REFLECTED POWER TOO HIGH
REMOVE AND REDUCE DRIVE POWER
RF PLATE =......V SHOULD BE ZERO
RF GRID =......W SHOULD BE ZERO
SCREEN VOLTAGE ON
BEFORE TIMEOUT OVER
TUNE CAPACITOR SYSTEM MALFUNCTION
+5V TOO HIGH (TOO LOW)
+/- 12V TOO HIGH (TOO LOW)
+24V /+48V TOO HIGH (TOO LOW)
* Abbreviations:
OFF5 - Turn the amplifier off for 5 minutes and try again.
RD&T - Reduce drive power from transceiver; do AUTO TUNE - see S.4-2.
CMV - Check the mains voltage and verify that it matches the voltage selector
- see S.2-2 and table 2-1.
CCC - Check the control cable from the transceiver to KEY-IN input - see
S.2-4.

9. SPECIFICATIONS

9-1. Parameters

a) Frequency Coverage: All amateur bands 1.8-29.7MHz
b) Power Output: 1500W PEP or continuous carrier, no mode limit.
In continuous carrier modes (RTTY etc.) for transmissions longer than 15 minutes (up to several
hours depending on ambient temperature), the optional auxiliary fan must be mounted.
c) Intermodulation Distortion: Better than 35dB below rated PEP output.
d) Hum and noise: Better than 35dB below rated output.
e) Harmonics Output Suppression: Better than 50dB below rated output.
f) Input and Output Impedances:
• nominal value: 50 Ohm unbalanced, UHF (SO239) type connectors;
• input circuit: broadband, VSWR less than 1.3:1, 1.8-30MHz continuously (no tunings, no
switching);
• bypass path VSWR less than 1.1:1, 1.8-30MHz continuously;
check antenna cable, selector, antenna and
grounding for loose contacts or worsened
insulation; trim the antenna for minimum
VSWR or use an antenna tuner; try another
antenna; check if REFLECTED POWER is
induced from another nearby transmitter.
RD&T*
OFF5*; CCC*
OFF5*; CCC*
OFF5*
OFF5*
CMV*
CMV*
CMV*
