Summary of Contents for D-MAX DCC-708DV
- Page 1 DISTRIBUTED BY...
- Page 2 COLOR VANDAL DOME CAMERA USER MANUAL 680 TVL...
- Page 3 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
- Page 4 ■ Precautions Only use the camera under It can cause the image quality to conditions where temperatures are be poor. between -10°C and +50°C. Be especially careful to provide ventilation when operating under high temperatures. Severe lighting change or flicker It is one of the most important can cause the camera to work parts of the camera.
- Page 5 ⊙ Features ■SONY 1/3" 480K/570K-Effective Pixel Ex-view HAD CCD II Minimum Resolution 0.1 Lux (F1.2, 50 IRE) ■High Resolution: More than 680 TV Lines This camera has realized high resolution of 680 TV lines using the top-notch full digital image processing, 12 Bit A/D serial signal processing and special algorithm technologies. ■NR (Digital Noise Reduction) The DNR technology eliminates noise thus generating a distinct and clear image.
- Page 6 ⊙ Cable Connection POWE VIDEO ⊙ Dimension...
- Page 7 ⊙ Assemble This part is dome cover to protect camera This part is camera lens There are 2 screws to adjust angle camera. There are 3 holes to fix camera on a ceiling or wall * How to install ① Fix the camera body on a ceiling or wall via 3 holes. ②...
-
Page 8: Specifications
⊙ Specifications SIGNAL SYSTEM NTSC TOTAL PIXEL 1020(H) × 596(V) 1020(H) × 596(V) 976(H) × 494(V) 976(H) × 582(V) EFFECTIVE PIXEL Sony 1/3" 480K/570K-Effective Ex-view HAD CCD Ⅱ IMAGE SENSOR HORIZONTAL RESOLUTION 680 TV Line 0.1Lux (50IRE)/0.02Lux(15IRE) MINIMUM ILLUMINATION B/W:0.08Lux(50IRE)/0.002Lux(15IRE) 3.6 mm Manual Lens 4-9mm Auto Iris Lens LENS...
