CDF18, CDF25, CDF35,
CDF45
DE
4
Kompressor-Kühlbox
Bedienungsanleitung
EN
17
Compressor Cooler
Instruction Manual
FR
30
Glacière à compression
Manuel d'utilisation
ES
44
Nevera por compresor
Instrucciones de uso
IT
58
Frigorifero a compressore
Istruzioni per l'uso
NL
72
Compressorkoelbox
Gebruiksaanwijzing
DA
85
Kompressor-køleboks
Betjeningsvejledning
SV
98
Kylbox med kompressor
Bruksanvisning
CDF18
CDF25
NO
111 Kjøleboks med kompressor
Bruksanvisning
FI
124 Kompressori-kylmälaatikko
Käyttöohje
PT
137 Geleira com compressor
Manual de instruções
RU
151 Компрессорный
холодильник
Инструкция по эксплуатации
PL
166 Lodówka kompresorowa
Instrukcja obsługi
CS
179 Kompresorový chladicí box
Návod k obsluze
SK
192 Chladiaci box s kompresorom
Návod na obsluhu
CDF45
CDF35
Advertisement
Table of Contents
Related Manuals for Waeco CDF18
Summary of Contents for Waeco CDF18
- Page 1 CDF45 CDF35 CDF25 CDF18 CDF18, CDF25, CDF35, CDF45 Kompressor-Kühlbox 111 Kjøleboks med kompressor Bedienungsanleitung Bruksanvisning Compressor Cooler 124 Kompressori-kylmälaatikko Instruction Manual Käyttöohje Glacière à compression 137 Geleira com compressor Manuel d’utilisation Manual de instruções Nevera por compresor 151 Компрессорный Instrucciones de uso холодильник...
- Page 2 CoolFreeze ERROR BATTERY MONITOR TEMPERATUR POWER HIGH COLD FREEZE CDF25, CDF35, CDF45 12/24V DC CDF25, CDF35, CDF45...
- Page 3 CoolFreeze TEMPERATURE BATTERY MONITOR ERROR HIGH POWER COLD FREEZE 12/24V DC CDF18 CDF25...
-
Page 4: Table Of Contents
CoolFreeze Explanation of symbols Please read this operating manual carefully before starting the device. Keep it in a safe place for future reference. If the device is passed on to another person, this operating manual must be handed over to the user along with it. The manufacturer cannot be held liable for damage resulting from improper usage or incorrect operation. -
Page 5: Safety Instructions
Safety instructions CoolFreeze NOTICE! Failure to observe this instruction can cause material damage and impair the function of the product. NOTE Supplementary information for operating the product. ➤ Action: This symbol indicates that action is required on your part. The required action is described step-by-step. ✓... - Page 6 CoolFreeze Safety instructions Do not store any explosive substances such as spray cans with propellants in the device. CAUTION! Disconnect the device from the mains – before cleaning and maintenance – after use Food may only be stored in its original packaging or in suitable containers.
-
Page 7: Scope Of Delivery
Operating manual Accessories To operate the device at the AC mains supply, we recommend using one of the following WAECO rectifiers. Available as accessory (not included in scope of delivery): – 220–240 V: CoolPower EPS100 or EPS817 – 110–240 V: CoolPower MPS35... -
Page 8: Intended Use
(e. g. cigarette lighter), boat or caravan. NOTE To operate the device at the AC mains supply, we recommend us- ing one of the following WAECO rectifiers: 220–240 V: CoolPower EPS100 or EPS817 110–240 V: CoolPower MPS35 CAUTION! Health hazard! Please check if the cooling capacity of the device is suitable for storing the food or medicine you wish to cool. - Page 9 (fig. 2, page 2, fig. 3, page 2, fig. 4, page 3): Description Explanation TEMPERATURE Temperature controller, cooling temperature at the end positions: COLD: +10 °C FREEZE: CDF18, CDF25: –18 °C CDF35, CDF45: –15 °C POWER Operating display LED is lit green: Device is switched...
-
Page 10: Operation
CoolFreeze Operation Operation Before initial use NOTE Before starting your new cooler for the first time, you should clean it inside and outside with a damp cloth for hygienic reasons (please also refer to the “Cleaning and maintenance” on page 27). Energy saving tips ... - Page 11 Operation CoolFreeze Using the battery monitor If the cooler is operated when the vehicle ignition is switched off, the cooler switches off automatically as soon as the supply voltage falls below a set level. The cooler will switch back on once the bat- tery has been recharged to the restart voltage level.
- Page 12 ✓ The “POWER” LED is lit green. ✓ The cooler starts cooling the interior. ➤ Set the cooling temperature with the temperature controller “TEMPERATURE”. ✓ CDF18 only: When the cooling temperature has been reached, the “POWER” LED is lit yellow.
- Page 13 Operation CoolFreeze Switching off the cooler ➤ Empty the cooler. ➤ To Switch the cooler off: Slide the sliding switch “BATTERY MONITOR” to “0”: ➤ Pull out the connection cable. If you do not want to use the cooler for a longer period of time: ➤...
-
Page 14: Cleaning And Maintenance
CoolFreeze Cleaning and maintenance Replacing the light bulb (CDF25 only) ➤ Press the switch pin (fig. 7 2, page 3) downwards so that the transparent part (fig. 7 1, page 3) of the lamp can be removed at the front. ➤... -
Page 15: Troubleshooting
Troubleshooting CoolFreeze Troubleshooting Fault Possible cause Suggested remedy Device does not There is no voltage The ignition must be switched on in most function, LED does present in the 12/24 V vehicles to apply current to the cigarette not glow. socket (cigarette lighter) lighter. -
Page 16: Disposal
If you wish to finally dispose of the product, ask your local recycling centre or specialist dealer for details about how to do this in accordance with the applicable disposal regulations. Technical data WAECO CoolFreeze CDF18 CDF25 CDF35 CDF45 Art.-Nr.:... - Page 17 GERMANY Dometic WAECO International GmbH Hollefeldstraße 63 · D-48282 Emsdetten +49 (0) 2572 879-195 · +49 (0) 2572 879-322 Mail: info@dometic-waeco.de · Internet: www.dometic-waeco.de AUSTRALIA ITALY SWITZERLAND Dometic Australia Pty. Ltd. Dometic Italy S.r.l. Dometic Switzerland AG 1 John Duncan Court...
