INSTALLATION INSTRUCTIONS
HB0124
VJ71130SS CHIMNEY RANGE HOOD
INTENDED FOR DOMESTIC COOKING ONLY
!
!
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGES 10 AND 11.
Venmar Ventilation Inc., 550 Lemire Blvd., Drummondville QC J2C 7W9
1-800-567-3855
REGISTER YOUR PRODUCT ONLINE AT: www.bnv.ca
For additional information - visit www.venmar.ca
20083 rev. 03
Advertisement
Table of Contents
Related Manuals for Venmar VJ71130SS
Summary of Contents for Venmar VJ71130SS
- Page 1 READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: USE AND CARE INFORMATION ON PAGES 10 AND 11. Venmar Ventilation Inc., 550 Lemire Blvd., Drummondville QC J2C 7W9 1-800-567-3855 REGISTER YOUR PRODUCT ONLINE AT: www.bnv.ca For additional information - visit www.venmar.ca...
- Page 2 WARNING WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR TO REDUCE THE RISK OF INJURY TO PERSONS IN THE INJURY TO PERSONS, OBSERVE THE FOLLOWING: EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWING*: 1. Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer at the address 1.
-
Page 3: Table Of Contents
To contact Venmar Ventilation Inc. Warranty Service call 1-800-567-3855 (in Canada). In order to qualify for a warranty claim, the owner of a Venmar Jazz range hood must have the model and serial number along with a proof of the original purchase date. -
Page 4: Install Ductwork
1. INSTALL DUCTWORK WARNING When performing installation, servicing or cleaning the unit, it is recommended to wear safety glasses and gloves. OOF CAP 6" R OUND DUCT ECORATIVE FLUE Plan where and how the ductwork will be installed. A straight, short duct run will allow the hood to perform most efficiently. Long duct 6"... -
Page 5: Prepare Installation
3. PREPARE INSTALLATION NOTE: Before proceeding to the installation, check the contents of the box. If items are missing or damaged, contact the retailer. Make sure that the following items are included: - Hood - Curved glass panels (installed on the hood) - Micromesh filter - Decorative flue assembly (lower and upper flues) - Lower flue mounting bracket... -
Page 6: Prepare Hood Location
5. PREPARE HOOD LOCATION WARNING • When cutting or drilling into wall, do not damage electrical wiring and other hidden utilities. • When building framework, always follow all applicable construction codes and standards. ALL STUDS RAMING BEHIND 1. Construct wood wall framing that is flush with surface of wall studs. DRYWALL Ensure: a) The framing is centered over installation location and is sturdy... -
Page 7: Install Hood
8. INSTALL HOOD WARNING Be careful when installing the decorative flue and hood, they may have sharp edges. CAUTION DO NOT REMOVE the protective plastic film covering the decorative flue (upper and lower) and the hood yet. 1. Place the hood at its location. Using a pen, mark the position of both keyholes narrow end as well as the position of both additional holes (Fig. -
Page 8: Grease Filter
9. GREASE FILTER To remove grease filter, open the hood front panel (A), then remove the grease filter by pressing down on its metal latch tab and tilting filter downward (B). To reinstall grease filter, align filter tabs with slots in the hood. Press down the metal latch tab, push filter into position and release. - Page 9 10. LIGHT BULBS ( ’ CONT 2. Unplug bulb assembly harness (C). HO0212 3. Squeeze both springs (D) and push light assembly down (E). Remove light assembly from hood and discard. HO0211 4. Install new light assembly by reversing steps 3 to 1. CAUTION •...
-
Page 10: Operation
11. OPERATION Always turn your hood on before you begin cooking to establish an air flow in the kitchen. Let the blower run for a few minutes to clear the air after you turn off the range. This will help keep the whole kitchen cleaner and brighter. -
Page 11: Care
12. CARE Grease Filter Grease filter should be cleaned monthly. Remove grease filter by pressing down on its metal latch tab. This will disengage the filter from the hood. Tilt the filter downward and remove. Use a warm detergent solution to clean the filter. Let it dry and reinstall it. Grease filter is dishwasher safe. -
Page 12: Replacement Parts
Venmar Ventilation Inc. also recommends to contact a Venmar certified service depot for all replacement parts and repairs. HL0202 ART NO ESCRIPTION...
