Primary IDE Master/Slave,

Primary IDE Master/Slave, Primary IDE Master/Slave,
5.3.4 5.3.4 Primary IDE Master/Slave, Primary IDE Master/Slave,

Serial ATA Ports 1 ~ 4

Serial ATA Ports 1 ~ 4 Serial ATA Ports 1 ~ 4 Serial ATA Ports 1 ~ 4 Serial ATA Ports 1 ~ 4
While entering Setup, the BIOS automatically detects the presence of IDE
devices. There is a separate sub-menu for each IDE device. Select a device
item then press <Enter> to display the IDE device information.
Main
Primary IDE Master
Device
Vendor
Size
LBA Mode
Block Mode
PIO Mode
Async DMA
Ultra DMA
SMART Monitoring
Type
LBA/Large Mode
Block(Multi-sector Transfer) M [Auto]
PIO Mode
DMA Mode
SMART Monitoring
32Bit Data Transfer
v02.58 (C)Copyright 1985-2004, American Megatrends, Inc.
The BIOS automatically detects the values opposite the dimmed items
(Device, Vendor, Size, LBA Mode, Block Mode, PIO Mode, Async DMA, Ultra
DMA, and SMART monitoring). These values are not user-configurable.
These items show N/A if no IDE device is installed in the system.
Type [Auto] Type [Auto]
Type [Auto] Type [Auto] Type [Auto]
Selects the type of IDE drive. Setting to Auto allows automatic selection of
the appropriate IDE device type. Select CDROM if you are specifically
configuring a CD-ROM drive. Select ARMD (ATAPI Removable Media Device)
if your device is either a ZIP, LS-120, or MO drive. Configuration options:
[Not Installed] [Auto] [CDROM] [ARMD]

LBA/Large Mode [Auto]

LBA/Large Mode [Auto]
LBA/Large Mode [Auto] LBA/Large Mode [Auto] LBA/Large Mode [Auto]
Enables or disables the LBA mode. Setting to Auto enables the LBA mode if
the device supports this mode, and if the device was not previously
formatted with LBA mode disabled. Configuration options: [Disabled]
[Auto]
Block (Multi-sector Transfer) [Auto] Block (Multi-sector Transfer) [Auto] Block (Multi-sector Transfer) [Auto] Block (Multi-sector Transfer) [Auto] Block (Multi-sector Transfer) [Auto]
Enables or disables data multi-sectors transfers. When set to Auto, the
data transfer from and to the device occurs multiple sectors at a time if
the device supports multi-sector transfer feature. When set to [Disabled],
the data transfer from and to the device occurs one sector at a time.
Configuration options: [Disabled] [Auto]
A S U S T 2 - P E 1 A S U S T 2 - P E 1 A S U S T 2 - P E 1 A S U S T 2 - P E 1 A S U S T 2 - P E 1
BIOS SETUP UTILITY
: Hard Disk
: ST320410A
: 20.0GB
: Supported
: 16 Sectors
: 4
: MultiWord DMA-2
: Ultra DMA-5
: Supported
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Disabled]
Select the type of
device connected to
the system.
Select Screen
Select Item
+-
Change Option
F1 General Help
F10 Save and Exit
ESC Exit
5 - 1 5 5 - 1 5 5 - 1 5 5 - 1 5 5 - 1 5
