INSTALLATION INSTRUCTIONS

H E P A 3 . 2 *
*Patents pending
NOTE: HEPA 3.2 model available in Canada only.

READ AND SAVE THESE INSTRUCTIONS

INSTALLER: LEAVE THIS MANUAL WITH CONSUMER.
HOMEOWNER: USE AND CARE INFORMATION
AND USER MANUAL
VB0049
For United States, use Venmar HEPA 1000 model.
RESIDENTIAL USE ONLY
ON PAGES 22, 25, 28, 29 and 30.
M O D E L S
a n d
VB0058
T H H 1 . 0 *
05438
rev E
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HEPA 3.2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Venmar HEPA 3.2

Summary of Contents for Venmar HEPA 3.2

  • Page 1: Installation Instructions

    T H H 1 . 0 * VB0049 VB0058 *Patents pending NOTE: HEPA 3.2 model available in Canada only. For United States, use Venmar HEPA 1000 model. RESIDENTIAL USE ONLY READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH CONSUMER.

  • Page 2: About This Manual

    2.1 For HEPA 3.2 unit only, if a duct has to be connected to the furnace return plenum, it must be connected not closer than 2 ft (0.61 m) from this plenum connection to the furnace.

  • Page 3: Table Of Contents

    HEPA 3.2 Wiring Diagram ........

  • Page 4: Technical Data

    1. TECHNICAL DATA ERFORMANCE HARTS HEPA 3.2 F ILTRATION IRFLOW 1.20 1.00 Low speed 0.80 (Normal mode) 0.60 0.40 High speed (Boost mode) 0.20 0.00 VG0064 Airflow (Cubic Feet per Minute) THH 1.0 V ENTILATION ERFORMANCE PEED 1.20 High Speed EXT.

  • Page 5: Dimensions

    1. TECHNICAL DATA (CONT’D) IMENSIONS HEPA 3.2 THH 1.0 29'' 30.2'' (737 mm) (767 mm) 17.8'' 17.8'' (452 mm) (452 mm) 22.9'' (581 mm) 22.9'' (581 mm) VK0047 VK0049 FRONT VIEW TOP VIEW FRONT VIEW TOP VIEW OUNTING AND ERVICING ONSIDERATIONS •...
  • Page 6 - 6 -...

  • Page 7: Hepa 3.2 Unit Installation

    OUNT THE ORTS ON THE Mount the 8” (HEPA 3.2 unit) oval ports on the top of the unit using the screws provided in the hardware box (4 screws #8 x 3/4” long per port). NOTE: If an optional wall control has to be installed, do not install the front oval port (1) at this time.
  • Page 8 2. HEPA 3.2 UNIT INSTALLATION (CONT’D) ’ OW TO ANG THE CONT • Turn the switch knob to OFF position in order to unlock the door. Unlatch the door and open it. NOTE: If preferred, the door can be removed. First, remove the stopper (A) located on the right side of the door hinge, then, slide the door out of its hinge.

  • Page 9: Planning Of The Ductwork

    2. HEPA 3.2 UNIT INSTALLATION (CONT’D) LANNING OF THE UCTWORK CAUTION Do not attempt to recover the exhaust air from a dryer or a range hood. This would cause clogging of the filters. • Follow the instructions in Section 2.7 below to determine the appropriate duct diameters for your system. Do not use branch lines smaller than 6”ø...

  • Page 10: Installing Ductwork And Registers

    2. HEPA 3.2 UNIT INSTALLATION (CONT’D) NSTALLING UCTWORK AND EGISTERS 2.8.1 S TAND LONE YSTEM Stale air exhaust ductwork WARNING Never install a stale air exhaust register in a closed room where a combustion device operates, such as a gas furnace, a gas water heater or a fireplace.
  • Page 11 2. HEPA 3.2 UNIT INSTALLATION (CONT’D) NSTALLING UCTWORK AND EGISTERS 2.8.2 C ENTRAL OINT Filtered air distribution ductwork (Return side connection) WARNING When performing duct connections, always use approved tools and materials. Respect all corresponding laws and/or safety regulations. Please refer to your local building code.

  • Page 12: Thh 1.0 Unit Installation

    - 12 -...

  • Page 13: How To Hang The Unit

    NOTE: If an optional wall control has to be installed, do not install the front oval port (1) at this time. VO0060 OUNT THE AMEPLATE ON THE Select your company nameplate (Venmar or vänEE) and snap it on the unit door. Discard the other nameplate. VO0049 OW TO...
  • Page 14 3. THH 1.0 UNIT INSTALLATION (CONT’D) ’ OW TO ANG THE CONT • Turn the switch knob to OFF position in order to unlock the door. Unlatch the door and open it. NOTE: If preferred, the door can be removed. First, remove the stopper (A) located on the right side of the door hinge, then, slide the door out of its hinge.

  • Page 15: Planning Of The Ductwork

    3. THH 1.0 UNIT INSTALLATION (CONT’D) LANNING OF THE UCTWORK CAUTION Do not attempt to recover the exhaust air from a dryer or a range hood. This would cause clogging of the filters and the heat recovery core. • Follow the instructions in Section 3.7 below to determine the appropriate duct diameters for your system. Do not use branch lines smaller than 4”ø...

  • Page 16: Installing Ductwork And Registers

    3. THH 1.0 UNIT INSTALLATION (CONT’D) NSTALLING UCTWORK AND EGISTERS 3.8.1 S TAND LONE YSTEM Stale air exhaust ductwork WARNING Never install a stale air exhaust register in a closed room where a combustion device operates, such as a gas furnace, a gas water heater or a fireplace.
  • Page 17 3. THH 1.0 UNIT INSTALLATION (CONT’D) ’ NSTALLING UCTWORK AND EGISTERS CONT 3.8.2 C ENTRAL OINT NOTE: For this type of installation, it is not essential that the furnace blower runs when the unit is in operation, but we recommend it. Fresh / Filtered air distribution ductwork (Return side connection) WARNING When performing duct connections, always use approved tools and materials.

  • Page 18: Installing Insulated Flexible Duct

    3. INSTALLATION OF THE THH 1.0 UNIT (CONT’D) NSTALLING NSULATED LEXIBLE UCTS CAUTION Make sure the vapor barrier on the insulated ducts does not tear during installation. Use the following procedure for connecting the insulated flexible ducts to the Tandem® transition* ( EXHAUST AIR TO OUTSIDE and FRESH AIR FROM OUTSIDE ).
  • Page 19 3. INSTALLATION OF THE THH 1.0 UNIT (CONT’D) ’ NSTALLING NSULATED LEXIBLE UCTS CONT 3.9.2 C 5’’ 6’’ ONNECTION TO THE OVAL PORTS OF THE UNIT Use the following procedure for connecting the insulated flexible ducts to the 5’’ to 6’’ oval ports of the unit ( EXHAUST AIR TO OUTSIDE and FRESH AIR FROM OUTSIDE ).

  • Page 20: Installing Dual Exterior Hood

    3. INSTALLATION OF THE THH 1.0 UNIT (CONT’D) 3.10 NSTALLING XTERIOR 3.10.1 A SSEMBLING XTERIOR Exterior dual hood comes in separate parts. Using 2 #8 x 3/4” screws, assemble the top metal screen and the plastic grille to the dual exterior hood. Then, slide the bottom metal screen to the dual exterior hood.

  • Page 21: Connecting The Drain

    3. INSTALLATION OF THE THH 1.0 UNIT (CONT’D) 3.10 ’ NSTALLING XTERIOR CONT 3.10.3 C ® ’ ONNECTING ANDEM TRANSITION TO THE UAL EXTERIOR CONT 3. Lean the exterior backplate to the exterior wall. Using 4 #8 x 1 1/2” screws, fix it to the wall. Seal the outline with caulking.

  • Page 22: Controls

    VC0053 PTIONAL ONTROLS The optional wall control part number for the HEPA 3.2 unit is 04862 (for Venmar unit) or 05439 (for vänEE unit). The optional wall control part number for the THH 1.0 unit is 04391 (for Venmar unit) or 05536 (for vänEE unit).
  • Page 23 Failure to follow these practices can introduce electrical interference, which can cause erratic control operations. 6. Route the cable to the unit. 7. If it is not done yet, remove the front 8’’ (HEPA 3.2 unit) or the 5” to 6” (THH 1.0 unit) oval port (1). VO0045 VO0060 HEPA 3.2 unit...

  • Page 24: Installation Of The Optional Wall Control

    See picture beside. VD0089 13. If the installation is not completed, return to Section 2 on page 8 ( for HEPA 3.2 unit) or Section 3 on page 13 (for THH 1.0 unit). If the installation is completed, plug the unit.

  • Page 25: Operating The #04862 Or #05439 Control

    4. CONTROLS (CONT’D) #04862 #05439 C PERATING ONTROL 4.5.1 #04862 #05439 C ONTROL DESCRIPTION OWER INDICATOR BOOST: LIGHTS UP WHEN SLIDE SWITCH NIT IS OPERATING ON NORMAL BOOST IS ON HIGH SPEED POSITION ORMAL ILTER MAINTENANCE NIT IS OPERATING ON INDICATOR NORMAL SPEED FLASHES EVERY MINUTE TO...

  • Page 26: Wiring Diagrams

    5. WIRING DIAGRAMS WARNING Risk of electrical shocks. Before performing any maintenance or servicing, always disconnect the unit from its power source. HEPA 3.2 W IRING IAGRAM Critical characteristic Access panel 120V, 60Hz 120V, 60Hz mechanical interlock Field wiring Ground...

  • Page 27: Balancing Procedure (Thh 1.0 Only)

    6. BALANCING PROCEDURE (THH 1.0 ONLY) EED TO ALANCE THE • A magnehelic gauge capable of measuring 0 to 0.5 inches water gauge (0 to 125 Pa) and 2 plastic tubes. • Two flow collars (the size will vary depending of duct diameter). Flow collar VP0005 RELIMINARY...

  • Page 28: Maintenance

    7. MAINTENANCE WARNING Risk of electrical shocks. Before performing any maintenance or servicing, always disconnect the unit from its power source. ANNUAL AINTENANCE ESSENTIAL If your unit is equipped with an optionnal wall control (04862 / 05439 or 04391 / 05536) you should perform this maintenance when the Filter Maintenance light is flashing.

  • Page 29: Annual Maintenance

    7. MAINTENANCE (CONT’D) ’ ANNUAL AINTENANCE ESSENTIAL CONT For THH unit only Wash the 2 core filters under hot water with mild soap. Soak the core in a solution of warm water and mild soap. Rinse the core filters and the core thoroughly and let dry before reinstalling them in the unit.

  • Page 30: Parts Ordering Chart

    To contact warranty service call 1-800-567-3855. In order to qualify for a warranty claim, the owner of a Venmar or vänEE whole-house HEPA air purifier system must have the model and serial number along with a proof of the original purchase date. In each case, costs for the removal of a defective part (and/or unit) and installation of a new or repaired one and travel costs are not covered by this warranty.
