DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. CYP (UK) Ltd assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be contained in this document.
SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
1. INTRODUCTION The PU-444HBTE Matrix enables distribution of four HDMI sources to four HDBaseT ™ outputs and four HDMI outputs. Each input is independently routed to any output for maximum source to screen flexibility within any AV system. The four HDBaseT outputs support the transmission of video...
4. SYSTEM REQUIREMENTS Source equipment with HDMI connection cables Certified CAT5e/6/7 cables HDMI over CAT5e/6/7 receivers with Certified CAT5e/6/7 cables Output displays or AV receivers with HDMI connection cables 5. FEATURES HDMI, HDCP and DVI complaint Common supported resolutions: HDTV: 480p, 576p, 720p, 1080i, 1080p, 1080p24;...
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel POWER LOCK MENU LCM: This monitor displays your setting information with each input and output selection. IR: This IR window accepts the remote control signal of this device only. Power Button & LED: Press this button to turn ON the device and the green LED will illuminate when the power is ON.
6.2 Rear Panel IR OUT IR IN IR OUT HDMI OUT CAT5e/6/7 OUT HDMI OUT CAT5e/6/7 OUT IR IN IR OUT IR IN IR OUT IR IN IR OUT HDMI OUT CAT5e/6/7 OUT HDMI OUT CAT5e/6/7 OUT IR IN HDMI IN 1 HDMI IN 2 HDMI IN 3 HDMI IN 4...
ALL IR OUT: This slot is to connect with the IR Blaster for IR signal received from receiver sides and send to the source side. ALL IR IN: This slot is to connect with the IR extender for IR signal receiving and send out to receiver sides.
IR Blaster Power 5 V IR Blaster Signal IR Extender IR Signal Power 5 V Ground 6.6 RS-232 Protocols PU-444HBTE Remote Control Console Assignment Assignment Baud Rate: 19,200bps Data bit: 8 bits Parity: None Flow Control: None Stop Bit: 1...
6.7 RS-232 & Telnet Commands Command Description A1~A4 Switch output A to 1~4 B1~B4 Switch output B to 1~4 C1~C4 Switch output C to 1~4 D1~D4 Switch output D to 1~4 E1~E4 Switch output E to 1~4 F1~F4 Switch output F to 1~4 G1~G4 Switch output G to 1~4 H1~H4...
Page 13
UARTBAUD? Display baud rate setting 1~6 1: 9600bps 2: 14400bps 3: 19200bps 4: 38400bps 5: 57600bps 6: 115200bps UARTBAUD2 Set output B’s baud rate from 1~6 UARTBAUD4 Set output D’s baud rate from 1~6 UARTBAUD6 Set output H’s baud rate from 1~6 UARTBAUD8 Set output H’s baud rate from 1~6 UARTSW?
6.8 Telnet Control Before attempting to use the telnet control, please ensure that both the Matrix (via the 'CONTROL' port) and the PC/Laptop are connected to the active networks. To access the telnet control in Windows 7, click on the 'Start' menu and type "cmd"...
Page 15
This will bring us into the device which we wish to control. Type "HELP" to list the available commands. Type “IPCONFIG” To show all IP configurations. To reset the IP, type “RSTIP” and to use a set static IP, type ”SETIP” (For a full list of commands, see Section 6.7).
6.9 Web GUI Control On a PC/Laptop that is connected to the active network as the Matrix, open a web browser and type device's IP address on the web address entry bar. The browser will display the device's status, control and User setting pages.
Page 17
Clicking on the 'User Setting' tab allows you to reset the IP configuration. The system will ask for a reboot of the device every time any of the settings are changed. The IP address needed to access the Web GUI control will also need to be changed accordingly on the web address entry bar.
7. CONNECTION DIAGRAM ZONE ZONE ZONE ZONE Power Link Power Link IR 1 IR 2 IR 1 IR 2 Extender Blaster RS232 Out Extender Blaster RS232 Out CAT5e/6 In CAT5e/6 In CAT5 RS-232 HDMI OUT CAT5e/6/7 OUT HDMI OUT CAT5e/6/7 OUT IR IN IR OUT IR IN...
Page 19
ZONE ZONE ZONE ZONE Power Link Power Link IR 1 IR 2 IR 1 IR 2 Extender Blaster RS232 Out Extender Blaster RS232 Out CAT5e/6 In CAT5e/6 In 5e/6/7 tputs Power tput Supply IR OUT IR IN IR OUT IR IN IR OUT HDMI OUT CAT5e/6/7 OUT...
8. SPECIFICATIONS 8.1 Technical Specification Video Bandwidth 225MHz/6.75Gbps Input Ports 4 x HDMI, 5 x IR Extender, 1 x RS-232, 1 x LAN (Control only), 1 x RJ45 (Control Only), 1 x USB Mini-B (Service Only) Output Ports 4 x HDMI, 4 x CAT5e/6/7, 5 x IR Blaster Power Supply 24V / 3.75A DC (US/EU standards, CE/FCC/UL certified)
8.3 Input Timing Support Chart HDMI Supported Input Resolutions Vertical Pixel HDMI Video Resolution Timing Frequency(Hz) Rate (MHz) Support Standard 640x480@60 60.00 25.175 VESA 31.500 VESA 640x480@72 72.00 31.500 VESA 640x480@75 75.00 36.000 VESA 640x480@85 85.00 35.500 VESA 720x400@85...
