Installation instructions
DishDrawer®
DD605
Important!
SAVE THESE INSTRUCTIONS
The models shown in this document may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, please go to our
website www.fisherpaykel.com or contact your local Fisher & Paykel dealer.
1

SAFETY AND WARNINGS

Electrical hazard
Before installing the DishDrawer® , remove the house fuse or open the circuit breaker.
If permanently connecting the DishDrawer®, be sure the power is isolated and the DishDrawer® unplugged.
This appliance must be earthed. In the event of a malfunction or breakdown, earthing will reduce the risk of electric shock by providing a path of least resistance for electric current. This appliance is
equipped with a cord having an equipment-earthing conductor and an earthing plug. The plug must be plugged into an appropriate outlet that is installed and earthed in accordance with all local
codes and ordinances. Improper connection of the equipment-earthing conductor can result in a risk of electric shock. Check with a quali ed electrician or service representative if you are in doubt
as to whether the appliance is properly earthed.
Do not modify the power supply plug provided with the appliance - if it will not t the outlet, have a proper outlet installed by a quali ed electrician. Do not use an extension cord, adapter plug or
multiple outlet box.
Failure to do so may result in electrical shock or death.
Cut hazard
Take care - panel edges are sharp.
Failure to use caution could result in injury or cuts.
Important safety precautions!
Installation of this DishDrawer® requires basic mechanical and electrical skills.
Be sure to leave these Instructions with the Customer.
Installation must comply with your local building and electricity regulations.
At the completion of the DishDrawer® installation, the Installer must perform
Final Check List.
Remove all packaging materials supplied with the DishDrawer®.
This DishDrawer® is manufactured for indoor use only.
Ensure all water connections are turned OFF. It is the responsibility of the plumber and
electrician to ensure that each installation complies with all Codes and Regulations.
The DishDrawer® MUST be installed to allow for future removal from the enclosure if service is required.
WARNING!
WARNING!
The switched power outlet must be outside the DishDrawer® cavity so that it is accessible after installation.
Care should be taken when the appliance is installed or removed to reduce the likelihood of damage to the
power supply cord.
If the DishDrawer® is to be relocated from one installation to another it must be kept upright to avoid
damage from water spillage.
Make sure only new hoses are used for connection (supplied with DishDrawer®). Old hoses should not be
reused.
Failure to install the DishDrawer® correctly could invalidate any warranty or liability claims.
If the product is installed in a motor vehicle, boat or similar mobile facility, you must bring the vehicle, boat
or mobile facility containing the product to the service shop at your expense or pay the service technician's
travel to the location of the product.
NZ AU GB IE
