BUS_INTERFACE DEBUG = microblaze_0_mdm_bus
BUS_INTERFACE DLMB = dlmb
BUS_INTERFACE ILMB = ilmb
PORT MB_RESET = mb_reset
PORT INTERRUPT = xps_intc_0_Irq
END
BEGIN plb_v46
PARAMETER INSTANCE = mb_plb
PARAMETER HW_VER = 1.05.a
PORT PLB_Clk = clk_100_0000MHzMMCM0
PORT SYS_Rst = sys_bus_reset
END
BEGIN lmb_v10
PARAMETER INSTANCE = ilmb
PARAMETER HW_VER = 1.00.a
PORT LMB_Clk = clk_100_0000MHzMMCM0
PORT SYS_Rst = sys_bus_reset
END
BEGIN lmb_v10
PARAMETER INSTANCE = dlmb
PARAMETER HW_VER = 1.00.a
PORT LMB_Clk = clk_100_0000MHzMMCM0
PORT SYS_Rst = sys_bus_reset
END
BEGIN lmb_bram_if_cntlr
PARAMETER INSTANCE = dlmb_cntlr
PARAMETER HW_VER = 2.10.b
PARAMETER C_BASEADDR = 0x00000000
PARAMETER C_HIGHADDR = 0x00001fff
BUS_INTERFACE SLMB = dlmb
BUS_INTERFACE BRAM_PORT = dlmb_port
END
BEGIN lmb_bram_if_cntlr
PARAMETER INSTANCE = ilmb_cntlr
PARAMETER HW_VER = 2.10.b
PARAMETER C_BASEADDR = 0x00000000
PARAMETER C_HIGHADDR = 0x00001fff
BUS_INTERFACE SLMB = ilmb
BUS_INTERFACE BRAM_PORT = ilmb_port
END
BEGIN bram_block
PARAMETER INSTANCE = lmb_bram
PARAMETER HW_VER = 1.00.a
BUS_INTERFACE PORTA = ilmb_port
BUS_INTERFACE PORTB = dlmb_port
END
BEGIN axi_uartlite
PARAMETER INSTANCE = RS232_Uart_1
PARAMETER C_BAUDRATE = 9600
PARAMETER C_DATA_BITS = 8
PARAMETER C_USE_PARITY = 0
PARAMETER C_ODD_PARITY = 0
PARAMETER HW_VER = 1.01.a
PARAMETER C_BASEADDR = 0x83000000
PARAMETER C_HIGHADDR = 0x8300ffff
PARAMETER C_INTERCONNECT_S_AXI_MASTERS = plbv46_axi_bridge_0.M_AXI
BUS_INTERFACE S_AXI = axi_interconnect_0
PORT RX = fpga_0_RS232_Uart_1_RX_pin
PORT TX = fpga_0_RS232_Uart_1_TX_pin
PORT Interrupt = RS232_Uart_1_Interrupt
PORT S_AXI_ACLK = clk_100_0000MHzMMCM0
END
BEGIN mpmc
PARAMETER INSTANCE = DDR3_SDRAM
