIGITAL CONSOLE User Manual

4. Appendices

4.1 Appendix A: Technical Specifications

Processing
Input Processing Channels
Output Processing Channels
16 aux buses, 6 matrices, main LRC
Internal Effects Engines (True Stereo / Mono)
Internal Show Automation (structured Cues / Snippets)
Internal Total Recall Scenes (incl. Preamplifiers and Faders)
Signal Processing
A/D Conversion (8-channel, 96 kHz ready)
D/A Conversion (stereo, 96 kHz ready)
I/O Latency (Console Input to Output)
Network Latency (Stage Box In > Console > Stage Box Out)
Connectors
MIDAS PRO Series Microphone Preamplifier (XLR)
Talkback Microphone Input (XLR)
RCA Inputs / Outputs
XLR Outputs
Monitoring Outputs (XLR / ¼" TRS Balanced)
Aux Inputs/Outputs (¼" TRS Balanced)
Phones Output (¼" TRS)
Digital AES/EBU Output (XLR)
AES50 Ports (KLARK TEKNIK SuperMAC)
Expansion Card Interface
ULTRANET P-16 Connector (No Power Supplied)
MIDI Inputs / Outputs
USB Type A (Audio and Data Import / Export)
USB Type B, rear panel, for remote control
Ethernet, RJ45, rear panel, for remote control
Mic Input Characteristics
Design
THD+N (0 dB gain, 0 dBu output)
THD+N (+40 dB gain, 0 dBu to +20 dBu output)
Input Impedance (Unbalanced / Balanced)
Non-Clip Maximum Input Level
Phantom Power (Switchable per Input)
Equivalent Input Noise @ +45dB gain (150 Ω source)
CMRR @ Unity Gain (Typical)
CMRR @ 40 dB Gain (Typical)
32 Input Channels, 8 Aux Channels, 8 FX Return Channels
8 / 16
100
8 / 16
500 / 100
100
40-Bit Floating Point
24-Bit, 114 dB Dynamic Range A-weighted*
24-Bit, 120 dB Dynamic Range A-weighted*
0.8 ms
1.1 ms
* A-weighted figures are typically ~3 dB better
32
1
2/2
16
2/2
6/6
2 (Stereo)
1
2
32 Channel Audio Input / Output
1
1/1
1
1
1
MIDAS PRO Series
< 0.01% unweighted
< 0.03% unweighted
10 kΩ / 10 kΩ
+23 dBu
+48 V
-125 dBu 22 Hz-22 kHz unweighted
> 70 dB
> 90 dB
