Syscom Video XD1000VA Instruction Manual page 14

The IMAGE menu provides the ability to adjust the SHARPNESS, LSC, D-EFFECT, DIS, D-ZOOM
and SMART D-ZOOM functions of the camera.
1) SHARPNESS
2) LSC
3) D-EFFECT
4) DIS
5) D-ZOOM
5) SMART D-ZOOM
LENS
EXPOSURE
BACK LIGHT
WHITE BAL
DAY&NIGHT
FUNCTION
SYSTEM
RESET
EXIT
<SMART D-ZOOM>
SHARPNESS
LSC
D-EFFECT
DIS
D-ZOOM
SMART D-ZOOM
RETURN
Adjust the SHARPNESS level. ▶ 0 - 15
Select the lens Lens Shading Compensation. ▶ ON, OFF
Select real or still mode ▶ ON, OFF
FREEZE
MIRROR Select OFF, MIRROR, V-FLIP, ROTATE
NEG. IMAGE
Select the Digital Image Stability ▶ ON, OFF
Adjust the Digital Zoom level. ▶ x1.0 - x62.0
* When D-ZOOM is ON, SMART D-ZOOM and DIS function can not turn on.
Adjust the Smart Digital Zoom area, level, sensitivity and time.
* When D-ZOOM is ON, D-ZOOM and DIS function can not turn on.
Select the Smart D-zoom Area ▶ AREA1, AREA2
SELECT
Select the Smart D-zoom Area display ▶ ON, OFF
DISPLAY
Adjust the Smart D-zoom Sensitivity ▶ 0 - 60
SENSITIVITY
Adjust the Digital Zoom level ▶ x1.0 - x62.0
D-ZOOM
Adjust time level ▶ 0 - 15 (sec)
TIME
MAIN MANU
DC
OFF
ATW
AUTO
| I | 8 ▪▪ ▪▪
OFF
OFF
OFF
OFF
OFF
RET
Select Negative image mode ▶ ON, OFF
SHARPNESS | I | 8 ▪▪ ▪▪
LSC OFF
D-EFFECT OFF
DIS OFF
D-ZOOM OFF
SMART D-ZOOM OFF
RETURN RET
SMART D-ZOOM
SELECT AREA1
DISPALY ON
SENSITIVITY |▪▪▪I▪| 60
D-ZOOM x2.8
TIME |▪I▪▪▪| 3
DEFAULT
RETURN RET
