INSTALLATION INSTRUCTIONS
HB0134
A
PPEARANCE MAY VARY
IC700, IC700ES* AND IB700 SERIES
INTENDED FOR DOMESTIC COOKING ONLY
!
!
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION
ON PAGES 17
19.
TO
Venmar Ventilation ULC, 550 Lemire Blvd., Drummondville QC J2C 7W9
1-800-567-3855
REGISTER YOUR PRODUCT ONLINE AT: www.bnv.ca
For additional information, visit
www.venmar.ca
*
21225 rev. 03
Advertisement
Table of Contents
Related Manuals for Venmar ISPIRA IC700 Series
Summary of Contents for Venmar ISPIRA IC700 Series
-
Page 1: Installation Instructions
READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: USE AND CARE INFORMATION ON PAGES 17 Venmar Ventilation ULC, 550 Lemire Blvd., Drummondville QC J2C 7W9 1-800-567-3855 REGISTER YOUR PRODUCT ONLINE AT: www.bnv.ca For additional information, visit www.venmar.ca... - Page 2 Always turn hood ON when cooking at high 9. To reduce the risk of fire and electrical shock, heat or when flambeing food (i.e.: Crêpes the Venmar Ispira IC700, IC700ES and IB700 Suzette, Cherries Jubilee, Peppercorn Beef series models should only be installed with Flambé).
- Page 3 - IC700, IC700ES AND IB700 SERIES RANGE HOOD SYSTEM - ODEL ODEL ODEL (3¼” X 10” (3¼” X 10” ODEL 3¼” 10” OPTIONAL LBOW PPER ECORATIVE (IC700 IC700ES) ODEL (3¼” 10” TANDARD OWER ECORATIVE (IC700 IC700ES) 3¼” 10” DAPTER AMPER SUPPLIED WITH HOOD FOR HORIZONTAL OR VERTICAL DISCHARGE...
-
Page 4: Table Of Contents
TABLE OF CONTENTS ........................4-5 NSTALL DUCTWORK ....................... 5-6 REPARE THE INSTALLATION ......................6 EMOVE HYBRID FILTERS ) ................... 6-7 NSTALL GLASS PANEL MODELS ONLY ......................7-8 REPARE THE OPENING ......................7 5.1. IC700 IB700 M ODELS ........................8 5.2. IC700ES M ODELS ) ................ -
Page 5: Install Ductwork
INSTALL DUCTWORK CONT 80% E AXIMUM ENGHT ECOMMENDED TO CHIEVE XHAUST EFFICIENCY 3¼ AXIMUM OOF OR WALL CAP LBOW (90° 45°) ENGHT WITH DAMPER 1” TANDARD ELBOWS WITH INTERNAL RADIUS 2. PREPARE THE INSTALLATION WARNING When performing installation, servicing or cleaning the unit, it is recommended to wear safety glasses and gloves. -
Page 6: Remove Hybrid Filters
2. PREPARE THE INSTALLATION CONT ERTICAL DISCHARGE 30” ⁄ ” WIDTH HOOD 36” ⁄ ” WIDTH HOOD 7/8” ⁄ ” 9¾” Refer to illustration at right to locate duct opening for vertical discharge. HK0060A 3. REMOVE HYBRID FILTERS Lay the back of the hood on a table. Use a piece of cardboard to avoid damaging the table or the hood. -
Page 7: Prepare The Opening
4. INSTALL GLASS PANEL (WG MODELS ONLY CONT 2. Carefully remove the glass panel from its packaging. Remove glass panel nuts (factory installed) from both studs and set aside. 3. Insert glass panel studs in the appropriate hood holes. 4. While holding the glass panel, pre-tighten the previously LASS PANEL STUD removed nuts by hand. -
Page 8: Ic700Es M
5. PREPARE THE OPENING CONT IC700ES MODEL ERTICAL DISCHARGE ETAL SHUTOFF PLATE Using a screwdriver, remove the metal shutoff plate located on the top of the hood by unscrewing both retaining screws. Discard plate and screws. See illustration at right. HR0091 6. -
Page 9: Damper
6. BLOWER REMOVAL CONT - IC700 IB700) HORIZONTAL DISCHARGE ONLY 2. Using a 5/16” socket, or a Robertson or Phillips no. 2 screwdriver, remove all blower mounting screws from the inner top of the hood. Set blower and screws aside. EFT SIDE MOUNTING IGHT SIDE MOUNTING SCREW LOCATION... -
Page 10: Install The Adapter
INSTALL THE ADAPTER/DAMPER CONT ERTICAL DISCHARGE CREW LOCATION Mount the 3¼” x 10” adapter/damper to the top of the hood using 2 no. 8 x 3/8” screws (included). Seal the adapter/damper to the hood using metal foil duct tape. HJ0065 8. -
Page 11: Install Upper Flue Mounting Bracket
9. INSTALL HOOD MOUNTING BRACKET (IC700 AND IC700ES) WARNING When cutting or drilling into wall, do not damage electrical wiring and other hidden utilities. ALL STUDS Construct wood wall framing that RAMING BEHIND is even with the surface of the wall DRYWALL studs. -
Page 12: Install Hood Mounting Bracket
11. INSTALL THE HOOD (IC700 AND IC700ES) WARNING BE CAREFUL when installing the decorative flue and hood, they may have sharp edges. CAUTION DO NOT REMOVE yet the protective plastic film covering the decorative flues (upper and lower). 1. Align the hood and center it above the hood mounting bracket. Gently lower the hood until it securely engages the bracket, and slightly pull it downward to make sure it is fully engaged. -
Page 13: Duct Connection
13. DUCT CONNECTION (VERTICAL DISCHARGE ONLY - IC700 AND IC700ES) 1. Plug hood power cord into the outlet. 2. Slide the duct over the adapter/damper on the hood. 3. Use metal foil duct tape to seal the joint. NOTE: If a transition to 7” or 8” round duct is used, it is recommended to place it at least 18”... -
Page 14: Install The Decorative Flue
15. INSTALL THE DECORATIVE FLUE (IC700 AND IC700ES) 1. To prevent the flue from moving, affix the included foam squares on both sides near the front edge of the blower box (as illustrated at right). HO0192 2. Carefully slide in place decorative lower flue (notches end first) on top of the hood (1) until flue notches completely fit in hood slots (2). -
Page 15: Built-In Installation
16. BUILT-IN INSTALLATION (IB700) Although this is a chimney range hood, it can also be installed built-in the cabinetry without its chimney. Following is our recommended built-in installation. NOTE: Installation may vary depending on the cabinet set-up. HB0118 1. Follow steps presented in sections 1 to 8. 2. -
Page 16: Reinstall Hybrid Filters
16. OPTIONAL BUILT-IN INSTALLATION (IB700) CONT NOTE: For better precision, the illustration at right shows the screws location on the left side of the hood only; their location is the same on the right side of the hood. 4. Slide the blower box in the opening and secure the hood to the bottom of the cabinet using 6 screws (A) (3 screws on each side). -
Page 17: Led Lighting
18. LED LIGHTING The lighting of this hood is produced by two LED modules (included). WARNING Do not touch lamps during or soon after operation. Burns may occur. Cannot be replaced by any other type of light bulb or LED module. 19. -
Page 18: Operation
20. OPERATION Always turn your hood on before you begin cooking to establish an air flow in the kitchen. Let the blower run for a few minutes to clear the air after you turn off the range. CAUTION After a power failure or during the range hood power up, a 5-second booting sequence is executed. -
Page 19: O Peration
20. OPERATION CONT ™: The hood is equipped with a HEAT SENTRY thermostat. If blower is ON at a lower ENTRY speed setting and excessive heat is detected above the cooking surface, it turns the blower up to third speed. When the temperature level drops to normal, the blower will return to its original setting. -
Page 20: Wiring Diagram
ARTS AND EPAIRS In order to ensure your unit remains in good working condition, you must use Venmar Ventilation ULC genuine replacement parts only. Venmar Ventilation ULC genuine replacement parts are specially designed for each unit and are manufactured to comply with all the applicable certification standards and maintain a high standard of safety. -
Page 21: Service Parts
22. SERVICE PARTS IDTHS ART NO ESCRIPTION 30" 36" SV09955XX* G 30” LASS ANEL SV09956XX* G 36” LASS ANEL 09550 LECTRONIC ONTROL 09022 RANSFORMER 62612 MODULE 62053 15.875” 14” x 0.5” (1) YBRID FILTER SV08582 NTERNAL BLOWER 62248 DRIVER AND CONNECTION HARNESS 21189 OWER 09014... -
Page 22: Warranty
To contact Venmar Ventilation ULC warranty service, call 1-800-567-3855 in Canada. In order to qualify for a warranty claim, the owner of a Venmar Ispira IC700, IC700ES or IB700 Series range hood must have the model and serial number along with a proof of the original purchase date. At the time of requesting service, describe the nature of any defect in the product or part.
