M32C DIGITAL RACK MIXER Select Knob Functions
Step 3: Select Knob
The SELECT knob serves several functions on the M32C. The following table describes the SELECT knob
behavior in each of the available scenarios.
Functions
Action
Scene Select Mode (Hold the SELECT knob depressed for 2 seconds)
Display
Short press
Rotate
Setup Mode (Press SELECT knob to access menu)
Rotate and press
1. Load Show
2. Contrast
3. LEDs
4. Clock Rate
5. Sync
Functional Description
>"Scene" in bold
>Current scene number
>Next scene number and name (small) to be loaded on GO
Recalls the selected Scene from M32C internal memory "GO"
> behavior depends on Scene settings/preferences (remote controlled via
editing software)
> Scene safes can only be set/reset remotely
> Scenes/Shows from USB drives can only be accessed remotely
>A complete show can be loaded from an attached USB drive into the internal
memory using Setup Mode
Preselects the next Scene
Select and enter the Setup pages:
1. Load Show
2. Contrast
3. LEDs
4. Clock Rate
5. Sync
6. IP Address
7. IP (Subnet) Mask
8. IP Gateway
9. Lock
Load show from root directory of attached USB drive
>display 3 rows:
-Load Show
-Exit
-Show Files
>Exit leads back to Setup Mode root level
>Turn clockwise to scroll through a list of show fi les found in USB root directory,
push to load selected show and return to Setup Mode root level
LCD contrast
> Rotate to adjust 0-100
> Press to confi rm and exit
LED brightness
> Rotate to adjust 0-100
> Press to confi rm and exit
Select the internal Sample Clock Rate
> Rotate to adjust 44.1 or 48 kHz (change requires to reboot the M32C)
> Press to confi rm and exit
Choose Clock Synchronisation source
> Rotate to select INT (internal), AES50 (Port) A, or AES50 (Port) B
> Press to confi rm and exit
Action Functional Description
6. IP Address Select the IP Address for M32C
> Rotate to adjust the fi rst triplet (0-255)
> Press to confi rm
> Rotate to adjust the second triplet (0-255)
> Press to confi rm
> Rotate to adjust the third triplet (0-255)
> Press to confi rm
> Rotate to adjust the fourth triplet (0-255)
> Press to confi rm and exit
7. IP Mask Select the IP Subnet Mask for M32C
> Rotate to adjust the fi rst triplet (0-255)
> Press to confi rm
> Rotate to adjust the second triplet (0-255)
> Press to confi rm
> Rotate to adjust the third triplet (0-255)
> Press to confi rm
> Rotate to adjust the fourth triplet (0-255)
> Press to confi rm and exit
8. IP Gateway Select the IP Gateway for M32C
> Rotate to adjust the fi rst triplet (0-255)
> Press to confi rm
> Rotate to adjust the second triplet (0-255)
> Press to confi rm
> Rotate to adjust the third triplet (0-255)
> Press to confi rm
> Rotate to adjust the fourth triplet (0-255)
> Press to confi rm and exit
9. Lock Locks the M32C
>Display "Lock Cancel"
>Press to cancel locking
> Rotating clockwise turns the display from Green to Red backlight and
shows "LOCKED"
>Press and hold the SELECT knob for 5 seconds in order to exit Locked mode
