Live view

Live view mode is the normal operating mode of the device where you watch live
images from the cameras. The encoder automatically enters into live mode once
powered up. On the viewer, you can see the current date and time, camera
name, and whether a recording is in progress.

Description of live view

Figure 6: Live view
Name
1. Menu toolbar
2. Viewer
3. Device list
4. Display format
TVE-110/410/810/1610 H.264 IP Video Encoder User Manual
Description
Lets you do the following:
• View live video
• Play back video
• Search for event logs
• Configure settings
• Exit the interface
View live video.
Display the encoder and its channels.
Define how you want video to be displayed in the viewer;
single screen, 2X2, 3X3 or 4X4.
When in multiview mode, double-click a video tile to get
full-screen mode. Double-click again to return to
multiview mode.
Click to switch to full screen mode.
11
