Summary of Contents for Gazer S110

  • Page 1 Internet store of PHONES (044) 360-7-130 294-0-130 autogoods (050) 336-0-130 597-0-130 (063) 788-0-130 SKYPE (067) 233-0-130 km-130 (068) 282-0-130 CAR RECEIVERS — Receivers • Media receivers and stations • Native receivers • CD/DVD changers • FM-modulators/USB adapters • Flash memory • Facia plates and adapters • Antennas • Accessories | CAR AUDIO —...
  • Page 2 Autogood products Internet store “130”...

  • Page 3: Table Of Contents

    Co n t en ts Camera Precaution ..........1 Technical Specification .......... 2 Camera Description ..........3 Camera Mounting Description ....... 5 Battery Installation ..........7 Turning On/Off the Camera ........8 Taking Video Footage ..........8 Menu Settings ............9 VGA/QVGA Shifting ..........

  • Page 4: Camera Precaution

    Camera Precaution Notice the following guidelines when using your camera The action cam is not shock-proof. You should avoid dropping it. For your safety, do not press the buttons on the camera during sports activities. Do not place the camera in a damp or dusty location for extended periods of time.

  • Page 5: Technical Specification

    Technical Specification 'Sensor 1,З Меgа pixels CMOS sensor /*Lens All glass lens Built-in memory 64MB SD Memory Card slot support up to 8G (Not included) Movie storage: VGA 640 x 480 pixels (50 FPS) QVGA320 x 240 pixels (50 FPS) Movie format AVI Battery 2 x AAalkaline batteries Autogood products Internet store “130”...

  • Page 6: Camera Description

    Camera Description Lens Camera grip Screw Handlebar grip Helmet grip O-ring USB cable AV cable Short Velcro strap Long Velcro strap Rubber head strap Bolt Autogood products Internet store “130”...
  • Page 7 LCD display ON/OFF & Enter button Movie shutter button Menu button Microphone Mini-USB port AV port SD card slot SD card (not included) Battery door 2X AA Batteries (not included) Autogood products Internet store “130”...

  • Page 8: Camera Mounting Description

    Camera Mounting Description The camera can be mounted in a number of ways Using the straps provided. Please follow the methods of mounting as suggested below: Fixing the position of the camera a) Turn it anti-clockwise to screw the camera tight and fix it into position. b) Turn it clockwise to unscrew the camera.
  • Page 9 Mounting the camera using the Velcro strap: 1+2.Place the helmet grip on the helmet, and thread the Velcro strap through the helmet grip. 3. Secure the Velcro strap by fastening it through the helmet vents. 4. Slide the camera into the helmet grip, and adjust the angle of the camera...

  • Page 10: Battery Installation

    Battery Installation 1. Unscrew the cover at the end of the unit. 2. Place yourfinger on the 'lip', which is on the bottom half of the rear of the unit, and open the battery slot door. 3. Insert 2 x AAalkaline batteries into the battery slot according to the polarity direction as shown.

  • Page 11: Turning On/Off The Camera

    Turning the Camera On Press and hold the power button, The LCD display will light up (one beeping sound). It enters video mode, The time displayed on screen is the remaining time for taking video, the first two numbers display hours, the last two numbers display minutes.

  • Page 12: Menu Settings

    Menu Setting VGA/QVGA Shifting (Video resolution setting) Press and hold the Menu button for 2 seconds, When the VGA icon 640 x 480 flickers (at the top ofthe LCD display), press the Shutter button once to shift to QVGA 320 x 240, then press the menu button to confirm.

  • Page 13: Time Setting

    menu button to delete all the video footage. To quit the menu and return to video mode, press again the shutter button. Time Setting Press the Menu for about 2 seconds to enter setting, the VGA icon flicks , press the shutter button repeatedly after it exists "...

  • Page 14: Playing Back Video Footage On Tv

    Set the Hour 3.After setting the Date, the small icon "H" flicker, meantime, The first digit of hour flickers, press the 'shutter' button to adjust number(01-24), then press the menu button to confirm Set the minute 4.After setting the Date, the small icon "M" flicker, meantime, The first digit of minute flicker, press the 'shutter' button to adjust number (01-59), then press the menu button to confirm When time setting finishes, press the menu button to return to video mode.

  • Page 15: Connecting To Pc& Pc Cam

    Connecting to PC 1.Turn the Action Cam on. 2.Connect the Action Cam to a PC via the USB cable. 3."PC" appears on the Action Cam LCD screen, open "My computer", check a new disk on your computer, open the new disk you will see the video footages. Remark: If there is no external memory card, PC will display the built in Memory disk, if there is SD/MMC card, PC will display SD/MMC card storage disk.
  • Page 16 Long press the "Menu" button on camera first, then connect the camera to computer via USB cable, the camera LCD will display "PC", open the "My computer", double click the camera icon , you could use it as PC camera. Remark: When the voltage below 2.4V, low battery icon will displayed, you should prepare to change the battery, when it run out of battery, the camera will continuous beeping, after three seconds, the camera will shut off automatically.

  • Page 17: Troubleshooting

    Troubleshooting There's no display -Are the batteries properly installed? -Do the batteries need replacing? After the Action Cam is connected to my PC, it cannot find the new drive in the 'My Computer' folder -Make sure each end of the Action Cam USB cable is properly and firmly connected.
  • Page 18 The remaining time is not accurate -The remaining time is not always accurate, it is an estimate. -The remaining time depends not only on the time recorded, but on the color density of the video footage. Under conditions with high contrast, such as outdoors, the actual time available will be less than under low-contrast conditions, such as indoors.
  • Page 19 Press the shutter button for about 5 seconds, LCD display "FOR", wait a moment it returns to video mode, the card is formatted successfully. Autogood products Internet store “130”...
