DL351 Modular I/O
Operator Manual
Midas Klark Teknik Limited,
Klark Industrial Park,
Walter Nash Road,
Kidderminster.
Worcestershire.
DY11 7HJ.
England.
Tel: +44 1562 741515
Fax: +44 1562 745371
Email: info@midasklarkteknik.com
Website: www.midasconsoles.com
DL351 Modular I/O — Operator Manual
DOC02-DL351 Issue C — July 2010
© Red Chip Company Ltd.
In line with the company's policy of continual improvement, specifications and function may be
subject to change without notice. This Operator Manual was correct at the time of writing. E&OE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro 6 DL351 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Midas Pro 6 DL351

Summary of Contents for Midas Pro 6 DL351

  • Page 1 DL351 Modular I/O Operator Manual Midas Klark Teknik Limited, Klark Industrial Park, Walter Nash Road, Kidderminster. Worcestershire. DY11 7HJ. England. Tel: +44 1562 741515 Fax: +44 1562 745371 Email: info@midasklarkteknik.com Website: www.midasconsoles.com DL351 Modular I/O — Operator Manual DOC02-DL351 Issue C — July 2010 ©...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.
  • Page 5 Midas EC-Declaration of Conformity The undersigned, representing the following manufacturer Manufacturer: Address: Midas Klark Teknik Ltd. Klark Industrial Park, Walter Nash Road, Kidderminster. Worcestershire. DY11 7HJ. hereby declares that the following product Product Type Number Product Description Nominal Voltage(s) Current Freq.
  • Page 7 Midas™ or Klark Teknik™ Product, as well as other software that we provide for installation on this Product. The Midas™ or Klark Teknik™ Product will not operate in accordance with its documentation without this software.
  • Page 8 If you wish to receive a computer-readable copy of the source code for any of the GNU Linux Programs that have been provided with your Midas™ or Klark Teknik™ Product, send a cheque or money order (no cash accepted), your address and [£10.00] to cover the cost...
  • Page 9 GNU General Public License (GPL) For details of the Third Party Software License Attribution, Copyright and Terms and Conditions and Notices, and the GNU LESSER GENERAL PUBLIC LICENSE, see the Midas Digital Equipment GNU General Public License (GPL) Booklet part number DOC04-GPL issue A.
  • Page 11 Precautions Before installing, setting up or operating this equipment make sure you have read and fully understand all of this section and the “IMPORTANT SAFETY INSTRUCTIONS” at the front of this manual. This equipment is supplied by a mains voltage that can cause electric shock injury! The following must be observed in order to maintain safety and electromagnetic compatibility (EMC) performance.
  • Page 12 Precautions Do not insert your fingers or hands in any gaps XLR connector shells should be of metal or openings on the equipment, for example, construction so that they provide a screen when vents. connected to the control centre and, where appropriate, they should have Pin 1 connected to the cable screen.
  • Page 13 xiii Precautions Optional equipment Special accessories Unless advised otherwise, optional equipment To comply with part 15 of the FCC Rules, any must only be installed by service personnel and special accessories (that is, items that cannot be in accordance with the appropriate assembly readily obtained from multiple retail outlets) and usage regulations.
  • Page 14 Precautions DL351 Modular I/O Operator Manual...

  • Page 15: Table Of Contents

    Contents Chapter 1 Introduction ....... . . 1 Overview ..........1 Features .
  • Page 16 Contents Appendix C I/O Modules ....... 29 DL441 analogue input module ......29 DL442 analogue output module .

  • Page 17: Introduction

    Chapter 1: Introduction Thank you for purchasing a Midas DL351 Modular I/O. Your DL351 Modular I/O was conceived by Midas to offer audio professionals high-performance audio equipment, designed to provide no-compromise sonic quality with a feature set that offers all essential facilities and functions.

  • Page 18: Features

    Warranty and registration Midas has total confidence in the quality and reliability of this product. To back this up, this product comes with the standard Midas and Klark Teknik three year warranty. Please take the time to register your product by completing and returning the registration card or registering on our website at www.midasconsoles.com.

  • Page 19: About This Manual

    Check the contents of your DL351 Modular I/O equipment package and, if there are any parts missing, incorrect or faulty, please contact your local distributor or Midas at the address shown in the front of this manual.
  • Page 20 Chapter 1: Introduction DL351 Modular I/O Operator Manual...

  • Page 21: Front Panel

    Chapter 2: Front Panel The front panel of the DL351 Modular I/O comprises the following: Four ventilation panels. Do not Control panel; see “Control panel” on obstruct. page 6. Eight rows of eight write-on strips for Power supply unit monitoring panel; see manually marking the analogue/digital channel “psu panel”...

  • Page 22: Aes50 Audio Panel

    Chapter 2: Front Panel AES50 audio panel The AES50 audio panel has four sets of LEDs (one set per AES50 audio connector) to indicate communication status, as follows: • Green ok LED pulsating = good communication. • Red error LED illuminated = communication error. Control panel The control panel is used for setting up and monitoring the DL351 Modular I/O.

  • Page 23: Rear Panel

    Chapter 3: Rear Panel The rear panel of the DL351 Modular I/O has three main sections, as shown below. Mains power sockets and isolator Connector panel; see “Connector panel” switches; see “Mains input” on page 7. on page 8. User-configurable module panel into which any combination of up to eight modules (see Appendix C “I/O Modules”) can be fitted.

  • Page 24: Connector Panel

    Chapter 3: Rear Panel Connector panel The connector panel comprises: MIDI INSTRUMENT MIDI-equipped instruments, such as synthesiser, DL371 Audio keyboard, System Engine guitar etc. Four AES50 audio Ethernet sockets for Two GPIO 25-way connectors, in and passing audio and control data to/from the out, for control of external devices, such as DL371 Audio System Engine.

  • Page 25: Getting Started

    Chapter 4: Getting Started This chapter shows you how to connect up, switch on, set up and configure the DL351 Modular I/O unit. Connecting up Refer to Figure 2 “Standard system configuration” on page 50 and “Connector panel” on page 8. Connect up the following, as appropriate, to the rear panel of your DL351 Modular I/O unit: •...

  • Page 26: Powering The Unit

    Chapter 4: Getting Started Powering the unit Caution: Do not switch the mains on/off switches on or off simultaneously. They must be switched on or off one at a time. This section shows you how to switch the unit on/off, and also how to completely isolate it electrically.

  • Page 27: Main Menu

    Chapter 5: Main Menu This chapter describes the menu options that allow you to set up your DL351 Modular I/O. About the main menu The main menu is accessed via the control panel and provides five options that allow you to carry out the following: •...
  • Page 28 Chapter 5: Main Menu Main menu flowchart (options 1 to 4) Default screen Press and hold for about two seconds Option 1 Option 2 Option 3 Option 4 Option 5 This option does not appear if there are no digital I/O boards fitted.
  • Page 29 Main menu flowchart This example shows that you have selected 2 as the unit’s ID number ID number flashes if it is available for selection Default display will show new ID number, if it has been changed Notes: In menu mode, This flowchart only shows Non-flashing options pressing MENU...
  • Page 30 Chapter 5: Main Menu Main menu flowchart (option 5) This option does not appear if there are no digital boards fitted Select from channels 1-2, 3-4, 5-6 and 7-8 All board positions (A to H) appear, even if some don’t have a board fitted This action occurs even if there is no digital...
  • Page 31 Main menu flowchart Select from OUTPUT SRC and INPUT SRC settings for Ch1&2, 3&4, 5&6 and 7&8 “in” = option is selected “out” = option is not selected DL351 Modular I/O Operator Manual...

  • Page 32: Using The Menu

    Chapter 5: Main Menu Using the menu This section shows you how to enter/exit the main menu, navigate your way around the options and how to select an option. The main menu is operated via the four control panel buttons (MENU, SELECT and the up and down arrows).

  • Page 33: Main Menu Options

    Main menu options Main menu options The following subsections describe the function of each main menu and how to use them for setting up, configuration, checking etc. While carrying out the configuration procedures detailed in this section, refer to the main menu flowchart (see “Main menu flowchart”...
  • Page 34 Chapter 5: Main Menu Do one of the following: • If the option is already selected (not flashing), use the up and down arrow buttons to go to the “Unchanged” option. • If the option is not selected (flashing), go to the next step. Press SELECT.
  • Page 35 Main menu options Option 5 — Digital boards This option allows you to set up the clock source (outputs), SRC and word size for any digital I/O board(s) fitted in the unit. This option has eight boards to choose from — “A”...
  • Page 36 Chapter 5: Main Menu >> To set up the SRC option for a pair of digital channels After selecting the digital I/O board you wish to configure (see “To select the digital I/O board (module position)” on page 19), press SELECT to go to the “Clock Setup(out)”...

  • Page 37: Operation

    Chapter 6: Operation This chapter explains the default screen. There are no operating procedures associated with the DL351 Modular I/O, as it is operated solely from the PRO6 Control Centre. Refer to PRO6 Control Centre operator manual (part number DOC02-DL3) for more details.
  • Page 38 Chapter 6: Operation DL351 Modular I/O Operator Manual...

  • Page 39: Appendix A Functional Block Diagrams

    Appendix A: Functional Block Diagrams This appendix contains a functional block diagram for each module. Analogue input module (DL441) Line/mic board details. DL351 Modular I/O Operator Manual...

  • Page 40: Analogue Output Module (Dl442)

    Appendix A: Functional Block Diagrams Analogue output module (DL442) Line out board details. SYSTEM LOCAL WORD CLOCK DIGITAL MUTE DIGITAL BACKPLANE SIGNALS ADDRESS STATUS REMOTE CONTROL DATA INTERFACE Lo Pass Filter REMOTE INTERROGATE LINE 1 OF 8 CHANNEL PATHS DL351 Modular I/O Operator Manual...

  • Page 41: Analogue Jack I/O Module (Dl443)

    Analogue Jack I/O module (DL443) Analogue Jack I/O module (DL443) DL351 Modular I/O Operator Manual...

  • Page 42: Aes/Ebu Digital I/O Module (Dl452)

    Appendix A: Functional Block Diagrams AES/EBU digital I/O module (DL452) DIGITAL BACKPLANE SIGNALS 1 OF 4 CHANNELS LOCAL SYSTEM WORD CLOCK Digital Audio Out Digital Audio In ADDRESS DATA SYSTEM CONTROL FPGA AUDIO SYSTEMS REMOTE SYNC Input MUTE REMOTE Output CLOCKS STATUS INTERROGATE...

  • Page 43: Appendix B Technical Specification

    DL351 Modular I/O specifications and for full technical specifications for the XL8 Live Performance System, please refer to the Owner’s Manual (part number DOC02-DL3). Due to a policy of continual improvement, Midas reserves the right to alter the function or specification at any time without notice. General specifications...
  • Page 44 Appendix B: Technical Specification Digital outputs Connector AES3 (two channels of digital audio) on 3-pin XLR Sample rates 48k, 96k or auto tracking to inputs Bypass Sample rate converter can be bypassed Word length 16-, 20- or 24-bit Analogue Jack inputs and outputs Connector 16 x 1/4”...

  • Page 45: I/O Modules

    Appendix C: I/O Modules There are eight module slots (A to H) into which any combination of the following modules can be fitted: • DL441 analogue input module; see “DL441 analogue input module” on page 29. • DL442 analogue output module; see “DL442 analogue output module” on page 30. •...

  • Page 46: Dl442 Analogue Output Module

    Appendix C: I/O Modules DL442 analogue output module The DL442 analogue output module provides eight balanced line outputs. Its rear panel houses eight output XLRs, each with a check and a mute LED. The line outputs have no analogue level adjustment. Eight XLR analogue outputs.

  • Page 47: Dl452 Digital I/O Module

    DL452 digital I/O module DL452 digital I/O module The DL452 digital I/O module provides four (stereo) AES/EBU inputs and outputs. Its rear panel houses these I/Os in four pairs. Each input has a check and a sync LED and each output has a check and a mute LED. Each AES/EBU input can run at sample rates up to 96kHz (44.1Hz, 48kHz, 88.2kHz and 96kHz) using a sample rate converter (SRC).
  • Page 48 Appendix C: I/O Modules DL351 Modular I/O Operator Manual...

  • Page 49: Replacing An I/O Module

    Appendix D: Replacing An I/O Module This appendix provides instructions on module replacement. Replacing a module The design of the DL351 Modular I/O makes module replacement very easy and straightforward. The unit has rack guides in each of the eight module positions so that the modules can slide easily in and out.
  • Page 50 Appendix D: Replacing An I/O Module >> To fit a module Make sure the unit is switched off and electrically isolated; see “To switch the unit off” on page 10. At the rear of the unit, offer up the rear of the module to its required module position.

  • Page 51: Service Information

    Appendix E: Service Information This appendix provides instructions on routine servicing and cleaning, and gives details on equipment disposal. Routine maintenance To help keep your DL351 Modular I/O unit in good working order and to make sure it gives you optimum performance, we recommend that you carry out the following: Monthly •...

  • Page 52: Equipment Disposal

    This procedure must be carried out by a fully qualified service engineer. If you have any queries, contact Midas; details can be found at the front of this manual. Equipment disposal...

  • Page 53: Pro6 Live Audio System

    Appendix F: PRO6 Live Audio System This chapter provides a detailed overview of the XL8 Live Performance System. Standard system configuration The PRO6 Live Audio System is a very powerful and flexible audio processing system that provides a complete solution for any audio mixing and signal distribution application in a live sound environment.
  • Page 54 • Mic amps — High quality, overload tolerant microphone amplifier per input. • Dynamics — High quality dynamic processing with traditional analogue artefacts. Midas dynamics has four styles on the inputs and five on the outputs. • EQ — Fully interpolated phase shifting EQ for that “Midas” sound.

  • Page 55: Applications

    US, UK and Singapore. Applications The PRO6 is the ‘work horse’ mid- to high-end Midas Digital Console System, akin to the ‘industry standard’ Heritage 3000. Although the PRO6 is designed for the traditional touring live sound environment, it is also ideal for medium-sized theatre, small house of worship installations and broadcast.

  • Page 56: System Components (Standard Supply)

    Appendix F: PRO6 Live Audio System System components (standard supply) The PRO6 Live Audio System is modular, allowing for some variations in physical placement and system size. The standard PRO6 touring system package is configured as a 14U rack (containing two DL3n1 units) in a single, easily portable flight case, with an equally portable, flight-cased control surface and minimal cabling.

  • Page 57: Mix Matrix

    Mix matrix • 16-off matrix buses, routable from the 56 inputs and eight aux inputs, and 16 aux buses and three master buses. • 16-off aux buses, routable from the 56 inputs and eight aux inputs. All the bus routings (above) provide simultaneous and time aligned mixing of all the sources, which will be defeatable for minimum latency requirements.

  • Page 58: Processing

    Appendix F: PRO6 Live Audio System Processing Although the control centre system allows for considerable insertion of external processing it also embodies more than enough internal high quality processing to eliminate the need for this, in the interests of simplicity and reduced overall system size, weight and cost.
  • Page 59 Processing Each of the eight auxiliary inputs has: • Input gain. • Source from internal FX or external input. • EQ. • Fader. • Panpot (SIS™). • Routing via level controls to the 16 matrix buses. • Routing via pan control to the left, right and mono master buses. Mix channel processing Each of the 16 auxiliary mix buses has: •...

  • Page 60: Audio Physical Connections

    Appendix F: PRO6 Live Audio System • Direct input. • Routing via level controls to 16 matrix buses. Effects processing and GEQs The PRO6 contains eight mono Klark Teknik (KT) GEQs and seven effects processors as standard. The seven effects processors can be freely chosen from: •...

  • Page 61: Surround Capabilities

    Surround capabilities Surround capabilities Theatres and broadcast have differing requirements for surround and both are catered for in the PRO6. Conventional stereo and SIS™ panning is assignable on a channel by channel basis (channel one can be in stereo while channel two can be in SIS™), as follows: •...

  • Page 62: Control Software

    Midas network, and will transfer audio to and from the Midas hardware without any additional interfaces or converters (provided it runs in TDM 96kHz mode). This will be particularly useful as the protocol gains acceptance with recording and playback devices, loudspeaker controllers, audio networking systems, digital amplifiers etc.
  • Page 63 Integration of third party hardware/software PC or MAC computers can use the Ethernet tunnel in the MidasNET system, and can communicate with other computers on the network. The PRO6 Control Centre features an external video for both screens, and the master bay GUI screen (on the right) also has a three-way KVM switch.
  • Page 64 Appendix F: PRO6 Live Audio System DL351 Modular I/O Operator Manual...

  • Page 65: Setting Up A Pro6 System

    This chapter shows you how to set up a PRO6 Live Audio System to its default configuration. Note: If you want to set up the PRO6 Live Audio System using a configuration other than the default, please contact Midas Technical Support for details. Initial set-up procedure Initial system set-up basically comprises: •...
  • Page 66 Appendix G: Setting Up A PRO6 System PRO6 Control Centre 3 x AES50 expansion (control surface, router, 8 x inputs, Copper ports 8 x outputs, 8 x insert Jack I/O pairs and 6 x monitor outputs) Dual cable redundant HyperMAC Fibre optic (fibre optic or copper) Mix position...

  • Page 67: Powering The Pro6 System

    Powering the PRO6 system Powering the PRO6 system The following details the recommended power up and power down procedures for the PRO6 system. Note: If you are in any doubt as to how to switch the DL3n1 units on/off, refer to their operator manuals.

  • Page 68: Switching The Pro6 Control Centre On/Off

    Appendix G: Setting Up A PRO6 System Switching the PRO6 Control Centre on/off Carry out the following to switch the PRO6 Control Centre on or off in a safe manner, observing all WARNINGS and Cautions. >> To switch on the PRO6 Control Centre Caution (1)! A minimum of two power supply modules must be supplying power to the PRO6 Control Centre for correct operation.
  • Page 69 Thank you for reading through this Operator Manual. We hope you found it useful. Please feel free to send us your comments. Our contact details and website address can be found at the front of this manual.
