2.10 Installing a hard disk drive (HDD)

The system supports one Ultra ATA/133 IDE or one Serial ATA hard disk
drive.
To install an IDE hard disk drive:
1. Locate the HDD tray lock screw
on the other side of the chassis.
2. Remove the lock screw with a
Philips screw driver. Keep the
screw for later use.
3. Slide the HDD tray outward until
the tray slots are released from
the chassis hooks.
4. Place a hard disk drive on the
tray with its bottom on the
open side. Align the HDD and
HDD tray screw holes.
5. Secure the HDD with four
screws.
Configure your hard disk drive as Master device before connecting the
IDE cable and power plug. Refer to the HDD documentation on how to
set the drive as a Master device.
2 - 2 0 2 - 2 0 2 - 2 0 2 - 2 0 2 - 2 0
1 1 1 1 1
2 2 2 2 2
T r a y l o c k s T r a y l o c k s T r a y l o c k s T r a y l o c k s T r a y l o c k s
5 5 5 5 5
5 5 5 5 5
C h a p t e r 2 : B a s i c i n s t a l l a t i o n C h a p t e r 2 : B a s i c i n s t a l l a t i o n C h a p t e r 2 : B a s i c i n s t a l l a t i o n C h a p t e r 2 : B a s i c i n s t a l l a t i o n C h a p t e r 2 : B a s i c i n s t a l l a t i o n
T r a y l o c k s T r a y l o c k s T r a y l o c k s T r a y l o c k s T r a y l o c k s
3 3 3 3 3
L o c k s l o t s L o c k s l o t s L o c k s l o t s
L o c k s l o t s L o c k s l o t s
4 4 4 4 4
