Installation instructions

DD605 and DS605 models
DishDrawer
NZ AU GB IE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DishDrawer DD605 and is the answer not in the manual?

Questions and answers

Related Manuals for Fisher & Paykel DishDrawer DD605

Summary of Contents for Fisher & Paykel DishDrawer DD605

  • Page 1: Installation Instructions

    Installation instructions DD605 and DS605 models DishDrawer NZ AU GB IE...

  • Page 2: Safety And Warnings

    At the completion of the DishDrawer® installation, the Installer must perform Final Check List. Remove all packaging materials supplied with the DishDrawer®. This dishwasher is manufactured for indoor use only. Ensure all water connections are turned OFF. It is the responsibility of the plumber and electrician to ensure that each installation complies with all Codes and Regulations.

  • Page 3: Table Of Contents

    Contents DOUBLE MODELS Product and cabinetry dimensions Installation Cavity preparation Route the hoses and move into the cavity Removing the tub and levelling the product Securing the product and refitting the tub Plumbing and drainage - OPTION 1 Plumbing and drainage - OPTION 1 (connection) Plumbing and drainage - OPTION 2 Plumbing and drainage - OPTION 2 (connection) Fitting the toekick...

  • Page 4: Product Dimensions

    Product dimensions Installation diagrams for illustration purposes only Product dimensions (mm) overall height* of product overall width of product overall depth of product (excl. curvature/handle) depth of drawer (open) (excl. curvature/handle) height* of chassis height range of levelling feet depth of chassis depth of drawer front panel depth of curvature or handle depth of kickstrip...

  • Page 5: Cabinetry Dimensions

    Installation diagrams for illustration purposes only Cabinetry dimensions (mm) inside height of cavity inside width of cavity inside depth of cavity (inside) height of adjacent cabinetry height of kickstrip Minimum clearances (mm) 2.5 mm Cabinetry dimensions 820 - 882.5 70 - 120 2.5 mm 13 mm 820 - 882.5...

  • Page 6: Parts Supplied

    Cavity preparation Parts supplied Drain hose Drain hose Wire clip (2) support (1) joiner (1) Hexagonal sockets (2) (Long & Short) If the Drain hose(s) supplied are not long enough to reach your services, you must use a Drain Hose Extension Kit P/N 525798 which will extend the drain hose(s) by 3.6m.

  • Page 7: Route The Hoses And Move Into The Cavity

    Route the hoses and move into the cavity Tie together to avoid kinking If top two tabs are being used, ensure they’re securely fitted before sliding product into cavity. optional optional Loosen feet first, but do not fully extend until product is in cavity. Ensure hoses and cord are not kinked or twisted.

  • Page 8: Removing The Tub And Levelling The Product

    Removing the tub and levelling the product Hexagonal socket 30 mm Ensure product is level. Using the most appropriate length Hexagonal socket supplied, and a screwdriver, fully extend levelling feet up to required distance. Ensure the tub is removed and then rotated counter-clockwise to prevent kinked hoses.

  • Page 9: Securing The Product And Refitting The Tub

    Securing the product and refi tting the tub The mounting tabs are in pairs, one on each side of the product. At least two sets of tab pairs must be used. A and B tab pairs OR B and C tab pairs or all three pairs.

  • Page 10: Plumbing And Drainage - Option 1

    Plumbing and drainage - OPTION 1 DishDrawer® and Standpipe Max. distance of Left hand hoses and cord from side chassis edge Drain hose 2011 mm Inlet hose 1561 mm Power cord 1776 mm Water Pressure Water softener models Other models Drains will need to be separated to satisfy Kosher requirements.

  • Page 11: Plumbing And Drainage - Option 1 (Connection)

    Plumbing and drainage - OPTION 1 (connection) DishDrawer® and Standpipe 38 mm Ø If space is limited for fixing, push hose through drain hose support to required height Fit supplied washer 750- max. 882.5 38 mm...

  • Page 12: Plumbing And Drainage - Option

    Plumbing and drainage - OPTION 2 DishDrawer® using sink trap with drain hose joiner Supplied drain hose joiner HIGHLOOP min. 150 mm Waste Water supply (COLD) Valve min. R200 mm...

  • Page 13: Plumbing And Drainage - Option 2 (Connection)

    Plumbing and drainage - OPTION 2 (connection) DishDrawer® using sink trap with drain hose joiner Ensure hoses are routed straight to joiner. Remove excess hose material if necessary. If space is limited for fixing, push hose through drain hose support to required height Fit supplied washer...

  • Page 14: Fitting The Toekick

    Fitting the toekick Important! D o not overtighten screw.
  • Page 16 Product dimensions Installation diagrams for illustration purposes only Product dimensions (mm) overall height* of product overall width of product overall depth of product depth of drawer (open) (excl. curvature/handle) height* of chassis depth of chassis depth of drawer front panel depth of curvature or handle height of drawer front height of venting area at base of product...
  • Page 17 Installation diagrams for illustration purposes only Cabinetry dimensions (mm) inside height of cavity inside width of cavity inside depth of cavity (inside) clearance below benchtop * Clearance is measured from the underside of benchtop to the chassis Minimum clearances (mm) 2.5 mm Cabinetry dimensions Minimum 3*...

  • Page 18: Cavity Preparation

    Cavity preparation Cavity Drain hose Drain hose Wire clip (1) support (1) joiner (1) If the Drain hose(s) supplied are not long enough to reach your services, you must use a Drain Hose Extension Kit P/N 525798 which will extend the drain hose(s) by 3.6m. The kit is available from the nearest Fisher & Paykel Authorized Service Agent or www.fisherpaykel.com.

  • Page 19: Route The Hoses And Move Into The Cavity

    Route the hoses and move into the cavity Tie together to avoid kinking Ensure hoses and cord are not kinked or twisted.

  • Page 20: Removing The Tub And Securing The Product

    Removing the tub and securing the product The mounting tabs are in pairs, one on each side of the product. Ensure the sound insulation is repositioned correctly. Ensure the tub is removed and then rotated counter-clockwise to prevent kinked hoses. 30 mm...

  • Page 21: Refitting The Tub

    Ensure the tub clips on both sides are reset. Ensure the tub is now rotated clockwise back. Refi tting the tub Before refitting the tub, ensure the hoses are not twisted and the latches at the rear of each drawer runner are facing forward.

  • Page 22: Plumbing And Drainage - Option 1

    Plumbing and drainage - OPTION 1 DishDrawer® and Standpipe Max. distance of Left hand hoses and cord from side chassis edge Drain hose 2011 mm Inlet hose 1561 mm Power cord 1776 mm Water Pressure Water softener models Other models 38 mm Ø...

  • Page 23: Plumbing And Drainage - Option 1 (Connection)

    Plumbing and drainage - OPTION 1 (connection) DishDrawer® and Standpipe 38 mm Ø If space is limited for fixing, push hose through drain hose support to required height Fit supplied washer 750- max. 882.5 38 mm...

  • Page 24: Plumbing And Drainage - Option

    Plumbing and drainage - OPTION 2 DishDrawer® using sink trap with drain hose joiner Supplied drain hose joiner HIGHLOOP min. 150 mm Waste Water supply (COLD) Valve min. R200 mm...

  • Page 25: Plumbing And Drainage - Option 2 (Connection)

    Plumbing and drainage - OPTION 2 (connection) DishDrawer® using sink trap with drain hose joiner If space is limited for fixing, push hose through drain hose support to required height max. 38 mm Fit supplied washer 750- 882.5...

  • Page 26: Final Checklist

    The drain hose connector must not support the weight of excess hoses. Keep hoses as fully extended as possible to prevent sagging. Any excess length of hose should be kept on the dishwasher side of the high loop. If using Plumbing and Drainage OPTION 2, ensure the Highloop is a minimum 150 mm higher than the drain hose connector.
  • Page 28 Copyright © Fisher & Paykel 2007. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time.
