X-Ref Target - Figure A-5
720
Video Scaler v4.0 User Guide
UG805 March 1, 2011
1280
480
270
aperture_start_pixel = 0
aperture_end_pixel = 479
Figure A-5: Zoom (Up-scaling) reading from External Memory,
20
HSF = 2
www.xilinx.com
output_y_size
= 720
aperture_start_line
= 0
aperture_end_line
= 269
20
x 480/1280; VSF = 2
x 270/720
Typical Uses
output_h_size = 1280
UG678_4-7_081809
73
