Digital Day & Night
Color Dome Camera
사용 설명서
MANUAL
용 서
600 TVL

Advertisement

loading
Need help?

Need help?

Do you have a question about the DCC-580D Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for D-MAX DCC-580D Series

  • Page 1 Digital Day & Night Color Dome Camera 사용 설명서 MANUAL 용 서 600 TVL...
  • Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance...
  • Page 3 ■ Warning The camera needs periodic inspection. Contact an authorized technician for inspection. Stop using your camera when you find a malfunction. If you use your camera around smoke or unusual heat for a long time, fire may be caused. Do not Install the camera on a surface that can not support it.
  • Page 4 ■ Precautions Only use the camera under conditions It can cause the image quality to be where temperatures are between poor. -10°C and +50°C. Be especially careful to provide ventilation when operating under high temperatures Severe lighting change or flicker can It is one of the most important parts of cause the camera to work improperly.
  • Page 5: Table Of Contents

    ■ Contents ------------------------------ 1.Features ------------------------------ 2. Cable Connection & OSD Control ------------------------------ 3. Setup Menu Operation ------------------------------ 4. Special menu ------------------------------ 5. Troubleshooting ------------------------------ 5. Dimensions ------------------------------ 6. Specifications...
  • Page 6: Features

    1. Features ☺ Ultra High Resolution 600 TV Lines Clear image quality has been achieved by employing SONY CCD with 410,000(effective) pixels, which provides a horizontal resolution of 600 TV lines. ☺ Excellent Sensitivity The built-in high sensitivity COLOR CCD enable a clear image even in 0.05Lux (color), 0.0001Lux (Sens-Up) or lower illumination.
  • Page 7: Cable Connection & Osd Control

    2. Cable Connection & OSD Control 1) Cable Connection 2) OSD Control ① 3AXIS BRACKET - Please loosen screws and fix tilted and panned position. ③ LENS : Vari-Focal Auto Iris Lens ( 4.0mm ~ 9.0mm / F1.5 ) ③ OSD PCB SETUP button : Used for the menu display.
  • Page 8: Setup Menu Operation

    3. Setup Menu Operation • Menu Structure MAIN MENU • DC • VIDEO • MANUAL LENS • BRIGHTNESS • SHUTTER • AGC EXPOSURE • SENS-UP • RETURN • ATW • OUTDOOR • INDOOR WHITE BALANCE • MANUAL • AWC-SET • OFF •...
  • Page 9 When the LEFT or RIGHT button is pressed, available values and modes are displayed in order. Please keep pressing the button until you get to the mode you wish to operate. ④ Please select 'EXIT' and then press the SETUP button to finish the setting. Note) •...
  • Page 10 1. BRIGHTNESS EXPOSURE When the lens is selected MANUAL, it can be adjusted BRIGHTNESS. 1. BRIGHTNESS 2. SHUTTER 3. AGC HIGH 2. SHUTTER 4. SENS-UP You can select either auto or manual shutter. 5.RETURN↙ Shutter speed is fixed at 1/60sec(1/50sec) ▶...
  • Page 11 3) WHITE BALANCE MAIN MENU 1. LENS DC↙ The screen color can be adjusted by using the 2. EXPOSURE↙ WHITE BALANCE function. 3. WHITE BAL - Please indicate the arrow to point 'WHITE 4. SSDR BAL' on the SETUP menu by using the UP and 5.
  • Page 12 select ‘SSDR’ by using the Up and Down buttons so that the arrow indicates ‘SSDR’ - Use the Left/Right buttons to change the DWDR level in the sub menu according to the contrast between bright and dark areas. 5. BACKLIGHT MAIN MENU Unlike conventional cameras, this camera is 1.
  • Page 13 Select ‘BLC’ to adjust the area to be HLC : Enable the user to change the enhanced then adjust the level level, limit, mask color/tone and area Note) • Because there can be a difference in the effectiveness of HLC according to the amount of light area in the screen, optimize the installation angle for the best HLC performance •...
  • Page 14 Note) • You cannot set the SSNR to ‘ON’ or ‘OFF’ when the AGC mode of the EXPOSURE menu is ‘OFF’ • When adjusting the noise reduction level in the SSNR mode, remember that the higher the level set, the more the noise level will be reduced, as will the brightness of the image.
  • Page 15: Special Menu

    SPECIAL MENU MAIN MENU SPECIAL 1. LENS DC↙ 1. IMAGE ADJ↙ 2. EXPOSURE↙ 2. MONITOR LCD↙ 3. WHITE BAL 3. CAM TITLE 4. SSDR 4. SYNC 5. BACKLIGHT 5. MOTION DET 6. DNR3 ON↙ 6. PRIVACY 7. DAY/NIGHT COLOR 7. DIS 8.
  • Page 16 Notes ) • When the V-REV or H-REV mode is enabled, the text on the screen does not flip. • If you increase the SHARPNESS level too high, the picture may become distorted or noise may appear. 2) Monitor Please change the settings value of video appropriate to your monitor.
  • Page 17 Notes) • When the CAM TITLE menu is ‘OFF’, no title will be displayed on the monitor screen even if you enter one • Only English is available in this mode. • If you move the cursor to CLR and press the SET button, all the letters are deleted.
  • Page 18 SENSITIVITY. • SEL POS : Determines which of the 4 vertices of each MD area is to be used. • YPOS : Determines the coordinate of the vertical axis for SEL POS. • XPOS : Determines the coordinate of the horizontal axis for SEL POS. •...
  • Page 19 Notes) • As the DIS function uses the digital zoom the camera's resolution will decrease. • DIS doesn’t operate when background illumination is too low. • DIS doesn’t operate when object pattern is monotonic as like sky or white wall. 8) LANGUAGE You can select the menu language according to your requirements.
  • Page 20: Troubleshooting

    Troubleshooting If there are problems in operation, please refer to the items below. If the problem persists, please contact the agent you purchased this product from Problems Troubleshooting • Please check the power connection. Nothing appears on the screen. • Please check the video signal line connection. •...
  • Page 21: Dimensions

    5. Dimensions...
  • Page 22: Specifications

    6. Specifications ▪ GENERAL Signal system NTSC 1/3” Sony HAD CCD Image Sensor Total Pixels 811(H)X508(V) 795(H)X596(V) Effective Pixels 768(H)X494(V) 752(H)X582(V) Resolution 600TV lines Scanning Frequency 15.734KHz(H), 60(V) 15.625KHz(H), 50(V) Shutter Speed 1/60~1/100,000 sec 1/50~1/100,000 sec Min. Illumination Color : 0.05Lux @ F 1.2, 0.0001Lux (Sense-up 512x) Day &...
  • Page 23 Dome Type Install Type Indoor Indoor Indoor Outdoor(IP66) Outdoor(IP66) 100(Bubble) x 120(Bubble) x 100(Bubble) x 100(Bubble) x 100(Bubble)x Dimension 76(H)mm 95(H)mm 139.5(H)mm 103(H)mm 107.5(H)mm 3 Axis 3 Axis 3 Axis 2 Axis 2 Axis 3 Axis Material Plastic Body & Plastic Body PC Bubble, PC Bubble, Aluminum Body...
