Media Settings (continued)
Menu Item
SENSOR TYPE
GAP
CONTINUOUS
REFLECTIVE
LABEL LENGTH
04.00in (0-99.99)
MAXIMUM LABEL LENGTH
16.00in (0-99.99)
PAPER OUT DISTANCE
00.25in (0-99.99)
LABEL WIDTH
XX (X-XX)
RIBBON LOW OPTIONS
RIBBON LOW DIAMETER
1.40in (1.00 – 2.00)
24
Selects the Top Of Form (TOF) sensing method used to
determine the leading edge of the label, where:
Senses the gaps or notches in the media.
TOF sensing is not used; see LABEL LENGTH.
Senses the reflective (black) marks on the underside of
the media.
Determines the length of the label when the SENSOR
TYPE is set to CONTINUOUS, where:
Is the desired length of the format.
Sets the distance that the printer will feed GAP or
REFLECTIVE media before declaring a TOF fault, where:
Is the length of travel to detect a TOF gap or mark.
Note: This distance should be 2.5 to 3 times the
length of the label.
Sets the Out Of Stock fault (empty) distance, where:
Is the attempted length of feed before empty is
declared.
Note: If using clear or translucent media, this
setting should be longer than the length of
the label.
Sets the maximum printable width. Objects extending
beyond this limit will NOT print, where:
Is the maximum width; see Appendix A for the model
dependant default and range.
Defines the response when THERMAL TRANSFER is
selected and the ribbon supply diminishes, where:
Sets the threshold that will trigger a Low Ribbon
Warning prompt, where:
Is the outer diameter size of the ribbon roll.
