IDT™

For sewing any fabric precisely PFAFF
4.5 sewing and embroidery machine provides
the ideal solution: the integrated dual feed, IDT™
system. As on industrial machines, the IDT™ system
feeds the fabric from the top and bottom at the
same time. The material is fed precisely, eliminating
puckering on seams in light weight fabrics such as
silk and rayon. The dual feed action of the IDT™
system prevents layers from shifting while sewing,
keeping quilt layers aligned and ensuring a more
perfect match when sewing plaid or striped fabrics.
IDT™
Important: For all work with the IDT™ system use
presser feet with the center back cut-out.
Raise the presser foot. Press the IDT™ system down
until it engages.
IDT™
Raise the presser foot. Hold the IDT™ system with
system down, then pull it away from you to release
the IDT™ system slowly upward.
1. Disengage the IDT
™
standard presser foot (B). Carefully loosen the
screw (C) until the cross-hole (D) is accessible.
2. Hold the foot in front of the needle. Turn the
hand wheel to lower the needle into the hole of
the foot and through the needle plate.
3. Turn the foot behind the needle screw (E) and
squeeze the foot to insert the pin of the foot into
the cross-hole (D) of the presser foot holder.
4. Push the foot into the hole as far as it will go
while tightening the screw (C).
To remove the embroidery foot loosen the screw
(C), squeeze the embroidery foot together and pull
it out to the right. Tighten the screw.
creative™
®
IDT™
system (A). Remove the
1
C
A
2
4
C
D
B
3
E
2:9
