Specifications

Model TVE-110
Video/Audio input Video compression
Analog video input
Audio compression
Audio input
Bi-directional audio
input
Audio output
Video/Audio output Recording resolution
Frame rate
Video bit rate
Stream type
Audio bit rate
Dual stream
External interface Network interface
Serial port
Alarm in
Alarm out
Others Protocol
Consumption
Operating temperature
Operating humidity
Dimensions
Weight
Model TVE-410
Video/Audio input Video compression
Analog video input
Audio compression
Audio input
Bi-directional audio
input
Audio output
56
H.264/MPEG4/MJPEG
1-ch, BNC connector (1.0 Vp-p, 75 Ω);
PAL / NTSC adaptive
G.711
1-ch, 3.5mm interface
1-ch, 3.5mm interface
(Using AUDIO IN)
1-ch, 3.5mm interface (Linear, 600 Ω)
WD1 / 4CIF / 2CIF / CIF / QCIF
Main stream:
WD1 / 4CIF / 2CIF / CIF @ 25 fps (P) / 30 fps (N)
Substream:
WD1 @ 2 fps / 4CIF @4 fps / 2 CIF @ 8fps / CIF
@12 fps / QCIF @ 25 fps(P) 30fps(N)
32 kbps to 8192 kbps
Video/ Video & Audio
64 kbps
Support
1, RJ45 10 M / 100 M adaptive Ethernet interface
1 RS-485 interface, half-duplex
1
1
Support CGI, PSIA and ONVIF
Max. 6W
-10 to +55 C° (14 to 131 °F)
10 to 90%
80 x 39 x 90 mm
270 g (0.59 lb.)
H.264/MPEG4/MJPEG
4-ch, BNC connector (1.0 Vp-p, 75 Ω);
G.711
4-ch,
1-ch, 3.5mm interface
1-ch, 3.5mm interface (Linear, 600Ω)
