8 . 8 . 8 . 8 . I n t e r n a l a u d i o c o n n e c t o r s ( 4 - p i n A U X , C D ) I n t e r n a l a u d i o c o n n e c t o r s ( 4 - p i n A U X , C D ) I n t e r n a l a u d i o c o n n e c t o r s ( 4 - p i n A U X , C D )
8 . I n t e r n a l a u d i o c o n n e c t o r s ( 4 - p i n A U X , C D ) I n t e r n a l a u d i o c o n n e c t o r s ( 4 - p i n A U X , C D )
These connectors allow you to receive stereo audio input from sound
sources such as a CD-ROM, TV tuner, or MPEG card.
Internal audio connectors
9 . 9 . 9 . F l o p p y d i s k d r i v e c o n n e c t o r ( 3 4 - 1 p i n F L O P P Y ) F l o p p y d i s k d r i v e c o n n e c t o r ( 3 4 - 1 p i n F L O P P Y )
9 . 9 . F l o p p y d i s k d r i v e c o n n e c t o r ( 3 4 - 1 p i n F L O P P Y ) F l o p p y d i s k d r i v e c o n n e c t o r ( 3 4 - 1 p i n F L O P P Y ) F l o p p y d i s k d r i v e c o n n e c t o r ( 3 4 - 1 p i n F L O P P Y )
This connector is for the provided floppy disk drive (FDD) signal cable.
Insert one end of the cable to this connector, then connect the other
end to the signal connector at the back of the floppy disk drive.
Floppy disk drive connector
Pin 5 on the connector is removed to prevent incorrect cable connection
when using an FDD cable with a covered Pin 5.
4 - 8 4 - 8 4 - 8 4 - 8 4 - 8
CD
(black)
¤
¤
NOTE: Orient the red markings on
the floppy ribbon cable to PIN 1.
C h a p t e r 4 : M o t h e r b o a r d i n f o C h a p t e r 4 : M o t h e r b o a r d i n f o C h a p t e r 4 : M o t h e r b o a r d i n f o C h a p t e r 4 : M o t h e r b o a r d i n f o C h a p t e r 4 : M o t h e r b o a r d i n f o
AUX
(white)
FLOPPY
PIN 1
