  • Page 1 CFX35, CFX40, CFX50, CFX65, CFX65DZ Compressor Cooler Instruction Manual...

  • Page 3: Table Of Contents

    CFX35 – CFX65DZ Please read this operating manual carefully before starting the device. Keep it in a safe place for future reference. If the device is passed on to another person, this operating manual must be handed over to the user along with it.

  • Page 4: Explanation Of Symbols

    Explanation of symbols CFX35 – CFX65DZ Explanation of symbols DANGER! Safety instruction: Failure to observe this instruction will cause fatal or serious injury. WARNING! Safety instruction: Failure to observe this instruction can cause fatal or serious injury. CAUTION! Safety instruction: Failure to observe this instruction can lead to injury.
  • Page 5 CFX35 – CFX65DZ Safety instructions WARNING!  Do not operate the device if it is visibly damaged.  This device may only be repaired by qualified personnel. Improper repairs can lead to considerable hazards.  Persons (including children) whose physical, sensory or mental...

  • Page 6: Operating The Device Safely

    Safety instructions CFX35 – CFX65DZ  If the cooler is connected to the DC socket: Disconnect the cooler or switch it off when you turn off the engine. Otherwise you may discharge the battery. Operating the device safely DANGER!  Do not touch exposed cables with your bare hands. This especially applies when operating the device with an AC mains power supply.

  • Page 7: Scope Of Delivery

    CFX35 – CFX65DZ Scope of delivery Scope of delivery Item Quantity Description Cooler Connection cable for 12/24 Vg connection Connection cable for 100–240 V connection – Operating manual Accessories Available as accessory (not included in scope of delivery): Designation Item no.

  • Page 8: Intended Use

    Intended use CFX35 – CFX65DZ Intended use The cooler is suitable for cooling and freezing foods. The device is also suitable for use on boats. The device is designed to be operated from a 12 V or 24 V board supply socket of a vehicle (e. g. cigarette lighter), boat or caravan as well as from a 100–240 V AC mains.

  • Page 9: Operating And Display Elements

    CFX35 – CFX65DZ Function description Operating and display elements Latch for lid, fig. 2 1 CFX35, CFX40 CFX50, CFX65, CFX65DZ Operating panel, fig. 3 – ° Item Description Explanation Switches the cooler on or off when the button is pressed for between one and two seconds “P“...
  • Page 10 Function description CFX35 – CFX65DZ Item Description Explanation Selects the input mode – Temperature setting – Celsius or Fahrenheit display – Set battery monitor – Display, shows the information DOWN – Press once to decrease the value UP + Press once to increase the value Connection sockets, fig.

  • Page 11: Operation

    CFX35 – CFX65DZ Operation Operation Before initial use NOTE Before starting your new cooler for the first time, you should clean it inside and outside with a damp cloth for hygienic reasons (please also refer to the “Cleaning and maintenance” on page 19).

  • Page 12: Energy Saving Tips

    Operation CFX35 – CFX65DZ Selecting the temperature units Temperature display units can be switched between Celsius and Fahrenheit as follows: ➤ Switch on the cooler. ➤ Press the “SET” button (fig. 3 4, page 9) twice. ➤ Use the “UP +” (fig. 3 7, page 9) or “DOWN -” (fig. 3 6, page 9) buttons to select Celsius or Fahrenheit.

  • Page 13: Using The Battery Monitor

    CFX35 – CFX65DZ Operation Connecting to a 100–240 V AC mains (E.g. in the home or office) DANGER! Danger of electrocution!  Never handle plugs and switches with wet hands or if you are standing on a wet surface.  If you are operating your cooler on board a boat from a mains connection of 100–240 V~, you must install a residual current...

  • Page 14: Using The Cooler

    Operation CFX35 – CFX65DZ In “HIGH” mode, the battery monitor responds faster than at the levels “LOW” and “MED” (see the following table). Battery monitor mode HIGH Switch-off voltage at 12 V 10.1 V 11.4 V 11.8 V Restartvoltage at 12 V 11.1 V...
  • Page 15 CFX35 – CFX65DZ Operation NOTE Place the cooler as shown (fig. 1, page 7).If you operate the box in a different position it can be damaged. ➤ Close the cooler, see “Connecting the cooler” on page 12. NOTICE! Danger from excessively low temperature! Ensure that the only those objects are placed in the cooler that are intended to be cooled at the selected temperature.

  • Page 16: Setting The Temperature

    Operation CFX35 – CFX65DZ Setting the temperature ➤ Press the “SET” button (fig. 3 4, page 9) once. ➤ Use the “UP +” (fig. 3 7, page 9) and “DOWN -” (fig. 3 6, page 9) buttons to select the cooling temperature.

  • Page 17: Defrosting The Cooler

    CFX35 – CFX65DZ Operation 6.10 Defrosting the cooler Humidity can form frost in the interior of the cooling device or on the evaporator. This reduces the cooling capacity. Defrost the device in good time to avoid this. NOTICE! Danger of damage! Never use hard or pointed tools to remove ice or to loosen objects which have frozen in place.

  • Page 18: Replacing The Plug Fuse (12/24 V)

    Operation CFX35 – CFX65DZ 6.12 Replacing the plug fuse (12/24 V) ➤ Turn anticlockwise the cap (fig. 7 1) to move it and pin (fig. 7 2) from the plug. ➤ Press one end of the fuse (fig. 7 3) and take it out.

  • Page 19: Cleaning And Maintenance

    CFX35 – CFX65DZ Cleaning and maintenance Cleaning and maintenance WARNING! Always disconnect the device from the mains before you clean and service it. NOTICE! Risk of damage  Never clean the cooler under running water or in dish water.  Do not use abrasive cleaning agents or hard objects during cleaning as these can damage the cooler.

  • Page 20: Troubleshooting

    Troubleshooting CFX35 – CFX65DZ Troubleshooting Fault Possible cause Suggested remedy Device does not func- There is no voltage pre- The ignition must be switched on in most tion, LED does sent in the 12/24 V vehicles to apply current to the cigarette not glow.

  • Page 21: Disposal

    CFX35 – CFX65DZ Disposal Disposal ➤ Place the packaging material in the appropriate recycling waste bins wherever possible. If you wish to finally dispose of the product, ask your local recycling centre or specialist dealer for details about how to do this in accordance with the applicable disposal regulations.
  • Page 22 Technical data CFX35 – CFX65DZ CFX50 CFX65 CFX65DZ Item no. 9105303572 9105303573 9105303574 Connection volt- 12/24 V and 100–240 V age: Rated current: 12 V : 7,8 A 12 V : 8,2 A 12 V : 5,5 A 24 Vg: 3,6 A...
