INSTALLATION INSTRUCTIONS AND USER MANUAL
HB0010
CONNAISSEUR 3000 SERIES
INTENDED FOR DOMESTIC COOKING ONLY
!
!
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGES 9 TO 11.
Venmar Ventilation inc., 550 Lemire Blvd., Drummondville, Qc., Canada J2C 7W9 Tel.: 1-800-567-3855 Fax: 1-800-567-1715
www.venmar-ventilation.com
03506 rev E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CONNAISSEUR 3000 SERIES and is the answer not in the manual?

Questions and answers

Bill Nowostawsky
April 21, 2025

How do i replace halogen lights on a Venmar Connaisseur Model CC321

0
1 comments:
Mr. Anderson
May 11, 2025

To replace halogen lights on a Venmar Connaisseur 3000 Series model CC321:

1. Use 50W PAR20 halogen lamps.
2. Insert the lamp into the socket holder.
3. Rotate the lamp clockwise until it is securely in place.

This answer is automatically generated

0

Related Manuals for Venmar CONNAISSEUR 3000 SERIES

Summary of Contents for Venmar CONNAISSEUR 3000 SERIES

  • Page 1 READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: USE AND CARE INFORMATION ON PAGES 9 TO 11. Venmar Ventilation inc., 550 Lemire Blvd., Drummondville, Qc., Canada J2C 7W9 Tel.: 1-800-567-3855 Fax: 1-800-567-1715 www.venmar-ventilation.com 03506 rev E...
  • Page 2 WARNING WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC TO REDUCE THE RISK OF INJURY TO SHOCK OR INJURY TO PERSONS, OBSERVE PERSONS IN THE EVENT OF A RANGE TOP THE FOLLOWING: GREASE FIRE, OBSERVE THE FOLLOWING*: Use this unit only in the manner intended by the SMOTHER FLAMES with a close-fitting lid, manufacturer.
  • Page 3 CONNAISSEUR 3000 SERIES Standard 8” duct (not included) 13282 Standard 3 1/4” x 10” to 8” transition 3 1/4” x 10” duct (not included) (not included) Adapter and damper (supplied with hood) Flow deviator (vertical exhaust only) (supplied with hood) 3000 SERIES RANGE HOOD CBS Series Backsplash CBF Series Baffle filter...

  • Page 4: Install Ductwork

    1. INSTALL DUCTWORK 2. MEASURE INSTALLATION Plan where and how the ductwork will be installed. Dimensions for the most common installations are shown below. Install proper-sized ductwork, elbows and roof or wall cap for the type of blower you are installing. If Te minimum hood distance above the cooktop using 8”...

  • Page 5: Prepare The Installation

    3. PREPARE THE INSTALLATION Make sure that the following items are included: -Hood -Filters -Bag of parts including : (1) wire clamp, (8) 1/2’’ double thread screws, (2) wire connectors, (2) 1/2’’ standard screws. -Adapter/damper assembly 3-1/4’’ x 10’’ -Deviator Parts sold separately: - Halogen lights (120V, 50W, PAR 20) - Heat lamps (120V, IR 175W, PAR 38)

  • Page 6: Install The Adapter

    5. CHOOSE THE OPENING AND INSTALL THE DEVIATOR Remove the knockout for the chosen opening (horizontal or vertical) at the back or on top of the hood and for electric connection. YOU MUST also install the deviator if you choose the vertical opening (see picture below).

  • Page 7: Install The Hood

    7. INSTALL THE HOOD Run power cable to installation location. Place the hood at its location. Mark the position of the screws (smaller part of the key holes) with a pen. Remove the hood and install the (8) 1/2” double thread screws leaving a 1/8”...

  • Page 8: Install Filters

    11. INSTALL FILTERS CAUTION Remove protective plastic film covering filters before installing them. It is recommended to install side filters first and finish with center one(s). Install as follows: MESH FILTER INSTALLATION Insert upper end of filter into the hood (finger sized cup side). Raise lower end toward the inside of hood.

  • Page 9: Use And Care

    USE AND CARE Filters and impeller(s) The grease filters, impeller(s) and grease collector channel should be cleaned frequently. Use a warm detergent solution. Impeller(s) are dishwasher safe. NOTE: It is not recommended to wash the grease filters in the dishwasher, because some minerals, when in contact with dishwasher soap additives, may cause a discoloration of the filters.

  • Page 10: Operation

    Hood cleaning Stainless steel cleaning: How to maintain its « BRIGHT LOOK » - Regularly wash surfaces with clean cloth or rag soaked with warm water and mild soap or liquid dishwashing detergent. - Always clean in the direction of original polish lines. - Always rinse well with clear water (2 or 3 times) after cleaning.
  • Page 11 1. Delay switch: When a speed is selected, press the delay switch to activate the delay function. The corresponding speed indicator light will start flashing to indicate this function is activated. The fan will continue to operate for 5 minutes and will stop automatically. To cancel the delay function, press the delay switch once again.

  • Page 12: Technical Specifications

    TECHNICAL SPECIFICATIONS Transformer 120 Vac, 60 Hz Lights 30”, 36” 42”, 48” Size PAR20 2 x 50W 3 x 50W Halogen bulbs Heat lamps 120V, IR 175W, 2 x 175W PAR 38 Infrared bulbs or Halogen lamps 2 x 90W 120V, 90W, PAR 38 Blower: single P5...

  • Page 13: Warranty

    ORIGINAL PURCHASE PRICE OF A CONNAISSEUR RANGE HOOD, NOR HELD RESPONSIBLE FOR SUBSEQUENT DAMAGE OR INCIDENT. During the period stated above, Venmar Ventilation inc. will, at its opinion, repair or replace, without charge, any product or part which is found to be defective under normal use and service. THIS WARRANTY DOES NOT EXTEND TO ANY LIGHT BULBS.

  • Page 14: Wiring Diagrams

    WIRING DIAGRAMS HALOGEN LAMP (50W PAR20) CONTROL BOARD M2S PC48492-3 HALOGEN LAMP (50W PAR20) J1-3 LOGIC LOGIC REFER- MOTOR K1 NO ENCE GROUND 165W CW K1 NC K2 NO J2-4 K2 NC K3 NO Connaisseur 30” and 36” single blower CAPACITOR AUTOTRANSFORMER 120 VAC...

  • Page 15: Service Parts

    SERVICE PARTS 3000 SERIES SINGLE BLOWER PART DESCRIPTION NUMBER 30” 36” 02264 LIGHT SOCKET 02772 FEMALE CONNECTOR 02563 SPST CARLING SIMPLE SWITCH 03597 ELECTRONIC CONTROL BOARD 02802 MALE/FEMALE NYLON SPACER 1/4” x 9/16” #6-32 03580 NYLON SPACER #6-32x1/2” 02414 AUTO TRANSFORMER 165W 03521 10"...
  • Page 16 SERVICE PARTS 3000 SERIES DUAL BLOWER PART DESCRIPTION NUMBER 36” 42” 48” 02264 LIGHT SOCKET 02772 FEMALE CONNECTOR 02563 SPST CARLING SIMPLE SWITCH 03597 ELECTRONIC CONTROL BOARD 02802 MALE/FEMALE NYLON SPACER 1/4” x 9/16” #6-32 03580 NYLON SPACER #6-32x1/2” 02414 AUTO TRANSFORMER 165W 03521 10"...
