7 .5.3 Paper Sensor (Paper Exit Sensor PT2)
Tools
Phillips Screwdriver #2
Disassembly Procedures
1.
Remove the paper exit cover. (See the item 7.1.5.)
2.
Disconnect the harness connector connected to the the paper exit sensor (PT2).
3.
Remove the paper exit sensor from the paper exit guide (paper exit stay).
Assembly Procedures
1.
Install a new paper exit sensor to the paper guide.
2.
Connect the harness connectors with the paper exit sensor.
3.
After the above , follow exactly the reverse order of disassembling procedures.
Replacement Procedures for Maintenance Parts
169
