Name
5. Video function toolbar
6. Video parameters
7. Preset
setup/selection
8. PTZ control panel
To see live view:
1. Open the encoder's web browser screen. See Figure 6.
2. Double-click a camera from the device list to select a camera to view.
3. Click the Display Format

Capturing a snapshot

In live view mode, click the snapshot button on the video function toolbar to
capture live pictures. A pop-up message will appear on screen to confirm that the
capture was successful. The image is saved as a JPEG file on the computer.
Note: Configure where the snapshots are saved on your computer in the
Configuration > Local Configuration page.
12
Description
Switch to main or substream.
Click to start/stop live view.
/
Enable e-PTZ (must be supported by the connected
camera).
Click to capture a snapshot of a video image. The image
is saved on the computer.
Click to manually start/stop recording video.
/
Click to display the previous camera view.
Click to display the next camera view.
Click to turn audio on/off.
/
Start/Stop two-way audio.
/
Adjust the brightness, hue, saturation and contrast of live video.
Set up and select presets.
Control PTZ of the currently selected camera, adjust the speed of
PTZ movement and turn on/off the camera light and wiper.
button to view multiple video tiles.
