Onboard Devices Configuration

Onboard Devices Configuration Onboard Devices Configuration
5.4.3 5.4.3 Onboard Devices Configuration Onboard Devices Configuration
Advanced
Configure Onboard Devices
Serial Port1 Address

Parallel Port Address

Parallel Port Mode
ECP Mode DMA Channel
Parallel Port IRQ
Onboard Firewire Device
Onboard LAN
Onboard LAN Boot ROM
v02.58 (C)Copyright 1985-2004, American Megatrends, Inc.

Serial Port1 Address [3F8/IRQ4]

Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4]
[2E8/IRQ3]
Parallel Port Address [378] Parallel Port Address [378] Parallel Port Address [378]
Parallel Port Address [378] Parallel Port Address [378]
Allows you to select the Parallel Port base addresses.
Configuration options: [Disabled] [378] [278] [3BC]
Parallel Port Mode [ECP] Parallel Port Mode [ECP] Parallel Port Mode [ECP]
Parallel Port Mode [ECP] Parallel Port Mode [ECP]
Allows you to select the Parallel Port mode.
Configuration options: [Bi-directional] [EPP] [ECP]
ECP Mode DMA Channel [DMA3]
Appears only when the Parallel Port Mode is set to [ECP]. This item
allows you to set the Parallel Port ECP DMA.
Configuration options: [DMA0] [DMA1] [DMA3]
EPP Version [1.9]
Allows selection of the Parallel Port EPP version. This item appears
only when the P a r a l l e l P o r t M o d e
Configuration options: [1.9] [1.7]
Parallel Port IRQ [IRQ7]
Allows selection of the Parallel Port IRQ.
Configuration options: [IRQ5] [IRQ7]
5 - 2 2 5 - 2 2 5 - 2 2 5 - 2 2 5 - 2 2
BIOS SETUP UTILITY
