Precise positioning allows you to place a design
on an exact spot on your fabric. It is also used
when you want to embroider a design next to a
previously embroidered design.
Use zoom and pan to be sure that you are placing
the design exactly where you want it. Fine tune
with the wheel.
overview
A Select locking point on screen
B
Place locking point on fabric
C
Select matching point on screen
D Place matching point on fabric
E
Touch function - move
F
Touch function - rotate
G Touch function - pan
H Wheel
I
Corner icons
J
Zoom to crosshair
To select
Select locking point on screen (A). Place the green
crosshair where you would like the locking point
to be in your embroidery. Use zoom to crosshair
(see below) to be able to place the crosshair exactly
where you want it.
To place
Next activate (B), place locking point on fabric.
The green crosshair will be locked on the screen,
changing color from green to black with a ring
around the center of the locking point. Now you
can place the design exactly where you want it on
the fabric by using the stylus or the wheel.
The position of the needle indicates where the
locking point is placed on the fabric.
Precise positioning is easy to use with the zoom
to crosshair option. Touch the zoom to crosshair
icon (J) to pan to the current crosshair position and
zoom in as much as possible on the screen. You can
position the locking and matching point on screen
exactly where you want them.
12
J
F
J
C
A
D
B
I
E
H
G
9:7
